BEA 10BODYMNT Bodyguard-T Spacer Mounting Bracket for Electronic Access Control

Professional Sensor Mounting Solution

The BEA 10BODYMNT is a specialized spacer mounting bracket designed for Bodyguard-T series sensors in electronic access control applications. This mounting accessory provides proper sensor positioning when door control enclosures or other objects may interfere with the sensor’s detection pattern, ensuring optimal performance in commercial installations.

Professional Features & Benefits

  • Bodyguard-T Series Compatibility: Specifically engineered for use with Bodyguard-T sensors for seamless integration and reliable mounting.
  • Pattern Clearance Solution: Positions sensors away from obstructions like door control enclosures that could block detection patterns.
  • Commercial-Grade Construction: Built for demanding commercial electronic access control applications where reliable sensor operation is critical.
  • Professional Installation: Provides secure mounting platform for consistent sensor positioning and performance.
  • Versatile Application: Suitable for various commercial installations where mounting clearance is required for optimal sensor function.

Technical Specifications

  • Technology: Active Infrared
  • Detection Mode: Presence
  • Installation Height: Variable 108 in max (9 ft); recommended 78 in - 96 in (6.5 ft - 8 ft)
  • Mounting Angles: Bodyguard Only: 5 deg., 10 deg. (factory default: 5 deg.) | With Bodymount: 0 deg., 5 deg., 10 deg.
  • Power Supply: 12 - 24 VAC / DC +/-10%
  • Mains Frequency: 50 - 60 Hz
  • Output Max. Contact Current: 1 A
  • Max. Contact Voltage: 60 VDC / 125 VAC
  • Max Power Supply: 30 W (DC), 60 VA (AC)
  • Relay Hold Time: 0.5 - 9 s
  • Operating Temperature: -22 deg. F - 140 deg. F
  • Immunity: Immune to electrical and radio frequency interference
  • Cable: 48 in (4 ft) - 6-conductor cable
  • Weight: 1 lb. 11 oz.
  • Dimensions: 11.8 in (W) x 1.9 in (H) x 1.9 in (D)
  • Material: Aluminum & ABS plastic
  • Housing: Black anodized aluminum

Installation & Operation

This spacer mounting bracket is designed for use with compatible Bodyguard-T series sensors. Refer to the parent device installation instructions and manufacturer documentation for proper integration. Ensure compatibility with existing hardware before installation.

Professional Applications

  • Commercial Building Security Systems
  • Electronic Access Control Installations
  • Door Control System Integration
  • Sensor Positioning Solutions
  • Commercial Facility Access Management
  • Industrial Security Applications

Why Choose BEA Quality?

BEA electronic access control components deliver professional-grade reliability with specialized mounting solutions engineered for demanding commercial applications. The 10BODYMNT spacer bracket ensures proper sensor positioning for optimal detection performance where dependable access control operation is essential.

Manufacturer Resources

BEA Product Catalog

Product Specs

Product Type:
Spacer
Subcategory:
Parts and Accessories
Commercial/Residential:
Commercial
Electronic:
Yes
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Series:
Bodyguard-T
Product Category:
Electronic Access Control
Department:
Door Hardware

BEA BEA-10BODYMNT – Frequently Asked Questions

1) What does the BEA 10BODYMNT bracket actually do for a Bodyguard-T sensor?
It is a spacer bracket that pushes the Bodyguard-T sensor out from the mounting surface so a door control enclosure or similar obstruction does not sit inside the detection pattern. Nothing electrical changes; it is purely a positioning platform for the sensor head.
2) Will adding the Bodymount spacer change the mounting angles I can set on a Bodyguard-T?
Yes, it adds a 0 degree option. A Bodyguard-T on its own gives 5 and 10 degrees, with 5 degrees as the factory default. With the Bodymount in place you can set 0, 5 or 10 degrees, so it is the part to order when you need the beam aimed straight down rather than angled.
3) I have a header-mounted sensor at about 8 feet with a door operator box in the way. Is this the right fix?
That is exactly the case the spacer is made for. The Bodyguard-T mounts up to 108 inches (9 ft) with 78 to 96 inches (6.5 to 8 ft) recommended, and at those heights an operator or control enclosure on the header can clip the presence pattern. The 10BODYMNT sets the sensor forward of the enclosure so the active infrared presence field stays clear.
4) Can a ROFU 20934 spacer be used in place of the BEA 10BODYMNT bracket?
No. The ROFU 20934 is a 1/2 inch spacer for the 8600 Series electric strikes, made to shim an 8512 or 8612 strike in the frame. The BEA 10BODYMNT is a spacer mounting bracket for Bodyguard-T series sensors, used to stand the sensor off from door control enclosures or other obstructions so the detection pattern is not blocked, and it also opens up a 0 degree mounting angle in addition to the 5 and 10 degree positions the Bodyguard offers on its own. They mount to different parts of the opening and are not interchangeable.
5) Is the spacer bracket a wired component I need to power or terminate?
No wiring is involved in the bracket itself. Power and output belong to the Bodyguard-T sensor, which runs on 12 to 24 VAC/DC plus or minus 10 percent with a 48 inch six-conductor cable and a dry contact rated 1 A, 60 VDC / 125 VAC. The spacer just holds the sensor; route the sensor's existing cable through as normal.
6) Do I need the 10BODYMNT if the header is clear of obstructions?
No. With an unobstructed header the Bodyguard-T mounts directly and runs at its factory default 5 degree angle. Order the spacer only when something blocks the pattern or when you specifically need the 0 degree straight-down setting, which is only available with the Bodymount fitted.
7) I need a spacer for an electric strike, not a sensor - is the BEA 10BODYMNT the right part?
No. The 10BODYMNT is a Bodyguard-T sensor spacer bracket that repositions an active infrared presence sensor mounted overhead at a recommended 78 to 96 inches. For shimming an electric strike in the frame, the ROFU 20934 is the 1/2 inch spacer built for 8600 Series 8512 and 8612 strikes.
8) Can this bracket be used on an exterior door or an unheated garage entry?
Yes. The Bodyguard-T assembly is rated from -22 to 140 degrees F, and the bracket is aluminum and ABS plastic with a black anodized aluminum housing, so it holds up on exterior and unconditioned openings. It is a commercial-duty part rather than a residential accessory.
