Product Summary
The E-Plex 2000 Series provides exterior access by combination, while allowing free egress. This electronic keypad lock eliminates problems and costs associated with issuing, controlling, and collecting keys and cards, has up to 100 access codes and is programmed via the keypad or with optional Microsoft Excel-based software.
Product Details
No Wires: Requires no wiring to or through the door—eliminates risk of damage from pinched wires that can result in costly callbacks
Locking Device Options:
- Cylindrical: Cylindrical latch with 3-hour UL/ULC fire rating
- Rim Exit Device: Compatible with most leading brands of Exit Devices (Exit Device and mounting hardware not included)
- American Standard Mortise: With 1¼" (32 mm) face plate; with and without deadbolt, auto deadbolt also available
Number of Codes: Multiple Users—100 Codes
Handing: Non-handed; pre-assembled for left-hand door installations—easily changed in the field
Audit Trail: The most recent 1,000 events are recorded in memory, including the use of mechanical key override. Software is required to view Audit Events.
Programming: Lock is easily programmed via keypad without removing lock from the door or with optional Microsoft Excel-based software
Key Override (Optional):
- Optional Key-in-Lever cylinder in Schlage "C" Keyway with black cap
- Small format—Best and equivalent (6 or 7-pin length)
Operation Modes:
- PIN access
- Passage—can be toggled on/off or can be pre-programmed to re-lock after a certain number of hours
- Lockout
Authority Levels: Five different levels allow who has access to specific lock functions, including:
Master Level— performs all set-up and programming functions
Manager Level— administers common programming functions
Access User Level— entry granted with valid PIN
Service Level— codes for single event or single day access, programmable in advance
Maintenance Level— no access is granted, information can be uploaded/downloaded to/from the lock
User Parameters:
- User Parameters: Code length—adjustable to accept 4 to 8 digits
- Anti-tamper lockout—adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds
- Re-lock time—adjustable from 2 to 20 seconds
Exit Device Compatibility: Find a list of compatible exit devices in the Electronic Lock price book
• Arrow S1250
• Arrow S3800
• Corbin Russwin 5200/5200A
• Detex 10/F10
• Dorma 9300/9300F
• Monarch 18R/F-18R
• Precision 21/FL21
• Sargent 2828
• Sargent 3828
• Sargent 8800
• Sargent 8888
• Von Duprin 22/22F
• Von Duprin 98/98F
• Von Duprin 99/99F
• Yale 7100
Compatibility is subject to change if modifications are made by Exit Device manufacturers.
Technical Details
Construction: Heavy-duty commercial Grade 1 lockset, solid cast exterior housing, solid cast levers, cylindrical drive wear tested for extensive use in indoor and outdoor applications
Handing: Non-handed, pre-assembled for left-hand door installation—easily changed in the field
Backset:
- Cylindrical: 2¾" (70 mm) backset, 2⅜" (60 mm) backset
- Mortise: 2¾" (70 mm) backset
- Exit Trim Model: Varies by Exit Device
Latches:
- Cylindrical Models: ½" (13 mm) throw latch, ¾" (19 mm) throw latch (optional)
- Mortise Models: ¾" (19 mm) latch, 1" (25 mm) deadbolt (optional)
Strikes: Cylindrical locks packaged standard with both ANSI A115.3 "T" Strike and A115.2 ASA Strike
Minimum Stile Required: 5" (127 mm)
Key-in-Lever Cylinder: 1539 6-pin cylinder—Schlage "C" Keyway
Interchangeable Core: Small format—Best and equivalent (6 or 7-pin length); cylinder not included
Door Preparation:
- Cylindrical and Exit Trim—ASA 161 (easily installs on door preparation with three additional through bore holes; wood or metal doors)
- Mortise—ASA 86 door preparation with three additional through bore holes
Door Thickness:
- Cylindrical Model: 1⅜" (35 mm) to 2½" (64 mm); pre-assembled to accommodate doors 1⅝" (41 mm) to 2" (50 mm)
- Exit Trim and Mortise Models: 1¾" (44 mm) to 2¼" (57 mm); pre-assembled to accommodate doors 1¾" (44 mm) to 2⅛" (54 mm)
Accessibility Standard: Americans with Disabilities Act (ADA)
Fire Rating: UL 10C fire rated
Durability: ANSI/BHMA Grade 1 Certified (A156.25, A156.2, A156.13, A156.3)
Environmental: Indoor/Outdoor approved; -31 °F (-35 °C) to 151 °F (66 °C)
Warranty: 3-year warranty from date of installation; built-in warranty counter in lock memory
Standard Finishes:
- Satin Chrome 26D (626) housings and levers
Optional Finishes:
- Satin Brass 04 (606) housings and levers
- Dark Bronze 744 (10B) housings and levers
DOWNLOADS
Manufacturer Resources
Product Specs
- Product Group:
- Mechanical Locks
- Series:
- E-Plex 2000 Series
- Product Type:
- Mortise Locks
- Warranty:
- 3 Year
- Product Subgroup:
- Mortise Locks and Trim
- Subcategory:
- Push Buttons Locks
- Stile Width:
- 5"
- Commercial/Residential:
- Commercial
- Cylinder and Keyways:
- Schlage C keyway standard for XS key override option
- Electronic:
- Yes
- Stile Type:
- Wide Stile
- Lock Type:
- Mortise
- Product Attribute:
- Electronic Locks
- Door Hand Direction:
- Field Reversible
- Product Category:
- Electronic Locks
- Product Substrate:
- Brass or Bronze
- Department:
- Door Hardware
Dormakaba E2066-XS-LL-626-41 – Frequently Asked Questions
1) What is the difference between the E-Plex 2066 no deadbolt, deadbolt, and auto deadbolt versions?
Three mortise functions are orderable, all with the 1-1/4 inch faceplate. The plain version latches only. The deadbolt version adds a 1 inch (25 mm) deadbolt that someone throws deliberately. The auto deadbolt version throws that bolt on its own each time the door closes, so the opening secures without anyone remembering to lock it. Pick the auto deadbolt for an exterior or after-hours door where you cannot rely on the last person out; pick latch only where the door is in constant traffic and a projecting bolt is just something else to jam.
2) What key override choices do I need to pick when ordering an E-Plex 2066, and is the cylinder included?
Three override options, and this is the one decision you cannot change later, because the lever preps are not interchangeable between them. Option XS ships with a Kaba key-in-lever cylinder in the Schlage C keyway already included, a 1539 6-pin cylinder with a black cap. Option B takes a small format interchangeable core, BEST and equivalents in 6 or 7-pin length, and the core is not included, so a locksmith keying the building to an existing SFIC system supplies it. The None option is a solid lever with no override at all, which is the choice where you do not want a mechanical bypass on the opening.
3) My aluminum storefront door has a narrow stile. What keypad lock goes there instead of the E-Plex 2066?
The E-Plex 2066 is a wide stile lock and needs a minimum stile of 5 inches (127 mm), so a narrow stile aluminum door will not take it. For that opening, the Alarm Lock DL1300NW is a Trilogy Networx wireless electronic mortise lock with keypad made for Adams Rite deadlatches, which is the latch most narrow stile aluminum doors already carry. On an all-glass door with no stile at all, the Kaba Ilco BR Series is a glass door bottom rail lock. Confirm the existing deadlatch or rail prep before ordering either one.
4) Which keypad mortise locks are approved for an exterior door in a cold climate?
The E-Plex 2066 is indoor/outdoor approved and rated from -31 degrees F (-35 degrees C) to 151 degrees F (66 degrees C), with a solid cast exterior housing, solid cast levers, and a drive wear tested for extensive indoor and outdoor use. The Alarm Lock DL2700CR Trilogy T2 is an electronic mortise lock with classroom function and weatherproof design, Grade 1, for doors 1-5/8 inch to 1-7/8 inch thick. On an outside door also weigh the key override choice: the E-Plex 2066 takes a Kaba cylinder in the Schlage C keyway, small format BEST and equivalent cores, or a solid lever with no override.
5) What mortise lock should I use instead of the E-Plex 2066 if the door has to tie into an access control system?
The E-Plex 2066 is a standalone lock that requires no wiring to or through the door; it is programmed at the keypad or with optional Microsoft Excel-based software, and the last 1,000 events are read out of memory with software. For a head-end tie-in, the BEST 45HW is a heavy duty wired electromechanical mortise lock with 12V/24V operation, the Command Access ML190 is a heavy-duty motorized mortise lock with field selectable EL/EU operation on 24VDC in storeroom function, and the Schlage L9092EU with 03A trim is a heavy duty electric lock/unlock outside lever mortise lock, keyed outside, with request to exit and 12/24VDC. Wireless options include the Alarm Lock DL1300NW Trilogy Networx and the Schlage LEMD-GRW ENGAGE Series.
6) What is the closest equivalent to the Dormakaba E-Plex 2066 if I need a standalone keypad mortise lock with mechanical key override?
Two peers sit closest. The BEST 45HZ EZ Series is an electronic keypad mortise lock with key override function, and the Accentra NTM623-NR is a Grade 1 nexTouch Generation 3 mortise lock with a capacitive touchscreen keypad, no deadbolt, and cylinder override. The E-Plex 2066 uses mechanical pushbuttons rather than a touchscreen, holds up to 100 access codes, and is ordered with the key override you want: XS gives a key-in-lever Kaba cylinder in the Schlage C keyway, B accepts small format BEST and equivalent cores in 6 or 7-pin length with the cylinder not included, or a solid lever with no override at all. The E-Plex 2066 is also ordered with no deadbolt, a deadbolt, or an auto deadbolt behind the 1-1/4 inch faceplate.
7) The drawing calls for classroom function on a mortise lock. Does the E-Plex 2066 meet that, or is there a better match?
The E-Plex 2066 operates in PIN access, passage that toggles on and off or re-locks after a set number of hours, and lockout. Where a spec names classroom function outright, the Alarm Lock DL2700CR Trilogy T2 and DL3500CR Trilogy are Grade 1 electronic mortise locks with classroom function, the TownSteel FME-2000 is a Grade 1 heavy duty classroom mortise lockset with RFID, and the TownSteel FME-4000 is an electronic intruder classroom mortise lockset with RFID. For a keyed mechanical classroom body, the Corbin Russwin ML2003 is a Grade 1 mortise classroom lockset for 1-3/4 inch doors and the Cal-Royal NM8070 is a heavy duty Grade 1 classroom mortise lockset with auxiliary deadlatch.
8) I want cards or fobs instead of a PIN. What replaces the E-Plex 2066 keypad?
The E-Plex 2066 grants access by combination entered on the keypad, with an optional mechanical key override. If the credential has to be a card, fob, or phone, the TownSteel FME-2000 is a Grade 1 heavy duty mortise lockset with RFID for 1-3/4 inch doors, the Schlage LEMD-GRW is a Grade 1 ENGAGE Series wireless mortise lock with a 125 kHz proximity reader and mobile-enabled deadbolt with LED on Greenwich trim, and the Schlage LEBMB-ADD is a Grade 2 mobile-enabled mortise lock with push button and LED. Note handing when you order: the LEMD-GRW is a right hand lock, while the E-Plex 2066 is non-handed and pre-assembled for left hand doors, changed in the field.
9) The spec says Grade 1 electronic mortise lock. Which keypad locks carry that certification?
The E-Plex 2066 is ANSI/BHMA Grade 1 certified to A156.25, A156.2, A156.13, and A156.3, is UL 10C fire rated, and meets the Americans with Disabilities Act accessibility standard. Among the electronic mortise peers, the Alarm Lock DL2700CR, DL3500CR, and DL4500 are Grade 1, the Schlage CO-100 standalone electronic mortise lock with keypad reader is Grade 1 heavy duty in privacy function for 1-3/4 inch doors, the TownSteel FME-2000 and FME-4000 are Grade 1 heavy duty, and the Schlage LEMD-GRW is Grade 1 with a 3-hour fire rating. The Schlage LEBMB-ADD is Grade 2, so it will not answer a Grade 1 line item.
10) Does the E-Plex 2066 need to be wired to the door or tied into an access control panel?
Nothing gets wired. The E-Plex 2000 needs no wiring to or through the door, which takes door cord and pinched wire callbacks off the table entirely. Programming happens at the keypad itself without pulling the lock off the door, or through the optional Microsoft Excel based software. That makes it a standalone opening: no panel, no reader run, no head-end. If the door has to report to a system in real time, this is the wrong tool and a wired or networked lock is what you want.
11) How many user codes does the E-Plex 2066 hold and does it keep a record of who came through?
Up to 100 access codes, with codes set to any length from 4 to 8 digits. The lock stores the most recent 1,000 events in memory, including any use of the mechanical key override, and the optional software is what reads those events back. Five authority levels sort out who can do what: Master for all setup and programming, Manager for routine programming, Access User for entry only, Service for single event or single day codes you can set in advance for a vendor, and Maintenance, which grants no entry but can move data to and from the lock.
12) Is the E-Plex 2066 Grade 1 and will it pass on a fire rated opening?
It is ANSI/BHMA Grade 1 certified against A156.25, A156.2, A156.13 and A156.3, and it is UL 10C fire rated. The lever operation meets the Americans with Disabilities Act accessibility standard. For a facilities or institutional spec that calls out Grade 1 mortise hardware with a keypad and no wiring, those four A156 certifications are the ones to cite on the submittal.
13) Can I leave a door on an E-Plex 2066 unlocked during business hours?
Yes, that is what passage mode is for. Passage can be toggled on and off at the keypad, or pre-programmed to re-lock by itself after a set number of hours, so a front door left open at 8 am secures at close whether or not anyone comes back to it. There is also a lockout mode when you need to shut an opening down entirely. On normal PIN entry, the re-lock delay after a valid code is adjustable from 2 to 20 seconds, and the anti-tamper lockout can be set to trip after 3 to 9 invalid attempts for a period of 0 to 90 seconds.
14) Is there a mortise lock like the E-Plex 2066 that uses cards or fobs instead of a PIN pad?
The E-Plex 2000 is PIN entry only, with an optional mechanical key override. For credentials instead of codes, TownSteel's FME-2000 Series is a Grade 1 heavy duty classroom mortise lockset with RFID, and the FME-4000 Series is the electronic intruder classroom version with RFID. The Schlage LEMD-GRW carries a 125kHz proximity reader and is mobile enabled. If you want a keypad but a touchscreen rather than pushbuttons, the Accentra NTM623-NR nexTouch Generation 3 mortise lock uses a capacitive touchscreen and comes with cylinder override, no deadbolt.
15) Will an E-Plex 2066 mount to my Von Duprin exit device?
No. The 2066 is the mortise configuration, and it goes into an ASA 86 mortise pocket, not onto an exit device. Within the E-Plex 2000 family the rim exit device trim is the model that mounts to exit devices, and dormakaba lists it against Von Duprin 22/22F, 98/98F and 99/99F, Sargent 2828, 3828, 8800 and 8888, Detex 10/F10, Precision 21/FL21, Corbin Russwin 5200/5200A, Arrow S1250 and S3800, Monarch 18R/F-18R and Yale 7100. The exit device and its mounting hardware are separate from the lock either way.
16) If I do not need the keypad, what mechanical mortise lock covers the same door?
Keyed mechanical Grade 1 mortise locksets that suit the same commercial opening include the Accentra 8805FL, a Grade 1 storeroom mortise lock from the 8800 Series with an Arcadia lever; the Cal-Royal NM8080, a heavy duty Grade 1 storeroom mortise lockset with an interchangeable core option for 1-3/4 inch doors; and the Sargent 7925, a Grade 1 heavy duty dormitory exit function mortise lock with rose trim and a single cylinder deadbolt. The E-Plex 2066 covers the same Grade 1 duty level while granting entry by combination with free egress, which removes the work of issuing, controlling, and collecting keys and cards across a fleet of doors.
17) Behavioral health room needs anti-ligature hardware. What goes on that door instead of the E-Plex 2066?
The E-Plex 2066 has solid cast levers and meets the Americans with Disabilities Act accessibility standard, but for a ligature-resistant requirement the peers built for it are the TownSteel MRX-L-01, a Grade 1 heavy duty anti-ligature lever mortise lockset in passage function for 1-3/4 inch doors; the TownSteel MRX-A-01, a satin stainless steel ligature resistant arch trim mortise lockset, also Grade 1 heavy duty passage; and the Marks USA 5PDN, a Grade 1 hospital passage mortise push/pull paddleset that is ligature resistant, ADA compliant, and satin stainless steel. All three are passage function, so plan code entry elsewhere on the suite if a room needs it.
18) We need lockdown capability on a school door. How does the E-Plex 2066 lockout mode compare to an intruder function lock?
The E-Plex 2066 has a lockout mode that blocks code entry, backed by five authority levels running from Master and Manager down to Service and Maintenance, plus an anti-tamper lockout adjustable from 3 to 9 invalid attempts holding for 0 to 90 seconds. Where the spec calls for a dedicated intruder function, the BEST 45HCAINL is a heavy duty mortise lockbody with intruder function, and the TownSteel FME-4000 is a Grade 1 heavy duty electronic intruder classroom mortise lockset with RFID for 1-3/4 inch doors. The BEST 45HCAC is a heavy duty public entrance function lockbody with field reversible operation if the corridor side needs a different behavior.
19) What finishes does the Dormakaba E-Plex 2066 come in, and can I match the ones already in my building?
Three: Satin Chrome 626 (26D) as the standard, with Satin Brass 606 (04) and Dark Bronze as the optional finishes, applied to both the housing and the levers. Each of the three is orderable with every function and every key override choice, so a building standardizing on Dark Bronze can run auto deadbolt on the exterior doors and latch only inside without a finish mismatch.
20) The opening only needs free passage, no code. What mortise lock covers that instead of the E-Plex 2066?
The E-Plex 2066 does have a passage mode that toggles on and off or can be pre-programmed to re-lock after a set number of hours, so a door that swings free part of the day still suits it. For an opening that never needs to lock, the Falcon MA101 is a Grade 1 heavy-duty mortise passage lock with field reversible operation and a fire rating, the Schlage PM010 is a Grade 1 non-keyed passage latch mortise lock for 1-3/4 inch doors, and the Hager 3810S and 3810E are Grade 1 passage mortise locks on a 2-3/4 inch backset for doors 1-3/4 inch to 2-1/2 inch, the 3810S with rose and the 3810E with escutcheon.
