B-Line N223SS6 Eaton series st...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$84.87
$46.29
B-Line N223SS6 Eaton series strut channel, nuts, all threaded rod, Steel, Channel nuts, Nut without spring, Stainless steel type 316, 250 lbs pull out strength, 450 lbs slip strength, 5/16"-18 thread size

B-Line N223SS6 Eaton series strut channel, nuts, all threaded rod, Steel, Channel nuts, Nut without spring, Stainless steel type 316, 250 lbs pull out strength, 450 lbs slip strength, 5/16"-18 thread size

(No reviews yet) Write a Review

Model: N223SS6
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$84.87
$46.29
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series strut channel, nuts, all threaded rod, Steel, Channel nuts, Nut without spring, Stainless steel type 316, 250 lbs pull out strength, 450 lbs slip strength, 5/16"-18 thread size

Manufacturer Resources

Product Specs

Bolt Thread Rod Size:
5/16"-18
Certifications:
Not Applicable
Load Rating Pull Out Strength:
250 lbs
Load Rating Slip Strength:
450 lbs
Product Category:
Channel nuts
Product Height:
.85 in
Product Length Depth:
1.75 in
Product Weight:
.1 lb
Product Width:
1.375 in
Department:
Electrical
Product Group:
Fasteners
Product Subgroup:
Washers / Nuts / Bolts / Screws
Product Type:
Nut without spring
Product Finish:
Stainless steel type 316
Product Details:
Nut without spring
Product Material:
Steel

B-LINE N223SS6 – Frequently Asked Questions

1) What thread size does the B-Line N223SS6 channel nut take?
The N223SS6 is tapped 5/16"-18, so it accepts 5/16"-18 threaded rod, hanger bolts, or machine bolts. If your rod is 3/8"-16 or 1/2"-13, this is not the nut for that run.
2) Is this strut nut stainless, and can it go outdoors or in a corrosive area?
It is Type 316 stainless steel, which is the grade specified for coastal, wash-down, water treatment, and chemical exposure where plated or Type 304 hardware would pit. Pair it with 316 strut and 316 rod so you are not mixing dissimilar metals in the same connection.
3) Does the N223SS6 have a spring on it?
No spring. It is a plain channel nut, so it will not hold itself in position in the strut while you line up the rod. On overhead work that means one hand on the nut until the bolt catches. If you are setting a lot of hangers alone or working above your head, a spring nut is the easier part to install.
4) What else do I need to order with these channel nuts to hang a pipe or conduit run?
The nut is the connection point only. You still need the strut channel itself, 5/16"-18 threaded rod or bolts to match the tapped thread, and the clamps or hangers that carry the pipe or conduit. For a 316 stainless install, keep the rod and clamps in 316 as well.
5) Is the N223SS6 sold as a single nut or in a box?
Each N223SS6 is one channel nut, weighing .1 lb apiece. Count one per rod or bolt connection and order the quantity your hanger layout calls for.
