Burndy YAV8CLBOX Ring Terminal Lug, 8 AWG Copper, #8-10 Stud

Burndy YAV8CLBOX Ring Terminal Lug, 8 AWG Copper, #8-10 Stud

(No reviews yet) Write a Review

Model: YAV8CLBOX

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1.60
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Burndy YAV8CLBOX Ring Terminal Lug, 8 AWG Copper, #8-10 Stud

The Burndy YAV8CLBOX is a heavy-duty copper compression ring terminal lug for 8 AWG conductors (AN-8 Flex), terminating on a #8-10 stud. This short-barrel, 1-hole ring tongue lug has an inspection window for crimp verification and a tin-plated finish for corrosion resistance. Part of Burndy's HYLUG™ line, it is UL Listed and CSA Certified.

Key Features

  • Conductor Size: 8 AWG stranded copper, AN-8 Flex, Copper Stranded Range 9-8.
  • Copper Construction: Solid copper compression lug body for high conductivity.
  • Tin-Plated Finish: Tin - Electro Plated coating resists corrosion.
  • Ring Tongue Design: 1-hole ring terminal, straight tongue angle, inspection window.
  • Stud Compatibility: Accepts a #8-10 stud with a 0.2 in bolt hole.
  • Compact Dimensions: Short barrel, 1.15 in length, 0.41 in pad width, 1/2" strip length.
  • HYLUG™ Series: Part of Burndy's HYLUG™ compression connector line.

Certifications & Compliance

  • UL Listed
  • CSA Certified
  • UL467 Compliant
  • Military Specified (Mil-Spec), Class 1
  • RoHS Compliant

Technical Specifications

  • Mounting Holes: 1
  • Plated (Yes or No): Y
  • CSA Certified: Y
  • Product Description: Copper Compression Lug, Heavy Duty, Ring Tongue, 1 Hole w/ Inspection Window, AN 8 Flex, #8 - #10 Stud, Short Barrel, Tin Plated
  • Copper Solid Size (Range): N/A
  • CULUS: N
  • UL Listed: Y
  • Mil-Spec Class Code: Class 1
  • Bulk Package: YAV8CL
  • UPC: 781810541104
  • Navy Cable Size (Range): N/A
  • Installation Tooling: Non-Ratchet:MY29-11Ratchet:MR4C, MR8-9Q, Y8MRB-1, M8ND w/ N8CT Die Set
  • Type of Plating: Tin - Electro Plated
  • Industry Standards: UL467,Military Specified (Mil-Spec)
  • Pad Width (in): 0.41
  • Copper Stranded (Range): 9-8
  • ROHS Compatible: Compliant
  • Tongue Angle: Straight
  • Length (in): 1.15
  • Connector Type: Ring Terminal
  • Strip Length: 1/2"
  • UL Recognized: N
  • Stud Size (in): #10,#8
  • Dimension - Bolt Size fraction: #8 - #10
  • Dimension - Bolt Hole Size inch: 0.2 in
  • Physical Attribute - Number of Holes: 1
  • Conductor - Copper Str Size Range: 8 AWG
  • Product Type: Terminal
  • Trade Name: HYLUG™

Typical Applications

  • Commercial and Industrial Electrical Connections
  • Grounding and Bonding Terminations
  • Panelboard and Equipment Wiring
  • Mil-Spec Compliant Installations
  • Motor and Equipment Lead Terminations

Why Burndy?

Burndy's YAV8CLBOX HYLUG™ lug delivers dependable, code-compliant connections backed by UL Listing, CSA Certification, and Mil-Spec Class 1 compliance. Solid copper construction and tin plating ensure lasting conductivity.

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
BURNDY-20260915
Mounting Holes:
1
Plating:
Tin Plated
Termination Method:
Compression
Plated (Yes or No):
Y
CSA Certified:
Y
CULUS:
N
UL Listed:
Y
Mil-Spec Class Code:
Class 1
Bulk Package:
YAV8CL
UPC:
781810541104
Installation Tooling:
Non-Ratchet:MY29-11Ratchet:MR4C, MR8-9Q, Y8MRB-1, M8ND w/ N8CT Die Set
Type of Plating:
Tin - Electro Plated
Industry Standard(s):
UL467,Military Specified (Mil-Spec)
Pad Width (in):
0.41
Copper Stranded (Range):
9-8
ROHS Compatible:
Compliant
Aircraft Cable Size (Range):
AN 8
Tongue Type:
Ring
Tongue Angle:
Straight
Length (in):
1.15
Connector Type:
Ring Terminal
Strip Length:
1/2"
Ul Recognized:
N
Stud Size (in):
#10,#8
Dimension - Bolt Size fraction:
#8 - #10
Dimension - Bolt Hole Size inch:
0.2 in
Physical Attribute - Number of Holes:
1
Conductor - Copper Str Size Range:
8 AWG
Product Type:
Ring Terminal
Trade Name:
HYLUG™
Product Material:
Copper
Department:
Electrical
Product Subgroup:
Lugs & Terminals
Product Group:
Wire Connectors & Terminals

Burndy YAV8CLBOX – Frequently Asked Questions

1) Will the Burndy YAV8CLBOX fit 8 AWG stranded copper wire?
Yes. The YAV8CLBOX HYLUG barrel is sized for 8 AWG stranded copper, with a stranded range of 9-8, so a 9 AWG stranded conductor also terminates correctly. It is also rated for AN 8 aircraft cable. Strip back 1/2 inch of insulation before crimping. Solid conductors are not part of its rated range.
2) What crimp tool and die do I need to install a Burndy YAV8 lug?
Burndy specifies MY29-11 for non-ratchet crimping, or MR4C, MR8-9Q, Y8MRB-1, or M8ND with the N8CT die set for ratchet tools. This is a compression lug, not a mechanical set-screw type, so it has to be crimped with one of those tools. The inspection window lets you confirm the conductor bottomed out in the barrel before you crimp.
3) Can I use this lug for a grounding and bonding termination?
Yes. The YAV8CLBOX is built to UL467, the standard for grounding and bonding equipment, and is UL Listed and CSA Certified. Solid copper body with electro-tin plating, which is what you want where the connection may see moisture or dissimilar metal contact.
4) Does this Burndy terminal meet Mil-Spec requirements?
It is Military Specified, Class 1, and RoHS compliant. That covers defense and shipboard work where a Mil-Spec class code has to appear on the submittal. Note it is UL Listed rather than UL Recognized.
5) Is the YAV8CLBOX sold as a box, and what is the bulk part number?
YAV8CLBOX is the boxed packaging of the same HYLUG lug. Burndy lists YAV8CL as the bulk package designation for buyers standardizing on this size in volume. Same lug either way: 8 AWG copper, #8-10 stud.
