B-Line B277ZN Eaton series str...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$670.03
Image coming soon

B-Line B277ZN Eaton series strut fittings and accessories, 3.93" Height, 9.18" Length, 1.68" Width, 2.85lbs, Steel, Twelve hole double corner gussetted connection, Electro-plated

(No reviews yet) Write a Review

Model: B277ZN

In Stock (leaves warehouse same day if ordered before 3pm ET)

$670.03
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series strut fittings and accessories, 3.93" Height, 9.18" Length, 1.68" Width, 2.85lbs, Steel, Twelve hole double corner gussetted connection, Electro-plated

Manufacturer Resources

Product Specs

Certifications:
Not Applicable
Product Height:
3.93 in
Product Length Depth:
9.18 in
Product Weight:
2.85 lb
Product Width:
1.68 in
Department:
Electrical
Product Type:
Twelve hole double corner gussetted connection
Product Finish:
Electro-plated
Product Details:
Twelve hole double corner gussetted connection
Product Material:
Steel

B-LINE B277ZN – Frequently Asked Questions

1) What size is the B277ZN strut corner gusset and how much does it weigh?
Dimensions are 9.18 in length/depth, 3.93 in height, and 1.68 in width, at 2.85 lb. The 1.68 in width matches the face of standard 1-5/8 in strut channel, so it seats on the channel face rather than overhanging it. Use the 9.18 and 3.93 in legs to check you have clearance on both runs before you bolt it up.
2) Is the B277ZN fitting okay for outdoor or damp locations?
It is steel with an electro-plated (zinc) finish, which is a dry indoor-to-sheltered coating. For sustained outdoor exposure, wash-down areas, or corrosive atmospheres, specify a hot-dip galvanized or stainless version of the fitting instead, since electro-plating is a thin sacrificial layer.
3) Do the hardware and channel nuts come with the B277ZN corner gusset?
The B277ZN is supplied as the fitting only, a twelve hole double corner gussetted connection. Order your channel nuts, bolts, and washers separately, sized to the strut you are joining, and match the plating to the fitting's electro-plated finish so you are not mixing dissimilar coatings in one joint.
4) Should I use a gusseted corner fitting or a flat 90 degree angle bracket on strut?
A flat angle plate only ties the two channels together at the corner. The B277ZN's double gusseted form triangulates the corner, which is what you want when the frame has to resist racking, as on a cantilever arm or a free-standing rack. For a light alignment joint where load runs straight through the channel, a plain angle fitting is enough and takes less room. The B277ZN needs 9.18 in along one leg and 3.93 in on the other.
5) What is the exact part number to order for the B-Line twelve hole gusseted corner fitting?
Order Eaton B-Line B277ZN. The ZN suffix is the electro-plated (zinc) finish; the same base fitting exists in other finishes under different suffixes, so quote the full B277ZN if you want the plated version.
6) Does the B277ZN carry a UL listing or other certification?
No certification applies to the B277ZN. It is a mechanical strut connection fitting in steel with an electro-plated finish, not an electrical device, so there is no listing mark on the part itself. Where a project spec calls for a rated support assembly, the requirement sits on the system design and the channel, not on the corner fitting.
