Color Keyed One-Hole Copper Cable Lug 350 kcmil 35kV Red Standard Barrel

Color Keyed One-Hole Copper Cable Lug 350 kcmil 35kV Red Standard Barrel

Professional copper cable termination for high-voltage electrical applications

The Color Keyed One-Hole Copper Cable Lug delivers reliable electrical connections for 350 kcmil cables in high-voltage applications up to 35kV. Featuring solid copper construction with red color coding for easy identification, this standard barrel lug provides secure termination with 1/2 inch stud compatibility for professional electrical installations.

Professional Features & Benefits

• 350 kcmil Cable Capacity: Accommodates large conductor sizes for high-current applications and power distribution systems.
• 35kV Voltage Rating: Engineered for high-voltage electrical systems with reliable insulation performance and safety margins.
• Copper Construction: Provides excellent conductivity and corrosion resistance for long-term electrical performance.
• Red Color Coding: Enables quick phase identification and reduces installation errors in complex electrical systems.
• 1/2 Inch Stud Size: Standard stud compatibility ensures versatile mounting options and secure mechanical connections.
• UL Listed (E9809): Meets rigorous safety standards for professional electrical installations and code compliance.
• Standard Barrel Design: Proven termination method provides reliable compression and optimal electrical contact.

Technical Specifications

• Brand Label: Color Keyed / Blackburn
• Cable Size: 350 kcmil
• Country Of Origin: Mexico (MX)
• Department: Electrical
• Effective Date: 19750324
• Idea Granular Category Code Igcc: 4532 >> Cable or wire lug
• Insulation Material: None
• Product Color: Red
• Product Material: Copper
• Product Type: Standard Barrel
• Standards: UL E9809
• Stud Size: 1/2 in
• Sub Brand Label: Color Keyed
• Voltage Rating: 35 kV

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• High-voltage power distribution systems
• Industrial electrical installations
• Commercial power infrastructure
• Utility substation connections
• Heavy-duty electrical equipment terminations
• Phase identification in complex electrical systems

Why Choose Color Keyed Quality?

Color Keyed cable lugs deliver professional-grade reliability with UL listing (E9809) ensuring code compliance and safety standards. The solid copper construction and standard barrel design provide long-term durability and optimal electrical performance for demanding high-voltage applications.
