B-Line Eaton series panels and...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,947.60
B-Line Eaton series panels and panel accessories, 1, White powder coated, Steel, Panels and panel accessories, Fits 48" X 48" enclosures, flanged pa

B-Line Eaton series panels and panel accessories, 1, White powder coated, Steel, Panels and panel accessories, Fits 48" X 48" enclosures, flanged pa

(No reviews yet) Write a Review

Model: AW4848P
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,947.60
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series panels and panel accessories, NEMA 1, White powder coated, Steel, Panels and panel accessories, Fits 48" X 48" enclosures, NEMA flanged panels, 12 gauge

Manufacturer Resources

Product Specs

Certifications:
CSA C22.2.
Degree Of Protection:
NEMA 1
Finish Color:
White powder coated
Product Category:
Panels & panel accessories
Product Height:
44.87 in
Product Length Depth:
44.875 in
Product Weight:
59.326 lb
Product Width:
44.875 in
Special Features:
Fits 48" X 48" enclosures
Department:
Electrical
Product Style:
Panel
Product Material:
Steel
Product Length:
44.875 in

B-LINE AW4848P – Frequently Asked Questions

1) Will the B-Line AW4848P back panel fit my 48 x 48 enclosure?
Yes. The Eaton B-Line AW4848P is built for 48 inch by 48 inch enclosures. The panel itself measures 44.875 inches wide by 44.87 inches high, which is the usable mounting area you get inside a 48 x 48 box once the panel sits on the mounting studs.
2) Is this B-Line panel rated for outdoor or washdown enclosures?
No. The AW4848P is a NEMA 1 panel, which is indoor, general purpose use. If you are building up an outdoor rain-tight enclosure or a washdown area, you need a panel and enclosure combination rated for that environment, not a NEMA 1 assembly.
3) I need a replacement sub-panel for an existing 48 x 48 enclosure. Is AW4848P the right part number?
AW4848P is the Eaton B-Line part number for the flanged steel panel sized to 48 inch by 48 inch enclosures, 44.875 inches square, white powder coated. Measure your existing panel across the flat before ordering; if yours is a plain flat plate rather than flanged, the mounting stud pattern may not match.
4) Is the AW4848P a flat back panel or a flanged panel?
It is a NEMA flanged panel, 12 gauge steel. The flanged edge stiffens the plate so heavy gear mounted on a 44-7/8 inch square field does not oil-can or sag between mounting points. If your drawing calls for a plain flat sub-panel, the flange is a different profile and you should confirm the spec before ordering.
5) Does the AW4848P carry any third-party certification for a Canadian job?
The panel is certified to CSA C22.2, so it can be specified on work where Canadian Standards Association compliance is called out. It is a NEMA 1, indoor general purpose rating.
6) What is the finish on the B-Line AW4848P sub-panel, and do I need to paint it?
It ships white powder coated over steel, so there is no field painting required. White is the standard interior finish for sub-panels because it reflects light inside the enclosure and makes wire and terminal marking easy to read during troubleshooting.
How fast can I get the B-LINE AW4848P delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the B-LINE AW4848P come with a warranty?
Absolutely. The B-LINE AW4848P is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the B-LINE AW4848P?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
