Eaton CCV Two-Pole Main Circuit Breaker 120/240V 10kAIC with Shunt Trip

Eaton CCV Two-Pole Main Circuit Breaker 120/240V 10kAIC with Shunt Trip

Professional Main Circuit Protection for Tenant Applications

The Eaton CCV Two-Pole Main Circuit Breaker delivers reliable electrical protection for tenant applications with 120/240V operation and 10kAIC interrupt rating. This UL 489 listed circuit breaker features shunt trip capability and standard lugs suitable for copper or aluminum wire connections, providing professional-grade protection in a compact CCV frame design.

Professional Features & Benefits

• 10kAIC Interrupt Rating: Provides robust fault current interruption capability for enhanced electrical system protection and safety.
• Two-Pole Configuration: Delivers simultaneous protection for both hot conductors in 120/240V applications with coordinated switching action.
• Shunt Trip Feature: Enables remote circuit breaker operation for emergency shutdown or automated control system integration.
• UL 489 Certification: Meets rigorous safety and performance standards for molded case circuit breakers in commercial applications.
• Standard Lug Terminals: Accommodates both copper and aluminum conductors for flexible installation and connection options.
• CCV Frame Design: Optimized for tenant main applications with compact dimensions and reliable mechanical operation.
• Type ECC Compatibility: Specifically designed for use with Type ECC unit enclosures for complete system integration.

Technical Specifications

• Catalog Notes: Terminals-standard lugs (wire connectors) suitable for copper or aluminum wire.
• Certifications: UL 489
• Circuit Breaker Frame Type: CCV
• Interrupt Rating: 10 kAIC
• Main Circuit Breaker: CCV
• Number Of Poles: Two-pole
• Product Height: 5.5 in
• Product Length Depth: 8 in
• Product Weight: 2.83 lb
• Product Width: 4.5 in
• Used With: Type ECC Unit Enclosures

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Tenant Main Service Protection
• Multi-Unit Residential Properties
• Commercial Tenant Spaces
• Apartment Building Electrical Systems
• Small Commercial Facilities
• Professional Office Buildings
• Retail Tenant Improvements

Why Choose Eaton Quality?

Eaton circuit breakers provide dependable electrical protection with UL 489 certification ensuring compliance with industry safety standards. The compact CCV frame design and compatibility with Type ECC enclosures deliver professional-grade performance for tenant main applications with reliable mechanical operation and durable construction.
