Bolts 3/8-16 x 1/2 HXBT Br (Jar 100)
Additional Notes
- other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Country Of Origin:
- China
- Division:
- Electrical H1
- Fastener Head Color:
- Brass
- Fastener Head Type:
- Hex
- Fastener Length:
- 2-Jan
- Language Code:
- EN
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- CT
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 3.6 in
- Product Length:
- 3 in
- Product Weight:
- 1297 g
- Product Width:
- 76.2 MM
- Sub Division:
- Electrical-E H2
- Thread Per Inch:
- 16
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- JBRHC
- Product Details:
- Hexagonal Bolt
- Product Material:
- Brass
Metallics JBRHC88 – Frequently Asked Questions
1) Are these bolts solid brass or just brass plated?
Solid brass. The material is listed as brass and the head color as brass, so the bolt is brass through, not a plated steel fastener. That matters for grounding and bonding work and for outdoor or damp locations where a plated steel bolt would rust and a dissimilar metal could set up galvanic corrosion against brass or copper bus.
2) Will a 1/2 inch long bolt be long enough for my application?
At 1/2 inch of shank, you have very little grip length, so the JBRHC88 is for thin stack-ups: a lug pad, a flat bar, a bonding jumper tab into a tapped hole or a nut. If your combined material thickness plus washers is more than about a quarter inch you will run out of thread and need a longer 3/8-16 bolt, and Metallics lists other sizes available by request.
3) Can I buy fewer than 100 of the Metallics JBRHC88 brass hex bolts?
No. The JBRHC88 ships as a jar of 100 and the order minimum is 100 count, so the jar is the smallest unit. If you need a different size or a different quantity, Metallics offers other sizes and quantities by request.
4) Do these brass bolts meet Buy American requirements on a federal job?
The JBRHC88 is flagged compliant for both ARRA and Buy American, while country of origin is listed as China. On a federally funded job, give your specifier both facts, since the compliance path on fasteners often turns on the specific clause in your contract.
5) What size wrench or socket do I need for a 3/8-16 brass hex bolt?
It's a hex head bolt, and a 3/8-16 hex cap screw normally takes a 9/16 inch wrench or socket. Brass is softer than steel, so snug it with a hand wrench rather than an impact driver to avoid rounding the head or stripping the threads.
