Cal-Royal HOS-PP30 Hospital Pu...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$225.42
$173.17
Cal-Royal Cal-Royal HOS-PP30 US32D Hospital Push / Pull Latch, Passage Lock - Stainless Steel HOS-PP30-US32D

Cal-Royal HOS-PP30 Hospital Push/Pull Latch, Passage Lock - Stainless Steel

(No reviews yet) Write a Review

Model: HOS-PP30-32D

In Stock (leaves warehouse same day if ordered before 3pm ET)

$225.42
$173.17
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Cal-Royal HOS-PP30 Hospital Push/Pull Latch, Passage Lock - Stainless Steel

The Cal-Royal HOS-PP30 Hospital Push/Pull Latch is a passage lock engineered for high-traffic commercial doors where hands-free operation is essential. Featuring stainless steel covers and paddles, this UL-listed latch is designed for a 1 ¾" door thickness with a standard 2 ¾" backset and an optional 5" backset for alternate door preparations. Ideal for use in hospitals, washrooms, or public buildings, the HOS-PP30 meets ADA requirements and can be installed in 6 different mounting positions for maximum installation flexibility.

Key Features

  • Door Thickness Compatibility: Designed for 1 ¾" door thickness with a standard 2 ¾" backset and optional 5" backset for flexible door preparation.
  • Face Plate Dimensions: 1 ⅛" x 2 ¼" face plate for standard installations.
  • Cover Dimensions: 2 ⅝" x 4 ⅜" covers with a 2 ⅝" handle projection for comfortable push/pull operation.
  • Multiple Mounting Positions: Can be installed in 6 different mounting positions, allowing adaptability across varied door configurations.
  • Stainless Steel Construction: Covers and paddles are made of stainless steel for long-term durability in demanding commercial environments.
  • Non-Handed Design: Non-handed configuration simplifies stocking and installation across multiple door openings.
  • Standard Hardware Included: Ships with a standard T-Strike and Plastic Dust Box; an optional ASA ANSI Strike is also available.
  • Specialty Options Available: Optional anti-microbial coating and optional lead lining are available for doors requiring lead lining protection.

Certifications & Compliance

  • UL-Listed for use on all fire doors
  • Meets ADA requirements

Technical Specifications

  • Subcategory: Cylindrical Locks
  • Product Group: Mechanical Locks
  • Product Subgroup: Bored Locksets
  • Product Type: Hospital Latches
  • Commercial/Residential: Commercial
  • Product Category: Mechanical Locks
  • Department: Door Hardware

Typical Applications

  • Hospitals and Healthcare Institutions
  • Public Washrooms
  • Commercial Office Buildings
  • Educational Facilities
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities

Why Cal-Royal HOS-PP30?

Cal-Royal hospital push/pull latches deliver professional-grade reliability with durable stainless steel covers and paddles built for demanding, high-traffic commercial environments. UL-listed for fire door use and ADA compliant, the HOS-PP30 is engineered to meet the practical needs of hospitals, public buildings, and washrooms where hygienic, hands-free door operation is essential.

Product Specs

Subcategory:
Cylindrical Locks
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Hospital Latches
Commercial/Residential:
Commercial
Product Model:
HOS-PP30
Product Category:
Mechanical Locks
Department:
Door Hardware

Cal-Royal HOS-PP30-32D – Frequently Asked Questions

1) Do I have to order a handed version of the Cal-Royal HOS-PP30 push/pull latch?
No handing to specify. The HOS-PP30 is non-handed, and it installs in 6 different mounting positions, so one part covers left and right hand openings and lets you set the paddle orientation on site. For a property manager stocking spares across a building, that means one SKU on the shelf instead of two.
2) Can a hospital push/pull latch be used on a fire rated door?
The Cal-Royal HOS-PP30 is UL-listed for use on all fire doors, and it meets ADA requirements. That combination is what makes it usable on rated corridor and washroom openings in healthcare and institutional buildings where the paddle also has to satisfy the no-tight-grasping rule.
3) What comes in the box with the Cal-Royal HOS-PP30, and what do I need to order separately?
Shipped standard: the stainless steel covers and paddles, a T-strike, and a plastic dust box. If your frame is prepped for an ASA/ANSI strike, order the optional ASA ANSI strike instead. Two other options are order-time only, not field additions: anti-microbial coating, and lead lining for openings that require it. Decide those before the order goes in.
4) Is the Cal-Royal HOS-PP30 a locking latch or just passage?
Passage only. The HOS-PP30 push/pull latch retracts the latch when you push or pull the paddle, with no key and no privacy function, which is the point on a hospital corridor or public washroom door where somebody has their hands full. If you need a hospital-style privacy function on the same kind of opening, the Schlage ALX44 is a Grade 2 non-keyed cylindrical hospital privacy lock.
5) What is the closest equivalent to the Cal-Royal HOS-PP30 hospital push/pull latch from another brand?
The Trimco 1562A Hospital Series push/pull latch is the nearest match. Like the HOS-PP30, it is a tubular hospital push/pull latch in passage function, so it operates hands-free with no keying and no locking cycle. Trimco lists the 1562A as heavy duty. The ABH 6000 Series push/pull hospital latch is the other close peer and is listed as ADA compliant, the same requirement the HOS-PP30 meets. All three are non-keyed paddle latches for the same kind of opening: washrooms, patient rooms, and corridor doors where hands are full.
6) The patient toilet room needs to lock. Can the Cal-Royal HOS-PP30 do that?
No. The HOS-PP30 is a passage latch, so the paddles retract the latch and nothing more, with no privacy or locking function. For a patient toilet or exam room that has to secure from inside, the Schlage ALX44 is a hospital privacy lock, Grade 2 cylindrical non-keyed, in medium duty. It uses a lever rather than paddles, so it is a different operating motion from the push/pull the HOS-PP30 gives you.
7) What other hospital push/pull latches are there besides Cal-Royal, and how do they differ?
Several, and they split by how they mount and how much they project. ABH's 6000 Series is a push/pull hospital latch with ADA compliance; the 6800 Series is the low profile version if projection is a problem, and the 6800Q adds a quiet operation with a round cover for patient rooms and night-quiet corridors. The ABH 6600 Series is the mortise lock version with a 2-3/4 inch backset. Trimco's 1562A is a tubular heavy duty passage push/pull. Kaba Ilco's 459 Series is a push/pull paddle. The Cal-Royal HOS-PP30 sits with the bored passage latches and is stainless steel covers and paddles.
8) Will a hospital push/pull latch hold up in a high traffic public washroom?
The covers and paddles on the HOS-PP30 are stainless steel, and it is a commercial-rated product, which is what you want on a washroom or corridor door taking hundreds of cycles a day and getting cleaned constantly. For infection-control areas, the anti-microbial coating is an order option on the same latch.
9) Can I get a hospital push/pull latch for an X-ray room door with lead lining?
Cal-Royal offers the HOS-PP30 with optional lead lining for doors that require lead lining protection, which is the imaging and radiology case. It has to be specified on the order, so flag it up front rather than trying to add it in the field.
10) Which hospital latch works on a fire-rated door if the room also has to be secured?
The HOS-PP30 is UL-listed for use on all fire doors, but it is passage only, so it cannot secure the room. Where a fire door has to latch and lock, the Schlage L9080BDC is a mortise storeroom lock, single cylinder non-deadbolt, heavy duty, for a 1 3/4 inch door, and the L9070BDC is the classroom-function version of the same mortise body, also heavy duty at 1 3/4 inches. Both are keyed cylinder locks operated by a lever, so they give up the hands-free push/pull operation the HOS-PP30 provides.
11) What finish does the Cal-Royal HOS-PP30 hospital latch come in?
US32D, satin stainless steel. That is the single model offered, HOS-PP30-32D, so there is no finish decision to make. US32D is the standard institutional finish and it will match satin stainless push plates, pulls and lever trim already on most healthcare and school openings.
12) For a high-traffic washroom door, should I specify the Cal-Royal HOS-PP30 or the Trimco 1562A?
Both are passage push/pull latches suited to a washroom, where hands-free entry is the point. The Trimco 1562A is a tubular hospital latch with levers down, listed as heavy duty. The HOS-PP30 uses stainless steel covers and paddles, is non-handed, and installs in 6 mounting positions, so the paddle can be oriented to the swing without stocking a second part. If the washroom door is fire rated, note that the HOS-PP30 is UL-listed for use on all fire doors.
