Don-Jo 258 CW Wrap Around Plate 4-1/4" x 12" for Double Lock Combination Locksets

Don-Jo 258 CW Wrap Around Plate 4-1/4" x 12" for Double Lock Combination Locksets

(No reviews yet) Write a Review

Model: 258-10B-CW
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$53.10
$29.74
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo 258 CW Wrap Around Plate 4-1/4" x 12" for Double Lock Combination Locksets

The Don-Jo 258 CW is a commercial-grade wrap around plate measuring 4-1/4" wide by 12" tall, engineered specifically for double lock combination locksets with 2-1/8" holes on 5-1/2" centers. Constructed from 22-gauge (.032) steel, this wrap around accommodates a 2-3/4" backset and is sized for 1-3/4" doors, featuring a double indent latch prep for a precise, professional fit. Available in a range of finishes to complement existing door hardware, the 258 CW delivers reliable reinforcement and a clean appearance in commercial door applications.

Key Features

  • Precise Dimensions: Measures 4-1/4" wide by 12" tall with a 5-1/2" center-to-center (CTC) spacing, designed to align perfectly with double lock combination lockset preparations.
  • Double Lock Combination Lockset Compatibility: Specifically designed for double lock combination locksets with two 2-1/8" holes on 5-1/2" centers for a secure, accurate fit.
  • Correct Backset and Door Sizing: Accommodates a 2-3/4" backset and is engineered for 1-3/4" door thickness, ensuring proper alignment and function.
  • Double Indent Latch Prep: Features a double indent latch preparation for a clean, professional installation that integrates seamlessly with compatible locksets.
  • 22-Gauge Steel Construction: Fabricated from 22-gauge (.032) steel for durable, long-lasting performance in commercial door hardware applications.
  • Multiple Finish Options: Available in 10B (613), AB (609), BZ (612), PB (605), and S (630) finishes to coordinate with a wide variety of door hardware styles.
  • Commercial-Grade Application: Rated for commercial use, making it suitable for demanding environments where reliability and appearance are essential.

Technical Specifications

  • Subcategory: Wrap Arounds
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Filler Plates, Lock Adapters and Wrap Arounds
  • Product Type: Wrap Arounds
  • Commercial/Residential: Commercial
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Don-Jo 258 CW?

Don-Jo wrap around plates are built to commercial standards, with the 258 CW crafted from 22-gauge (.032) steel to provide lasting reinforcement and a finished appearance around double lock combination locksets. Engineered with precise dimensional specifications — including 4-1/4" x 12" sizing, 5-1/2" CTC, and double indent latch prep — this plate ensures a professional, code-compliant installation on 1-3/4" doors in high-demand commercial environments.

Manufacturer Resources

DON-JO Wrap-Around Plates

Product Specs

Subcategory:
Wrap Arounds
Product Group:
Door Trim and Accessories
Product Subgroup:
Filler Plates, Lock Adapters and Wrap Arounds
Product Type:
Wrap Arounds
Commercial/Residential:
Commercial
Door Width:
1-3/4"
Cross Bore:
2-1/8"
Product Model:
258 CW
(CTC) Center-to-Center:
5-1/2"
Product Category:
Door Trim and Accessories
Backset (Distance):
2-3/4"
Department:
Door Hardware

Don-Jo 258-10B-CW – Frequently Asked Questions

1) Will the Don-Jo 258 CW wrap around plate fit a door prepped for a double lock combination lockset with two 2-1/8 inch holes?
That is the exact prep the 258 CW is punched for: two 2-1/8 inch bores on 5-1/2 inch centers, a 2-3/4 inch backset, and a double indent latch prep at the edge. Take two measurements before you order. Center of the knob bore to center of the deadbolt bore should be 5-1/2 inches, and center of either bore to the door edge should be 2-3/4 inches. If both check out on a 1-3/4 inch door, the plate goes on over the existing prep with no new holes in the door.
2) My door only has one 2-1/8 inch knob bore and no deadbolt. Can I use the 258 CW wrap around?
No. The 258 CW is a double lock plate, punched for two 2-1/8 inch holes on 5-1/2 inch centers. On a knob-only door the second cutout lands over solid door face and you are left looking at an open hole in the plate. For a single-bore opening, order a wrap around cut for one 2-1/8 inch hole at a 2-3/4 inch backset instead, and match the plate height to the damage you are covering.
3) Does the Don-Jo 258 CW fit a 1-3/8 inch door?
The 258 CW is sized for 1-3/4 inch doors. A wrap around is formed to a specific door thickness so it grips the edge and lies flat on both faces, so on a 1-3/8 inch door it sits loose and will not pull up tight. 1-3/4 inch is the standard commercial door thickness and 1-3/8 inch is the common older interior thickness, so measure the door edge first. If it comes back 1-3/8, you need a wrap around built for that thickness.
4) Will a 258 CW wrap around cover the gouges and old screw holes around the lock on a beat up apartment entry door?
The plate face measures 4-1/4 inches wide by 12 inches tall, so it covers a band that height running through both bores and the latch area, on the face and around the door edge. It is 22-gauge (.032) steel, which gives you a clean flat surface over splintered wood, filled kick-in damage, or the ghost holes left by a lock that was swapped out. Damage outside that 4-1/4 by 12 inch footprint stays visible, so measure the marked-up area before you settle on this size.
5) Should I use a wrap around plate or a filler plate on a door with a chewed up lock area?
It comes down to whether the holes stay in service. A wrap around like the 258 CW keeps the existing prep working: it has the two 2-1/8 inch bores at 5-1/2 inch centers and the latch cutout, so the lockset goes back through it and the steel covers the damage around it. A filler plate is the other job, closing a bore that is no longer used after a lock has been removed or relocated. If you are reinstalling a double lock combination set on that opening, the wrap around is the part you want.
6) Can I standardize on the Don-Jo 258 CW across every unit door in my building?
Only across the openings that share the same prep. Four things have to match: 1-3/4 inch door thickness, 2-3/4 inch backset, two 2-1/8 inch bores, and 5-1/2 inch center to center between them. Buildings that were re-keyed or re-locked in phases often have a mix of center spacings and backsets, so walk a sample of doors on each floor and measure before you commit to a bulk order. Any opening that measures differently needs a wrap around cut to its own spacing, not this one.
7) I need the wrap around to match the existing lever and deadbolt finish. What does the 258 CW come in?
Five finishes, and each carries its BHMA number so you can match what is already hanging on the door: 10B oil rubbed bronze (613), AB antique brass (609), BZ satin bronze (612), PB polished brass (605), and S satin stainless (630). If the building runs 630 satin stainless on its commercial hardware, that is the S finish. Check the number stamped inside the existing lock face or trim rather than judging by eye, since 605 and 609 read close together once brass has aged.
8) Do I have to take the lockset off the door to install a 258 CW wrap around?
Yes. The plate slips over the door edge and the two 2-1/8 inch bores pass through it, so the knob or lever and the deadbolt have to come off first, the plate goes on, then the lockset reinstalls through the plate. The latch faceplate area is handled by the double indent prep in the plate, so the latch seats back into the edge. Plan on the door being open and unsecured for the length of that swap.
9) Is 22-gauge steel heavy enough for a wrap around on a high traffic commercial door?
22-gauge works out to .032 inch of steel, and Don-Jo lists the 258 CW for commercial use. Understand what it is doing: it is a wear and cover surface over the lock area, taking the keys, rings, and knuckle marks that would otherwise land on the door itself, and hiding the damage already there. It is not a security reinforcement and it does not change how the lock resists force. For openings in offices, schools, healthcare, retail, and multi-tenant residential, that is what a wrap around is for.
