Eaton CCV2060 Series – Shunt-Trip Tenant Main Circuit Breaker – 60A, 2-Pole, 120/240V, 10 kAIC

Eaton CCV2060 Series Shunt-Trip Tenant Main Circuit Breaker - 60A, 2-Pole, 120/240V with Line/Load Collar

(No reviews yet) Write a Review

Model: CCV2060SR02

In Stock (leaves warehouse same day if ordered before 3pm ET)

$3,260.00
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CCV2060 Series Shunt-Trip Tenant Main Circuit Breaker

Professional tenant metering and main disconnect solution with remote trip capability

The Eaton CCV2060 Series delivers reliable tenant main circuit protection with integrated shunt-trip functionality for remote disconnect applications. This 60-amp, 2-pole circuit breaker operates at 120/240V with 10 kAIC interrupting capacity, featuring a specialized line/load collar design for seamless integration with Type ECC unit enclosures. UL 489 certified construction ensures code compliance and professional-grade performance in multi-tenant electrical distribution systems.

Professional Features & Benefits

  • 60A Rating: Provides robust current capacity for tenant main service applications with reliable overcurrent protection.
  • Shunt-Trip Capability: Enables remote disconnect functionality for emergency shutoff and utility control applications.
  • Two-Pole Configuration: Delivers simultaneous disconnect of both hot conductors for complete circuit isolation and safety.
  • 120/240V Operation: Compatible with standard residential and light commercial voltage systems for versatile installation.
  • Line/Load Collar Design: Facilitates secure connections and proper conductor management in tenant metering applications.
  • UL 489 Certification: Meets rigorous safety and performance standards for molded case circuit breakers.
  • Type ECC Compatibility: Engineered specifically for integration with Eaton Type ECC unit enclosures for streamlined installation.

Technical Specifications

  • Amperage Rating: 60 A
  • Certifications: UL 489
  • Circuit Breaker Frame Type: CCV
  • Number Of Poles: Two-pole
  • Product Details: Shunt trip line/load collar
  • Product Height: 5.5 in
  • Product Length Depth: 8 in
  • Product Weight: 2.83 lb
  • Product Width: 4.5 in
  • Used With: Type ECC Unit Enclosures
  • Voltage Rating: 240 V - 240 V

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Multi-tenant residential buildings and apartment complexes
  • Commercial tenant spaces requiring individual metering
  • Mixed-use developments with separate utility billing
  • Property management facilities with remote disconnect needs
  • Retail strip centers and professional office buildings
  • Student housing and dormitory electrical systems
  • Emergency services requiring remote shutoff capability

Why Choose Eaton Quality?

Eaton circuit breakers deliver proven reliability through UL 489 certification and precision engineering. The CCV2060 Series combines robust 60-amp capacity with specialized shunt-trip functionality, ensuring dependable performance in demanding tenant metering applications. Professional-grade construction and Type ECC enclosure compatibility provide long-term durability and seamless system integration.

Manufacturer Resources

Product Specs

Amperage Rating:
60 A
Certifications:
UL 489
Circuit Breaker Frame Type:
CCV
Number Of Poles:
Two-pole
Product Details:
Shunt trip line/load collar
Product Height:
5.5 in
Product Length Depth:
8 in
Product Weight:
2.83 lb
Product Width:
4.5 in
Used With:
Type ECC Unit Enclosures
Voltage Rating:
240 V - 240 V
Department:
Electrical
Product Group:
Circuit Breakers
Product Type:
Circuit Breaker
