Don-Jo 93KV-CW Wrap Around Plate 5-1/2" x 12-3/4" for Best 93KV Locks

Don-Jo 93KV-CW Wrap Around Plate 5-1/2" x 12-3/4" for Best 93KV Locks

(No reviews yet) Write a Review

Model: 93KV-S-CW
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$151.38
$98.81
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo 93KV-CW Wrap Around Plate 5-1/2" x 12-3/4" for Best 93KV Locks

The Don-Jo 93KV-CW is a commercial-grade wrap around plate engineered specifically for use with Best 93KV locks, providing a clean, professional finish and reinforced door protection. Measuring 5-1/2" wide by 12-3/4" tall, this wrap around is constructed from 22-gauge (.032) steel and features a Satin Stainless Steel finish (630) for lasting durability. Designed for 1-3/4" doors with a 2-3/4" backset, it includes an electronic lock hole preparation and an indent latch prep, making it a versatile solution for commercial door hardware installations.

Key Features

  • Precise Dimensions: Measures 5-1/2" wide x 12-3/4" tall, sized to provide full coverage and a professional appearance on commercial doors.
  • Lock Compatibility: Specifically designed to work with Best 93KV locks, ensuring a precise fit and seamless integration with existing hardware.
  • Heavy-Gauge Construction: Fabricated from 22-gauge (.032) steel for robust, long-lasting performance in demanding commercial environments.
  • Door & Backset Compatibility: Engineered for 1-3/4" doors with a 2-3/4" backset for reliable, code-compliant installation.
  • Electronic Lock Hole Preparation: Pre-cut electronic lock hole accommodates electrified lock configurations for access control applications.
  • Indent Latch Prep: Includes an indent latch preparation for smooth, accurate latch alignment and operation.
  • Satin Stainless Steel Finish (630): Corrosion-resistant 630 finish delivers a clean, professional aesthetic suited to commercial interiors.

Technical Specifications

  • Subcategory: Wrap Arounds
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Filler Plates, Lock Adapters and Wrap Arounds
  • Product Type: Wrap Arounds
  • Commercial/Residential: Commercial
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties

Why Don-Jo 93KV-CW?

Don-Jo wrap around plates are built to commercial standards, combining 22-gauge (.032) steel construction with a durable 630 Satin Stainless Steel finish for reliable, long-term performance. The 93KV-CW is purpose-engineered for Best 93KV lock compatibility, with pre-cut electronic lock hole and indent latch prep that streamline installation and ensure a precise, professional result on 1-3/4" commercial doors.

Manufacturer Resources

DON-JO Wrap-Around Plates

Product Specs

Subcategory:
Wrap Arounds
Product Group:
Door Trim and Accessories
Product Subgroup:
Filler Plates, Lock Adapters and Wrap Arounds
Product Type:
Wrap Arounds
Commercial/Residential:
Commercial
Door Width:
1-3/4"
Product Model:
93KV CW
Product Category:
Door Trim and Accessories
Backset (Distance):
2-3/4"
Department:
Door Hardware

Don-Jo 93KV-S-CW – Frequently Asked Questions

1) What lock does the Don-Jo 93KV-CW wrap around plate line up with?
It is cut for Best 93KV locks. The prep includes an electronic lock hole and an indent latch prep, so it suits electrified 93KV configurations used on access control openings. If your lock is a different series or a different backset than 2-3/4 inches, the holes will not register and you need a wrap with matching prep.
2) How big is the Don-Jo 93KV-CW plate and will it cover damage around an existing lock cutout?
The plate measures 5-1/2 inches by 12-3/4 inches. That footprint wraps the lock area of the door and hides chewed-up edges, old filled holes, or scarred face material around a 93KV lock prep. Damage outside that 5-1/2 by 12-3/4 inch area stays exposed.
3) Can I use this wrap around plate to hide a lock swap on a damaged door instead of replacing the door?
That is the main reason property managers buy it. Rather than pulling a beat-up 1-3/4 inch door, the wrap folds over the lock edge and presents a clean face on both sides around the 93KV prep. With the electronic lock hole already cut, it also works when you are moving an opening from a mechanical to an electrified 93KV lock and the old holes need covering.
4) What is an indent latch prep on a wrap around plate and why does it matter?
The indent is a recess formed at the door edge so the latch face and faceplate sit down into the plate rather than on top of it. Without it, the added steel packs the latch out and throws off strike alignment. The 93KV-CW has that indent formed in, so the latch seats and the door closes to the existing strike.
5) Is 22-gauge steel heavy enough for a school or hospital corridor door?
The 93KV-CW is 22-gauge (.032) steel with a 630 satin stainless finish, and Don-Jo rates it commercial. That is the working gauge for wrap arounds used in offices, schools, healthcare, retail, and multi-tenant buildings. It reinforces and covers the lock area; it is not an armor plate for forced-entry resistance.
6) What finish does the Don-Jo 93KV-CW come in, and will it match other stainless hardware on the opening?
One finish only: satin stainless steel, BHMA 630. That is the standard commercial stainless finish, so it sits alongside 630 levers, hinges, and push plates without looking off. If your building is standardized on 626 satin chrome the tone will read slightly different in daylight.
