BEA 10MS51W-SKIT Touchless Single Gang Battery-Powered Actuator Kit with 900 MHz Wireless Transmission

Professional Touchless Access Control Solution

The BEA 10MS51W-SKIT is a complete touchless actuator kit featuring battery-powered operation with built-in 900 MHz wireless transmission for flexible installation without extensive wiring. This comprehensive kit includes two 10MS51W-S "Wave To Open" hand logo faceplates with surface-mount boxes and one 900 MHz receiver module. The MS51W series delivers three years of uninterrupted battery operation with LED battery status alerts for easy maintenance monitoring.

Professional Features & Benefits

  • Extended Battery Life: Three years of uninterrupted operation reduces maintenance requirements and ensures reliable performance in commercial applications.
  • Wireless 900 MHz Transmission: Built-in transmitter eliminates extensive wiring requirements and provides flexible mounting options for various installation scenarios.
  • Complete Kit Solution: Includes (2) 10MS51W-S faceplates with surface-mount boxes and (1) 900 MHz receiver module for immediate installation capability.
  • Environmental Resilience: Engineered for reliable operation in challenging conditions including harsh lighting and cold weather climates with selectable immunity modes.
  • Weather Protection: Selectable immunity modes mitigate environmental disturbances such as rain, water spray, and snow for consistent outdoor performance.
  • Maintenance Monitoring: LED alerts indicate battery status for proactive maintenance scheduling and uninterrupted operation.
  • Germ-Free Operation: Active infrared touchless technology provides door activation without physical contact for safer interactions and improved hygiene.
  • Accessibility Enhancement: "Wave To Open" hand logo faceplates improve traffic flow and provide enhanced accessibility for users with mobility challenges.

Technical Specifications

  • Technology: Microwave Doppler Radar
  • Detection Mode: Motion (bidirectional), Toggle or Timed Mode
  • Sensing Zone: 2 in - 24 in (adjustable)
  • Hold Time: 1 s - 30 s
  • Alert Settings (Audible): Silent Mode or Signal Mode
  • Alert Settings (Visual): Blue (Standby); Green (Activation)
  • Supply Voltage: 12 - 24 VAC / VDC or 5 VDC
  • Current Consumption: < 2.8 W
  • Temperature Range: -22 deg. F - 158 deg. F
  • Enclosure Rating: NEMA 4 / IP65
  • Relay: 1-Form C Solid State Relay; 1 A; 30 VAC / VDC (max)
  • Dimensions (Single Gang): 2.75 in (W) x 4.5 in (H) x 0.98 in (D)
  • Dimensions (Double Gang): 4.5 in (W) x 4.5 in (H) x 0.98 in (D)
  • Dimensions (Jamb): 1.68 in (W) x 4.5 in (H) x 0.98 in (D)
  • Wire Harness Length: 12 in
  • Material: Stainless Steel (faceplate) / ABS (center)

Installation & Operation

  1. Verify electrical requirements match available power supply. Confirm voltage per specifications and current capacity before proceeding.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the unit in the specified location ensuring adequate clearance for wiring access, ventilation, and future service requirements.
  4. Route and connect wiring according to manufacturer wiring diagrams. Use appropriate wire gauge and connectors for the application.
  5. Configure operational settings including any configurable options per application requirements.
  6. Restore power and test all functions including normal operation, alarm/alert functions, and integration with connected systems.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Building Security Systems
  • Healthcare Facility Access Control
  • Educational Institution Safety Systems
  • Retail Loss Prevention
  • Industrial Facility Monitoring
  • Emergency Exit Compliance
  • Multi-Tenant Residential Access Control

Why Choose BEA Quality?

BEA touchless actuator products deliver professional-grade reliability with active infrared technology engineered for three years of uninterrupted battery operation. The MS51W series features environmental resilience designed for challenging conditions including harsh lighting and cold weather climates. Engineered for demanding commercial applications where dependable touchless access control and enhanced accessibility are essential.

Manufacturer Resources

BEA Product Catalog

Product Specs

Product Type:
Touchless Actuator
Series:
MS51W Series
Subcategory:
Sensors, Switches, Relays and Timers
Commercial/Residential:
Commercial
Electronic:
Yes
Product Group:
Electronic Access Controls
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Category:
Electronic Access Control
Department:
Door Hardware

BEA BEA-10MS51W-SKIT – Frequently Asked Questions

1) Does the BEA 10MS51W-SKIT wave-to-open kit need wiring run to the actuators?
No wiring to the push plates. Each of the two 10MS51W-S faceplates is battery powered and transmits over 900 MHz to the receiver module that ships in the kit, so the only connection you make is at the receiver end. That is what makes it workable on existing masonry, glass storefront walls, or finished corridors where fishing wire to both sides of an opening is the expensive part of the job. The kit contains two faceplates with surface-mount boxes and one 900 MHz receiver, so a typical two-sided opening (interior and exterior push plate) is covered out of the box.
2) Will a BEA touchless actuator work outdoors in rain and snow?
The MS51W actuator carries a NEMA 4 / IP65 enclosure rating and an operating range of -22 deg. F to 158 deg. F, so an exterior push plate is within its design envelope. It also has selectable immunity modes that reduce nuisance activations from rain, water spray, and snow, which is the practical failure mode on an exterior wave plate: a wet gust triggering the operator all afternoon. Stainless steel faceplate with an ABS center section.
3) How close does someone have to get their hand to a BEA MS51W wave plate for it to activate?
The sensing zone is adjustable from 2 in out to 24 in. Tighten it down in a tight vestibule or where people walk close past the plate without meaning to open the door; open it up in a hospital corridor or anywhere a gurney, cart, or gloved hand needs a generous target. Hold time is separately adjustable from 1 s to 30 s, which is how you tune how long the operator stays energized after the wave.
4) What does the BEA 900 MHz receiver need for power and how does it connect to my door operator?
The receiver runs on 12 - 24 VAC/VDC or 5 VDC, drawing under 2.8 W, and switches through a 1-Form C solid state relay rated 1 A at 30 VAC/VDC maximum. That dry contact is what lands on the actuation input of the low energy operator. It ships with a 12 in wire harness, so plan the receiver location within reach of the operator's terminal strip or extend the run yourself. Check your operator's actuation input against the 1 A / 30 V relay limit before wiring.
5) How often will I have to change batteries in a BEA wireless touchless switch, and will I know when?
Three years of operation per the MS51W spec, and the plate gives an LED battery status alert rather than simply going dead. For a property manager or MRO group running a fleet of openings that matters more than the number itself: the alert lets you fold the swap into a scheduled round instead of getting a call that a door stopped working. The plate's standby LED shows blue and goes green on activation, so a walk-by tells you the unit is alive.
6) Can a BEA MS51W actuator be set to latch the door open instead of just cycling it?
Yes. Detection mode is selectable between bidirectional motion, toggle, or timed operation. Toggle mode is the one to use when a receiving door or a delivery entrance needs to be held open for a stretch and then closed with a second wave. Timed mode gives a fixed hold, adjustable 1 s to 30 s. There is also an audible alert choice, silent or signal mode, which is worth setting to silent in a patient care area or a quiet lobby.
7) I only need one wave plate on the door, not two. Is the BEA 10MS51W-SKIT still the right thing to order?
The 10MS51W-SKIT is packaged as a two-plate kit: two 10MS51W-S single-gang faceplates and one 900 MHz receiver. Most low energy operator jobs want a plate on each side of the opening, so the kit matches the common case. If your opening genuinely only takes one plate, the second is a spare for the next door or for a plate that gets damaged, but you are still buying the pair, since the kit is not split.
8) Does the BEA MS51W come in a narrow jamb-mount size for a storefront mullion?
The MS51W plate is offered in three footprints: single gang at 2.75 x 4.5 x 0.98 in, double gang at 4.5 x 4.5 x 0.98 in, and a jamb version at 1.68 x 4.5 x 0.98 in. The 10MS51W-SKIT supplies the single-gang plates. If you are mounting to a narrow aluminum stile or mullion where 2.75 in of face width will not sit flat, the 1.68 in jamb form is the one that fits, and the kit is not it.
