Eaton B-Line series wireway elbow fitting, Lay-in, 90° elbow, inside opening, NEMA 1, Steel, ANSI 61 gray painted, 3" X 3"
Manufacturer Resources
Product Specs
- Certifications:
- UL Listed
- Degree Of Protection:
- 1
- Finish Color:
- ANSI 61 gray painted
- Product Height:
- 3 in
- Product Length Depth:
- 3 in
- Product Weight:
- 2.638 lb
- Product Width:
- 7.306 in
- Wiring Method:
- Lay in
- Department:
- Electrical
- Product Group:
- Conduit & Fittings
- Product Subgroup:
- Elbows
- Product Type:
- 90° elbow, inside opening
- Product Details:
- 90° elbow, inside opening
- Product Material:
- Steel
B-LINE 33 FL IN – Frequently Asked Questions
1) Will the B-Line 33 FL IN elbow fit 3 inch by 3 inch lay-in wireway?
Yes. The B-Line Eaton 33 FL IN is built for 3 x 3 inch lay-in wireway, with a product height of 3 in and length/depth of 3 in matching that trough size. It is a 90 degree elbow with an inside opening, so it turns the run toward the inside of the corner. It will not mate with 4 x 4 or larger wireway.
2) What is the difference between an inside opening and an outside opening 90 degree wireway elbow?
On the 33 FL IN, the opening faces the inside of the turn, so the cover access and the wire path are on the short (inner) side of the corner. An outside-opening elbow puts the opening on the long side of the turn. Pick by which way your wireway run bends relative to the wall or equipment: if the trough turns away from the corner you are working in, you need the outside version instead. Getting this wrong means the conductors will not lay in.
3) Is this B-Line wireway elbow rated for outdoor or wet locations?
No. It is a NEMA 1 enclosure rating, which is indoor general purpose only, protecting against incidental contact and falling dirt. For rooftops, wash-down areas, or anywhere water is present you need a NEMA 3R or 4 rated wireway fitting, not this one.
4) Will this elbow match the gray finish on my existing wireway run?
The elbow is painted ANSI 61 gray, which is the standard gray used across B-Line lay-in wireway trough and fittings, so it matches a typical existing industrial run. Body is steel.
5) What is the part number to order this B-Line 3x3 inside elbow?
Order it as B-Line (Eaton) model 33 FL IN. The FL indicates the lay-in flanged wireway line and IN the inside opening; the outside-opening companion is a different suffix, so specify IN if that is what your layout needs.
6) Do I need conduit fittings or connectors to join this elbow to my wireway?
No conduit connectors are involved. This is a lay-in wireway fitting, so it bolts directly to the flanged ends of matching 3 x 3 in lay-in trough with the same connector hardware used between trough sections. Conductors lay into the open channel rather than being pulled through.
7) How much does the 3x3 B-Line 90 degree lay-in wireway elbow weigh?
2.638 lb. Light enough to hold in place one-handed while you set the connecting screws, which matters when you are working off a ladder on an overhead run. Overall width of the fitting is 7.306 in, so allow that much clearance at the corner.
