Burndy YE26R60 Aluminum Terminal Plug, 2/0 AWG Compression Connector

Burndy YE26R60 Aluminum Terminal Plug, 2/0 AWG Compression Connector

(No reviews yet) Write a Review

Model: YE26R60

In Stock (leaves warehouse same day if ordered before 3pm ET)

$42.31
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Burndy YE26R60 Aluminum Terminal Plug, 2/0 AWG Compression Connector

The Burndy YE26R60 Aluminum Terminal Plug is an aluminum Hyplug compression connector engineered as a terminal plug for 2/0 Str. Al and 2/0 (6/1) Quail AWG ACSR conductors. This 9-1/2 in (9.50 in) connector features a 1/0 Sol. pin diameter with a 6 in pin length, a tin-plated finish, and a gray color code for quick size identification, delivering a reliable compression termination for aluminum and ACSR conductor applications.

Key Features

  • Conductor Range: Sized for 2/0 AWG aluminum stranded conductors and 2/0 (6/1) Quail AWG ACSR conductors.
  • Durable Aluminum Construction: Aluminum Hyplug connector body built for utility-grade conductor terminations.
  • Compression Termination: Compression-style connection method for a secure, low-resistance mechanical and electrical joint.
  • Overall Length: 9-1/2 in (9.50 in) terminal plug length.
  • Pin Dimensions: 1/0 Sol. pin diameter with a 6 in pin length.
  • Tin-Plated Finish: Type of plating is tin, protecting against corrosion and maintaining conductivity.
  • Color Code: Gray color coding for fast size identification in the field.

Certifications & Compliance

  • RoHS Compliant

Technical Specifications

  • Termination Method: Compression
  • Color Code: Gray
  • UL Recognized: N
  • Plated (Yes or No): Y
  • ROHS Compatible: Compliant
  • Index Number: 249,840,11A
  • Product Description: Aluminium Hyplug Connector; 2/0 Str. Al 2/0 ACSR; 9-1/2 in L; Terminal Plug for Aluminum and ACSR
  • Type of Plating: Tin
  • Pin Diameter (in): 1/0 Sol.
  • CULUS: N
  • CSA Certified: N
  • Aluminum Size (Range): 2/0 AWG
  • Prefilled (Oxide Inhibitor): N
  • UL Listed: N
  • UPC: 781810154205
  • Length (in): 9.50
  • Pin Length (in): 6
  • ACSR Size (Range): 2/0 (6/1) Quail AWG
  • Conductor - ACSR Str Size Range: 2/0 (6/1) Quail AWG
  • Conductor - AL Str Size Range: 2/0 AWG
  • Product Type: Compression

Typical Applications

  • Overhead Distribution and Transmission Lines
  • Utility Pole and Line Hardware Installations
  • Aluminum and ACSR Conductor Terminations
  • Substation and Switchyard Wiring
  • Grounding and Bonding for Utility Infrastructure

Why Burndy?

Burndy engineers the YE26R60 aluminum Hyplug connector with a tin-plated finish and compression termination method to deliver a dependable connection for 2/0 AWG aluminum and ACSR conductors. The RoHS-compliant construction and color-coded gray identification support consistent, code-aware installations for utility and industrial electrical professionals.

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
BURNDY-20260915
Termination Method:
Compression
Series:
Hyplug
Color Code:
Gray
Ul Recognized:
N
Plated (Yes or No):
Y
ROHS Compatible:
Compliant
Index Number:
249,840,11A
Length (Fraction):
9-1/2
Type of Plating:
Tin
Pin Diameter (in):
1/0 Sol.
CULUS:
N
CSA Certified:
N
Aluminum Size (Range):
2/0 AWG
Prefilled (Oxide Inhibitor):
N
UL Listed:
N
UPC:
781810154205
Length (in):
9.50
Pin Length (In.):
6
ACSR Size (Range):
2/0 (6/1) Quail AWG
Conductor - ACSR Str Size Range:
2/0 (6/1) Quail AWG
Conductor - AL Str Size Range:
2/0 AWG
Product Type:
Compression
Product Material:
Aluminum
Department:
Electrical
Product Subgroup:
Lugs & Terminals
Product Group:
Wire Connectors & Terminals

Burndy YE26R60 – Frequently Asked Questions

1) What conductor sizes does the Burndy YE26R60 Hyplug terminal plug accept?
The YE26R60 takes 2/0 AWG stranded aluminum, or 2/0 (6/1) Quail ACSR. One size only, so a 1/0 or 4/0 run needs a different Hyplug catalog number. The gray color code on the body is the field marker for that size.
2) Is the YE26R60 a copper connector or aluminum, and can I use it on copper conductor?
It is an aluminum body, tin plated, and the conductor range covers aluminum stranded and ACSR only. Use it for aluminum and ACSR terminations, not copper conductor. The tin plating is what lets the aluminum barrel land on a plated or dissimilar-metal pad without the bare-aluminum corrosion problem.
3) Does the Burndy YE26R60 come prefilled with oxide inhibitor?
No. The YE26R60 ships without inhibitor in the barrel, so you need to brush the conductor and apply a compound yourself before crimping the aluminum or ACSR. Skipping that step on aluminum is the usual cause of a hot joint.
4) What are the pin dimensions on the YE26R60 terminal plug?
The pin is 1/0 Sol. diameter with 6 inches of pin length, on a connector 9-1/2 inches long overall. Check the pin diameter against the socket or clamp it is going into, since a 1/0 solid equivalent pin will not seat correctly in a device sized for a different pin.
5) Is the Burndy YE26R60 UL Listed or CSA certified?
It is not UL Listed, not UL Recognized, not cULus and not CSA certified. It is RoHS compliant. If your specification requires a UL or CSA marked terminal, this Hyplug plug will not satisfy it, so specify a listed connector instead.
6) Is the YE26R60 a bolted or a compression connection?
Compression. The barrel is crimped onto the conductor with a die and tool, so there is no bolt to torque and nothing to retighten later. If you want a joint you can take apart in the field, a mechanical or bolted lug is the better choice; if you want a permanent low-resistance termination on an overhead aluminum or ACSR run, this is the right style.
7) What is the Burndy part number and UPC for this 2/0 aluminum terminal plug?
Order it as Burndy YE26R60, Hyplug series, UPC 781810154205. Burndy also references it by index number 249,840,11A.
8) Where is a Hyplug terminal plug like the YE26R60 typically used?
Utility work: overhead distribution and transmission line terminations, pole and line hardware, substation and switchyard wiring, and grounding and bonding on utility infrastructure, wherever a 2/0 aluminum or 2/0 Quail ACSR conductor has to be converted to a pin for landing in a socket-type device.
