B-Line Eaton series panels and...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$409.83
B-Line Eaton series panels and panel accessories, 1, White powder coated, Steel, Panels and panel accessories, Fits 30" X 16" enclosures, flanged pa

B-Line Eaton series panels and panel accessories, 1, White powder coated, Steel, Panels and panel accessories, Fits 30" X 16" enclosures, flanged pa

(No reviews yet) Write a Review

Model: AW3016P
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$409.83
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series panels and panel accessories, NEMA 1, White powder coated, Steel, Panels and panel accessories, Fits 30" X 16" enclosures, NEMA flanged panels, 12 gauge

Manufacturer Resources

Product Specs

Certifications:
UL Listed
Degree Of Protection:
NEMA 1
Finish Color:
White powder coated
Product Category:
Panels & panel accessories
Product Height:
27 in
Product Length Depth:
12.875 in
Product Weight:
11.098 lb
Product Width:
12.875 in
Special Features:
Fits 30" X 16" enclosures
Department:
Electrical
Product Style:
Galvanized panel
Product Material:
Steel

B-LINE AW3016P – Frequently Asked Questions

1) Will the B-Line AW3016P panel fit a 30 x 16 inch enclosure?
That is exactly what the AW3016P is sized for. It is a flanged back panel for 30 inch by 16 inch B-Line enclosures. If your box is a different size, order the panel matched to that enclosure instead, since the mounting studs inside the box are on fixed centers and an undersized or oversized panel will not land on them.
2) Is this B-Line panel suitable for an outdoor or washdown enclosure?
No. The AW3016P is a NEMA 1 rated panel, which is indoor general purpose only, intended to guard against incidental contact with enclosed equipment and falling dirt. For wet, outdoor, or washdown locations you need a panel matched to a NEMA 3R, 4, or 4X enclosure.
3) What is the difference between a flanged panel and a flat back panel for an electrical enclosure?
A flanged panel like the AW3016P has formed edges that add stiffness and stand the mounting face off the back wall of the box, which gives you room to run wire behind the plate and keeps the panel rigid under load. A flat plate sits tight against the studs and is simpler, but flexes more with heavy components on it.
4) Does the B-Line AW3016P come painted or bare metal?
It ships white powder coated. The white face makes wire labels and device markings easier to read inside the box, and the coating resists corrosion better than an untreated plate in a dry indoor environment.
