Camden CM-25/26CB Series Narrow Push Plate Switch, Handicap Symbol/Push To Open

Camden CM-25/26CB Series Narrow Push Plate Switch, Handicap Symbol/Push To Open

(No reviews yet) Write a Review

Model: CM-25/2
Selected Finish is
Selected Faceplate Graphic Options is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$77.00
$54.14
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Camden CM-25/26CB Series Narrow Push Plate Switch, Handicap Symbol/Push To Open

CM-25, CM-26CB, CM-35 and CM-35N Series all-active switches are heavy-duty, ADA-compliant door controls. CM-25 (1-5/8" x 4-1/2") and CM-26CB/CM-35 series (2" x 4-1/2") rectangular faceplates are stainless steel, aluminum or solid brass. The CM-25 is designed to mount directly on a metal door frame or narrow surface box. The CM-35 and CM-35N Series meets new OBC requirements for activation plate size and is designed for mounting on a single gang box.

Note: CM-35 and CM-25 Series push plate switches are not available with optional DPDT contact.

Architectural Finishes:
CM-25 Series switches with architectural finish
only available with /1, /2, /3, /4 graphic options

Contact Type: N/O SPST
Switch Type: Momentary
Contact Rating: 3 A @ 30 VDC
Temp Range: -40°F to 140°F (-40°C to +60°C)
Std. Finish: US32 / C32D
Dimensions:
CM-25,CM-26CB: 4-3/16" x 1-3/4" x 1-3/16"
(113mm x 44mm x 30mm)

Manufacturer Resources

DOWNLOAD

Product Specs

Subcategory:
Switches/Push Buttons
Warranty:
3 Year Limited
Wireless Communication:
No
Commercial/Residential:
Commercial
Product Type:
Push Plate
Electronic:
Yes
Product Group:
Electronic Access Controls
Product Subgroup:
Switches/Push Buttons
Product Dimension:
4-1/2" x 1-3/4"
Product Category:
Electronic Access Control
Department:
Door Hardware

Camden Door Controls CM-25/2 – Frequently Asked Questions

1) What switch contact and rating does the Camden CM-25/26CB push plate use, and can it drive a door operator relay?
It is a momentary, normally open SPST contact rated 3 A at 30 VDC. That is a dry momentary closure, so it signals a door operator, controller input or relay rather than switching the operator's load directly. Note the CM-25 and CM-35 series are not offered with the optional DPDT contact, so if you need a second set of contacts for a separate device you need to plan around that.
2) What size opening do I need to cut for the CM-25/CM-26CB push plate?
The CM-25 and CM-26CB switch body measures 4-3/16 x 1-3/4 x 1-3/16 inches (113mm x 44mm x 30mm), with a faceplate footprint of 4-1/2 by 1-3/4 inches. The 1-3/16 inch depth is what decides whether it will clear inside a frame or a narrow surface box.
3) I need a larger activation plate for an Ontario Building Code job. Is the CM-25 the right one?
No. The CM-35 and CM-35N Series is the one that meets the newer OBC requirement for activation plate size, on a 2 by 4-1/2 inch plate mounted to a single gang box. The CM-25 is the narrow 1-5/8 by 4-1/2 inch plate intended for frame or narrow surface box mounting.
4) Can a Camden CM-26CB push plate be installed outdoors or in an unheated area?
The operating temperature range runs from -40 F to 140 F (-40 C to +60 C), so exterior vestibules, parking garages and unheated loading areas are within spec. Contact rating is 3 A at 30 VDC on a momentary normally open contact.
5) Does the Camden narrow push plate come with the wheelchair symbol and Push to Open text?
Two graphics are offered: the wheelchair symbol alone, or the active wheelchair symbol paired with Push to Open text. Both are available in blue or in an architectural finish, so you pick graphic and finish when you order.
6) Is the Camden CM-25/26CB push plate wireless, or does it need to be hard wired?
Hard wired. There is no wireless option on this switch, so you run low voltage cable from the plate back to the operator or access control input. It is an electronic device carrying a normally open momentary contact rated 3 A at 30 VDC.
7) Is this Camden push plate switch suitable for high traffic commercial buildings?
It is a commercial-duty product. Camden lists the CM-25, CM-26CB, CM-35 and CM-35N all-active switches as heavy-duty, ADA-compliant door controls, with the whole plate face acting as the actuator rather than a small button.
8) What is the standard finish on the Camden CM-25 series switch, and what are the plates made of?
Standard finish is US32 / C32D, polished or satin stainless. Faceplates come in stainless steel, aluminum or solid brass. If you want an architectural finish on a CM-25, note it is only offered with the /1, /2, /3 and /4 graphic options.
