Don-Jo 12-2-CW Wrap Around Plate 5-1/8" x 12" with Lever Prep for Cylinder Door Locks

Don-Jo 12-2-CW Wrap Around Plate 5-1/8" x 12" with Lever Prep for Cylinder Door Locks

(No reviews yet) Write a Review

Model: 12-S-2-CW
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$42.40
$23.50
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo 12-2-CW Wrap Around Plate 5-1/8" x 12" with Lever Prep for Cylinder Door Locks

The Don-Jo 12-2-CW is a commercial-grade wrap around plate measuring 5-1/8" wide by 12" tall, engineered for cylinder door locks with a 2-1/8" hole and lever prep configuration. Constructed from 22-gauge (.032) steel, this wrap around provides a clean, professional finish while reinforcing the lock area on 1-3/4" doors. With a 2-3/4" backset and latch prep indent, it is designed for straightforward integration with standard commercial door hardware setups.

Key Features

  • Precise Dimensions: Measures 5-1/8" wide by 12" tall, providing ample coverage for cylinder door lock installations on commercial doors.
  • Lever Prep Configuration: Features a lever prep hole layout designed for cylinder door locks with a 2-1/8" hole, ensuring compatibility with standard lever-style locksets.
  • Door & Backset Compatibility: Sized for 1-3/4" doors with a 2-3/4" backset, meeting common commercial door hardware standards.
  • Latch Prep Indent: Includes a latch prep indent for seamless integration with the door latch mechanism, reducing installation complexity.
  • Heavy-Gauge Steel Construction: Manufactured from 22-gauge (.032) steel for durable, long-lasting performance in commercial applications.
  • Multiple Finish Options: Available in 10B (613), PB (605), and S (630) finishes to coordinate with existing door hardware and architectural aesthetics.
  • Commercial-Grade Quality: Rated for commercial use, making it suitable for high-traffic environments requiring reliable door trim accessories.

Technical Specifications

  • Product Group: Door Trim and Accessories
  • Subcategory: Wrap Arounds
  • Product Subgroup: Filler Plates, Lock Adapters and Wrap Arounds
  • Product Type: Wrap Arounds
  • Commercial/Residential: Commercial
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Don-Jo 12-2-CW?

Don-Jo wrap around plates are built to commercial standards using 22-gauge (.032) steel construction, delivering the durability and precision fit that demanding door hardware applications require. The 12-2-CW's carefully engineered dimensions — 5-1/8" x 12" with lever prep, 2-3/4" backset, and latch prep indent — ensure a professional installation result on 1-3/4" commercial doors every time.

Manufacturer Resources

DON-JO Wrap-Around Plates

Product Specs

Product Group:
Door Trim and Accessories
Subcategory:
Wrap Arounds
Product Subgroup:
Filler Plates, Lock Adapters and Wrap Arounds
Product Type:
Wrap Arounds
Commercial/Residential:
Commercial
Handle Type:
Lever
Door Width:
1-3/4"
Product Model:
12 2 CW
Product Category:
Door Trim and Accessories
Backset (Distance):
2-3/4"
Department:
Door Hardware

Don-Jo 12-S-2-CW – Frequently Asked Questions

1) Will the Don-Jo 12-2-CW wrap around plate cover the chewed-up area around my lockset on a 1-3/4 inch commercial door?
The 12-2-CW is sized for 1-3/4 inch doors and covers a 5-1/8 by 12 inch area of the lock stile, wrapping the edge so damage on both faces of the door is hidden. It reinforces the lock area rather than replacing the lock, so the existing lever lockset goes back in through the plate. Prep is for a cylindrical lock with a 2-1/8 inch cross bore on a 2-3/4 inch backset, and there is a latch prep indent at the edge for the latch face.
2) My lock has a 2-3/8 inch backset. Can I still use the Don-Jo 12-2-CW?
No. The 12-2-CW is punched on a 2-3/4 inch backset, meaning the 2-1/8 inch lock hole sits 2-3/4 inches from the door edge. Two-and-three-eighths and 2-3/4 are the two standard cylindrical backsets, and the holes will not line up if you mix them. Measure from the door edge to the center of your existing knob or lever hole before ordering; if it comes in at 2-3/8, you need the 2-3/8 backset version of the wrap, not this one.
3) Will the 12-2-CW fit a 1-3/8 inch door?
No. The wrap is formed for 1-3/4 inch doors, and the bend at the edge is what sets that. On a thinner 1-3/8 inch door (common on older interior openings) the plate will stand off the face and will not sit flat. Confirm door thickness at the lock edge before you order.
4) Does the Don-Jo 12-2-CW work with a lever lockset or only a knob?
Lever prep. The 12-2-CW has the lever-style hole layout around the 2-1/8 inch cross bore, so a standard cylindrical leverset passes through it. A round knob rose will also clear the same 2-1/8 inch bore, but the plate's prep is cut for lever trim, which is the taller footprint of the two.
5) What is a wrap around plate and when do I use one instead of a flat scar plate?
A wrap around bends over the edge of the door and covers both faces at the lock, so it hides damage on the push and pull side and adds metal around the bore. A flat plate only covers one face. On a stripped or split cylindrical lock area, the wrap is what lets you keep the door instead of replacing it. The 12-2-CW does that job for a lever lock on a 1-3/4 inch door with a 2-3/4 inch backset.
6) How thick is the steel on the Don-Jo 12-2-CW, and will it hold up in a high traffic corridor?
22-gauge steel, .032 inch thick. That is a trim and repair gauge, not a security reinforcement plate, so it covers and stiffens the lock area and takes daily corridor abuse in offices, schools, healthcare and retail. If you are trying to stop a kick-in or defeat forced entry, this is the wrong part; you want a heavier latch protector or a security wrap.
7) Does the latch stay in place when I install the 12-2-CW, or do I have to pull the latch too?
The plate has a latch prep indent at the door edge, so it clears the existing latch face and the latch does not have to come out to make room for it. Practical sequence is to pull the lever trim, slip the wrap over the edge and align the 2-1/8 inch bore, then reinstall the lockset through the plate.
8) What finishes does the Don-Jo 12-2-CW wrap around come in, and can I match my existing lever hardware?
Three finishes: 10B oil rubbed bronze (613), PB polished brass (605), and S satin stainless (630). Satin stainless 630 is the usual match for commercial lever hardware in schools and offices, 605 for older brass openings, and 613 where the building runs dark bronze. Matching the plate to the lever rose is what keeps a repair from looking like a repair across a floor of doors.
