Bobrick B-6806.99 Diameter Straight Grab Bar Pee
1-1/2″ (38mm) diameter tubing. Satin-Finish, slip-resistant surface stainless steel grab bar for bath/shower/toilet compartment. Snap Flange. Add .99 for peened surface.
Available lengths straight/satin:
B-6806 x 12: 12″ (305mm)
B-6806 x 18: 18″ (455mm)
B-6806 x 24: 24″ (610mm)
B-6806 x 30: 30″ (760mm)
B-6806 x 36: 36″ (915mm)
B-6806 x 42: 42″ (1065mm)
B-6806 x 48: 48″ (1220mm)
Available lengths straight/peened:
B-6806.99 x 12: 12″ (305mm)
B-6806.99 x 18: 18″ (455mm)
B-6806.99 x 24: 24″ (610mm)
B-6806.99 x 30: 30″ (760mm)
B-6806.99 x 36: 36″ (915mm)
B-6806.99 x 42: 42″ (1065mm)
B-6806.99 x 48: 48″ (1220mm)
Features
- Stainless steel, satin finish with peened grip
- Surface Mount
- 48″ L x 1-1/2″ Diameter
- Cover snaps over mounting flange to conceal screws
- This unit meets ADA Accessibility Guidelines in the U.S.
Product Specs
- Finish : Satin-Finish Stainless Steel, Satin-Finish Stainless Steel - Peened
- Configuration : Straight
- Diameter : 1-1/2" (38mm)
- Accessibility : ADA Compliant
Resources
Manufacturer Resources
Product Specs
- Capacity:
- 900 lbs
- Product Type:
- Grab Bars
- Product Group:
- Washroom/Bath Accessories
- Product Subgroup:
- Grab Bars
- Product Diameter:
- 1-1/2"
- Product Material:
- Stainless Steel
- Department:
- Plumbing
Bobrick 6806.99x12 – Frequently Asked Questions
1) What is the difference between the Bobrick B-6806 and the B-6806.99 grab bar?
Same bar, different grip surface. The .99 suffix adds a peened surface to the satin-finish stainless tubing, so the B-6806.99 gives a textured, slip-resistant grip instead of the plain satin bar. Everything else matches: 1-1/2 inch diameter stainless tubing, straight configuration, surface mount with a snap flange, and the same 12, 18, 24, 30, 36, 42 and 48 inch lengths. If you want the peened grip, you have to order the .99 part number, not the plain B-6806.
2) What length grab bar do I need for an ADA toilet compartment?
For a standard ADA water closet you generally need two bars: a 42 inch on the side wall and a 36 inch on the rear wall. The B-6806.99 covers both, and also comes in 12, 18, 24, 30 and 48 inch. The 48 inch is the one to reach for on a roll-in shower wall or an oversized stall; the short 12 and 18 inch sizes are typically vertical or transfer assists rather than the primary horizontal bars.
3) Does the Bobrick B-6806.99 hide the mounting screws?
It does. The bar uses a snap flange, and the cover snaps over the mounting flange to conceal the screws once the bar is fastened to the wall. That is why it is a common pick for finished restrooms where an exposed-screw flange looks unfinished, and it means the fasteners are not sitting out where the public can get at them.
4) Will a peened grab bar work in a shower or wet area?
That is what the peened surface is for. The B-6806.99 is a slip-resistant, peened satin stainless bar intended for bath, shower and toilet compartment use, and the textured surface holds grip better than smooth satin when hands are wet or soapy. Stainless tubing handles the humidity. Peened bars are also harder to keep looking clean than smooth satin, which is the usual reason a spec calls for the plain B-6806 in a dry-side lavatory run and the .99 inside the shower.
5) Is the Bobrick B-6806.99 surface mounted or does it recess into the wall?
Surface mount. The B-6806.99 fastens flat to the finished wall face through flanges at each end, so there is no wall cutout or recessed carrier to coordinate. That makes it the straightforward option for retrofitting a bar into an existing restroom, where you are working off finished tile and cannot open up the partition.
6) Can I standardize a whole building on the Bobrick B-6806.99 across different stall sizes?
Yes, and that is the usual reason it gets specified fleet-wide. One part number covers seven lengths, 12 through 48 inches, all in the same 1-1/2 inch peened satin stainless with the same snap flange, so every bar in the building looks identical and only the length changes by location. Maintenance carries one finish, and a replacement bar in any size matches the ones already up.
7) How do I order a specific length of the Bobrick B-6806.99 grab bar?
Length is called out after the model number: B-6806.99 x 36 is the 36 inch peened bar, B-6806.99 x 42 the 42 inch, and so on through x 12, x 18, x 24, x 30 and x 48. Drop the .99 and you get the same bar in plain satin. Getting the suffix right matters, since the number without .99 ships smooth, not peened.
8) Will the Bobrick B-6806.99 match the grab bars already installed in my restrooms?
If what is up now is a 1-1/2 inch satin stainless bar with a concealed-screw flange cover, the B-6806.99 will read as a match in profile and finish, with one difference you can see and feel: the .99 is peened, so it has a textured grip rather than a smooth one. To match plain smooth bars exactly, order the B-6806 without the .99. Mixing the two in the same room is noticeable up close.
