Don-Jo 8-CW 8 CW Wrap Around Plate 4-1/4" x 4-1/2" with 2-3/4" Backset for 1-3/4" Doors

Don-Jo 8-CW 8 CW Wrap Around Plate 4-1/4" x 4-1/2" with 2-3/4" Backset for 1-3/4" Doors

(No reviews yet) Write a Review

Model: 8-S-CW
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$21.46
$18.35
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo 8 CW Wrap Around Plate 4-1/4" x 4-1/2" with 2-3/4" Backset for 1-3/4" Doors

The Don-Jo 8 CW is a commercial-grade wrap around plate measuring 4-1/4" wide by 4-1/2" tall, engineered for deadbolt applications requiring a 1-1/2" hole and a 2-3/4" backset on 1-3/4" doors. Constructed from 22-gauge (.032) steel, this wrap around provides a clean, professional finish while reinforcing the door around the lock prep area. It features a latch prep indent and is available in multiple finishes including 10B (613), AB (609), BZ (612), PB (605), and S (630) to complement a wide range of door hardware configurations.

Key Features

  • Precise Dimensions: Measures 4-1/4" wide by 4-1/2" tall, sized to cover and reinforce the lock prep area on standard commercial doors.
  • Deadbolt Compatibility: Designed specifically for deadbolts with a 1-1/2" hole, ensuring a proper fit with common deadbolt hardware.
  • Correct Backset and Door Size: Configured for a 2-3/4" backset on 1-3/4" door thickness for accurate, code-compliant installation.
  • Heavy-Gauge Steel Construction: Fabricated from 22-gauge (.032) steel for durable, long-lasting performance in commercial environments.
  • Latch Prep Indent: Includes a latch prep indent for seamless integration with existing door prep and hardware.
  • Multiple Finish Options: Available in 10B (613), AB (609), BZ (612), PB (605), and S (630) finishes to coordinate with surrounding door hardware.
  • Display Package Option: Also available in display packaging — when ordering, replace "CW" with "V" after the item number for the display-packaged version.

Technical Specifications

  • Subcategory: Wrap Arounds
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Filler Plates, Lock Adapters and Wrap Arounds
  • Product Type: Wrap Arounds
  • Commercial/Residential: Commercial
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Retail Establishments
  • Educational Facilities
  • Healthcare Institutions
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities

Why Don-Jo 8 CW?

Don-Jo wrap around plates are built to commercial standards, with 22-gauge (.032) steel construction that delivers reliable reinforcement and a finished appearance around deadbolt installations. The 8 CW is precisely dimensioned at 4-1/4" x 4-1/2" with a 2-3/4" backset configuration, making it a dependable solution for professional door hardware installations where fit, finish, and durability are essential.

Manufacturer Resources

DON-JO Wrap-Around Plates

Product Specs

Subcategory:
Wrap Arounds
Product Group:
Door Trim and Accessories
Product Subgroup:
Filler Plates, Lock Adapters and Wrap Arounds
Product Type:
Wrap Arounds
Commercial/Residential:
Commercial
Door Width:
1-3/4"
Cross Bore:
1-1/2"
Product Model:
8 CW
Product Category:
Door Trim and Accessories
Backset (Distance):
2-3/4"
Department:
Door Hardware

Don-Jo 8-S-CW – Frequently Asked Questions

1) Will the Don-Jo 8 CW wrap around plate fit my door if I have a 2-3/8 inch backset deadbolt?
No. The 8 CW is bored for a 2-3/4 inch backset, so the hole in the plate will not line up with a deadbolt set at 2-3/8 inches. The two common residential and commercial backsets are 2-3/8 and 2-3/4 inches, and they are not interchangeable on a wrap plate. Measure from the door edge to the center of the deadbolt hole before ordering; if that measurement comes to 2-3/8 inches you need the 2-3/8 backset version of the wrap, not this one.
2) What size deadbolt hole does the Don-Jo 8 CW wrap plate cover?
The cross bore on the 8 CW is 1-1/2 inches, which is the standard deadbolt bore. It slips over the existing 1-1/2 inch hole and the deadbolt reinstalls through the plate. If your door was bored 2-1/8 inches for a cylindrical lockset rather than a deadbolt, this is the wrong wrap plate for that opening.
3) How do I hide the damage around a deadbolt on a metal door without replacing the door?
A wrap around plate is the usual repair. The Don-Jo 8 CW is a 22-gauge (.032) steel wrap that folds over the door edge and covers both faces around the lock prep, hiding torn or oversized prep and stiffening the area at the same time. It measures 4-1/4 inches wide by 4-1/2 inches tall, so it covers a band around the bore rather than the full stile. Damage wider than that footprint needs a larger wrap or a door edge filler, not this one.
4) Is the Don-Jo 8 CW a deadbolt wrap or a lockset wrap?
Deadbolt. The 8 CW is prepped with a single 1-1/2 inch bore at a 2-3/4 inch backset, so it reinforces a deadbolt only. It has no second bore for a knob or lever, so on a door with both a lockset and a deadbolt this plate covers the deadbolt position by itself. For an opening where you want one plate spanning both a lockset and a deadbolt, you need a taller combination wrap with two holes.
5) What finishes does the Don-Jo 8 CW wrap around plate come in, and which one matches a satin chrome lockset?
Five finishes: 10B oil rubbed bronze, AB antique brass, BZ satin bronze, PB polished brass, and S satin stainless. For a satin chrome or brushed nickel lockset, S (630) satin stainless is the closest match and is the standard commercial choice. PB (605) polished brass pairs with bright brass hardware, and 10B (613) with dark bronze exit and lever trim.
6) Does the 8 CW wrap plate clear the latch on a door that also has a knob or lever?
There is a latch prep indent formed into the plate, so it clears existing latch prep on the edge of the door rather than binding against it. That matters on a door where the deadbolt sits close to the lockset latch. The wrap wraps the edge, so anything projecting from that edge has to be accounted for, and this one accounts for the latch.
7) Can I standardize one wrap around plate across all the deadbolted doors in my building?
Only across doors that share the same three numbers: 1-3/4 inch thickness, 1-1/2 inch deadbolt bore, and 2-3/4 inch backset. Wrap arounds are not adjustable, so a mixed building often needs two or three part numbers. Walk the doors and record backset and thickness first; the 8 CW covers the 1-3/4 inch, 2-3/4 inch backset group, and it comes in five finishes so you can still match different hardware suites within that group.
8) Is 22-gauge steel heavy enough for a wrap around plate on a school or apartment entry?
22-gauge (.032) steel is what Don-Jo builds this commercial wrap from, and it is a cosmetic and reinforcing cover rather than a security plate. It stiffens the area around the bore and hides prep damage on high-traffic openings in offices, schools, healthcare and multi-tenant buildings. If the door has been forced and the lock edge itself is deformed, a wrap plate dresses it but does not restore the door edge, and the door or a latch protector is the real fix.
9) How do I order the Don-Jo 8 wrap plate in retail display packaging?
Substitute V for CW after the item number. The 8 CW is the bulk commercial pack; the display packaged version of the same plate uses the V suffix. The plate itself is unchanged, only the packaging.
