BEST 45HCA Series Heavy Duty M...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$584.00
$404.32
BEST 45HCA Series Heavy Duty Mortise Lockbody with Hotel Function - Field Reversible

BEST 45HCA Series Heavy Duty Mortise Lockbody with Hotel Function - Field Reversible

(No reviews yet) Write a Review

Model: 45HCAHJ626
$584.00
$404.32
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$584.00
$404.32
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

BEST 45HCA Series Heavy Duty Mortise Lockbody with Hotel Function - Field Reversible

Professional Grade Mortise Lock Solution for Commercial Hospitality Applications

The BEST 45HCA Series mortise lockbody delivers heavy-duty performance specifically designed for hotel and hospitality applications. This field-reversible lockbody features a 2-3/4" backset with solid stainless steel components and Grade 1 operational strength per ANSI A156.13 standards. The case construction utilizes 0.095" cold rolled steel measuring 5-7/8" H x 7/8" D x 4-1/16" W for exceptional durability in high-traffic commercial environments.

Professional Features & Benefits

  • Heavy-Duty Case Construction: 0.095" cold rolled steel case with zinc dichromate plating provides superior corrosion protection and structural integrity for demanding commercial applications.
  • Solid Stainless Steel Latch: One-piece anti-friction latch delivers 50% more surface contact with strike for enhanced strength and security with precision-engineered curve for extended cycle life.
  • Field Reversible Design: Reversible latch rotates 180 degrees for easy handing change without opening the case, plus four-position hub toggle for flexible installation requirements.
  • Enhanced Security Features: Armored front completely surrounds latch and deadbolt providing increased lateral strength with self-aligning design during installation.
  • Grade 1 Performance: Meets ANSI A156.13 Series 1000 Grade 1 Operation and Strength standards with Grade 2 Security rating for professional hospitality applications.
  • Roller Bearing Hub Mechanism: Provides smooth, wear-resistant operation with lever return spring mechanism for positive lever return and enhanced protection against lever droop.
  • Standard Door Compatibility: Designed for 1-3/4" thick doors with thick door configuration available for doors up to 5" thick when specified.
  • Antimicrobial Finish Options: Available with UltraShield antimicrobial protected coating (626AM and 630AM finishes) for healthcare and hospitality applications where cleanliness is priority.

Technical Specifications

45H Series –The design and operation of the BEST® mortise lock meets the intent
of the standard for ANSI A117.1 section 404.2.6.
Builders Hardware Manufacturers Association:
45H Series –ANSI A156.13, Series 1000, Grade 1 Operation and Strength, Grade 2 Security. To meet Grade 1 Security, a drill resistant core
(1CD, 1CDP, 1CDF, or 1CDX) must be used with escutcheon trims, and 1EK7K4 high security cylinder must be used with sectional trims.
47H Series – ANSI A156.13, Series 1000, Grade 1 Operational, Strength, and Security

Auxiliary bolt – Stainless steel, non-handed.
Backset – 2-3/4"
Case –0.095” cold rolled steel, 5- 7/8" H x 7/8" D x 4-1/16" W. Steel is zinc dichromate plated for corrosion protection.
Deadbolt – Stainless steel, 1" throw.
Latchbolt –Solid stainless steel, 3/4" throw. Latch is oil-impregnated for anti-friction operation. Reversible without opening case.
Strike – For complete strike package spec’s see page 5.
Door Thickness – Standard lock configuration designed for doors 1-3/4" thick. Thick door configuration available for doors up to
5" thick (specify thickness when ordering).
Faceplate –Stainless steel, brass or bronze material, 8" H x 1-1/4" W x 1/16" T. Lock face automatically adjusts to proper bevel during
installation.
Products protected by one or more of the following patents: 4,873,853 5,590,555 5,794,472
Finishes –
• 605 - bright brass, clear coated
• 606 – satin brass, clear coated
• 611 – bright bronze, clear coated
• 612 – satin bronze, clear coated
• 613* – oxidized satin bronze, oil rubbed
• 618 – bright nickel plated, clear coated (brass base material)
• 619 – satin nickel plated, clear coated (brass base material)
• 622 – flat black coated (brass base material) 625 – brightchromium plated (brass base material)
• 626 – satin chromium plated (brass base material)
• 629 – bright stainless steel
• 630 – satin stainless steel
• 690* – dark bronze coated (brass base material)
*613 finish is designed to wear over time, providing an “antique” appearance.
*690 finish will continue as a dark brown appearance over time.
Antimicrobial Finish –
• 626AM – satin chrome plated with UltraShield™ antimicrobial protected coating
• 630AM – satin stainless steel with UltraShield™ antimicrobial protected coating
The BEST UltraShield finish inhibits the growth of bacteria and other microbes on the surface of the hardware.
NOTE: BEST UltraShieldTM option is recommended for use on any hardware application where product cleanliness is a high priority. i.e;.
Hospital/Healthcare, Elderly Care, Education, Transportation, Food-Service, Hospitality.

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness (standard 1-3/4" or up to 5" thick door configuration), mortise pocket dimensions, and handing requirements.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces for proper backset alignment.
  3. Prepare door mortise pocket to accommodate case dimensions of 5-7/8" H x 7/8" D x 4-1/16" W and route faceplate area for 8" H x 1-1/4" W installation.
  4. Install lockbody into mortise pocket and secure with appropriate fasteners per manufacturer torque specifications, ensuring armored front self-aligns with door bevel.
  5. Configure four-position hub toggle settings and adjust latch reversibility as needed for proper handing without opening case.
  6. Test lockbody operation to verify proper function of latch throw (3/4"), deadbolt throw (1"), and all mechanical components. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Hotel and Hospitality Guest Rooms
  • Motel and Extended Stay Properties
  • Resort and Conference Center Accommodations
  • Healthcare Patient Room Access
  • Educational Institution Dormitories
  • Senior Living and Assisted Care Facilities
  • Commercial Building Private Offices

Antimicrobial Protection Option

BEST UltraShield antimicrobial finish options (626AM satin chrome and 630AM satin stainless steel) inhibit the growth of bacteria and other microbes on hardware surfaces. Recommended for healthcare, elderly care, education, food service, and hospitality applications where product cleanliness is a high priority.

Why Choose BEST Quality?

BEST 45HCA Series mortise lockbodies deliver professional-grade reliability with 0.095" cold rolled steel construction and solid stainless steel components engineered for demanding commercial hospitality applications. Grade 1 operational and strength performance per ANSI A156.13 standards ensures dependable service in high-traffic environments. Patent-protected design features and comprehensive finish options including antimicrobial protection provide the durability and hygiene standards required for professional hospitality installations.

Product Specs

Series:
45H
Standard Cylinder:
SFIC Prep Less Core
Duty Level:
Heavy Duty
Keyed Function:
Single Cylinder
Product Group:
Mechanical Locks
Product Subgroup:
Mortise Locks and Trim
Product Type:
Mortise Lock Body
Subcategory:
Mortise
Keyed:
Yes
Commercial/Residential:
Commercial
Lock Type:
Mortise
Lock Function:
Hotel
Product Attribute:
Mortise Locks
Electronic:
No
Product Function:
Hotel/Motel
Face Plate:
8" H x 1-1/4" W x 1/16" T
Product Category:
Mechanical Locks
Backset (Distance):
2-3/4"
Department:
Door Hardware

BEST 45HCAHJ626 – Frequently Asked Questions

1) Does the BEST 45HCA hotel function mortise lock come with a cylinder or core?
No core is included. The 45HCA lockbody is prepped for a BEST small format interchangeable core (SFIC) and ships less core, so you order the core and keying separately. It is a single cylinder keyed function, meaning key access on one side only, which is normal for a hotel guest room opening. Note that to reach ANSI A156.13 Grade 1 Security rather than the Grade 2 Security the lock carries by itself, a drill resistant core (1CD, 1CDP, 1CDF or 1CDX) has to be used with escutcheon trim, or a 1EK7K4 high security cylinder with sectional trim.
2) Is the BEST 45HCA lockbody handed, or can I change the handing in the field?
Handing is field reversible. The stainless latchbolt rotates 180 degrees without opening the case, and a four-position hub toggle lets you set the lock for the opening you have. The auxiliary bolt is non-handed. You still pick a hand when ordering (RH, LH, RHRB or LHRB), but a lock that shows up set wrong can be flipped on site instead of returned.
3) What door thickness does the BEST 45H mortise lockbody fit?
Standard configuration is built for 1-3/4 inch doors, which covers most commercial openings. For anything thicker, up to 5 inches, a thick door configuration is available but you have to state the actual door thickness when you order. Ordering standard and hoping it reaches will leave you short on spindle and cylinder length.
4) What mortise pocket and edge prep do I need for the BEST 45HCA?
Cut the pocket for a case measuring 5-7/8 x 7/8 x 4-1/16 inches, and route the door edge for a faceplate of 8 x 1-1/4 x 1/16 inches. Backset is 2-3/4 inches, so lever and cylinder holes get bored to that centerline. The armored front self-aligns to the door bevel during installation, so you do not need to order a beveled face for a beveled door.
5) Will the BEST 45HCA latch into the strike that is already in my frame?
The latchbolt throws 3/4 inch and the deadbolt throws 1 inch at a 2-3/4 inch backset, which is the standard mortise geometry, so an existing mortise strike cut for a 45H or 40H series lock will normally take it. What changes fit is the strike lip: if your frame sits proud of the jamb face you can order the 7/8 inch lip-to-center strike option instead of the standard. Measure from the frame stop to the door face before you decide.
6) Am I buying a complete lockset or just the case?
Just the case. The 45HCA is a mortise lockbody only. To finish the opening you still need trim (lever or knob with escutcheon or sectional rose), the SFIC core and keying, and the strike. Decide on trim style early, because it determines which core or cylinder you need to hit Grade 1 Security.
7) Which finish should I order for a healthcare or senior living corridor?
Two antimicrobial options are offered: 626AM satin chrome and 630AM satin stainless, both carrying the BEST UltraShield coating that inhibits growth of bacteria and other microbes on the hardware surface. BEST recommends it for hospital and healthcare, elderly care, education, transportation, food service and hospitality. Thirteen standard finishes are also available, from 605 bright brass through 630 satin stainless and 690 dark bronze. Two of those age on purpose: 613 oil rubbed bronze is meant to wear to an antique look, and 690 stays a dark brown over time, so neither is a good pick if you need new locks to match existing ones exactly years later.
8) What do I have to specify when ordering the BEST 45HCA besides finish?
Four things beyond finish. Handing (RH, LH, RHRB or LHRB) even though the lock reverses in the field. Whether you want security head screws. Whether you need the 7/8 inch lip-to-center strike instead of standard. And door thickness if the door is over 1-3/4 inches, up to the 5 inch maximum. Core and keying are ordered separately since the case comes SFIC prepped less core.
9) Is this mortise lock durable enough for a high-traffic guest room door?
It is built as heavy duty commercial hardware. The case is 0.095 inch cold rolled steel with zinc dichromate plating for corrosion resistance, the latchbolt is one-piece solid stainless with an anti-friction oil-impregnated curve that gives roughly 50 percent more contact with the strike, and the hub runs on roller bearings with a lever return spring to resist lever droop. That combination is what Grade 1 Operation and Strength under ANSI A156.13 is measuring.
10) Is the BEST 45HCA an electronic or access control lock?
No, it is a purely mechanical mortise lockbody with key and thumbturn operation. There is no card reader, no wiring and no electrified option on this case. If a hotel needs credential-based guest room access, this is not the right product family.
