Eaton CCV2125 Series – Tenant Main Circuit Breaker – 125 A, 2-Pole, 120/240 V, 10 kAIC

Eaton CCV2125 Series Tenant Main Circuit Breaker - 125A 2-Pole 120/240V 10kAIC

(No reviews yet) Write a Review

Model: CCV2125W

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,050.00
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CCV2125 Series Tenant Main Circuit Breaker - 125A 2-Pole 120/240V 10kAIC

Professional Tenant Electrical Distribution & Protection

The Eaton CCV2125 Series tenant main circuit breaker delivers reliable electrical protection and distribution for multi-tenant applications. This 125A, 2-pole unit operates at 120/240V with 10kAIC interrupt rating, featuring the proven CCV frame design with standard lugs suitable for copper or aluminum wire connections. UL 489 certified for professional installations requiring dependable tenant electrical service.

Professional Features & Benefits

  • 125A Rating: Provides substantial electrical capacity for tenant main service applications with reliable overcurrent protection.
  • 2-Pole 120/240V Configuration: Delivers standard residential and light commercial voltage distribution for versatile tenant electrical systems.
  • 10kAIC Interrupt Rating: Ensures safe fault current interruption capability for professional electrical protection requirements.
  • CCV Frame Design: Proven circuit breaker frame type engineered for reliable performance in tenant main applications.
  • Standard Lugs for Cu/Al Wire: Accommodates #2/0 AWG-300 kcmil copper or aluminum conductors for flexible installation options.
  • UL 489 Certification: Meets rigorous safety and performance standards for professional electrical distribution equipment.
  • 4.5" Width: Compact profile designed for efficient installation in Type ECC unit enclosures.

Technical Specifications

  • Amperage Rating: 125 A
  • Catalog Notes: Terminals-standard lugs (wire connectors) suitable for copper or aluminum wire.
  • Certifications: UL 489
  • Circuit Breaker Frame Type: CCV
  • Interrupt Rating: 10 kAIC
  • Main Circuit Breaker: CCV
  • Number Of Poles: Two-pole
  • Product Details: Tenant main circuit breaker
  • Product Width: 4.5 in
  • Used With: Type ECC Unit Enclosures
  • Voltage Rating: 120/240 V
  • Wire Size: #2/0 AWG-300 kcmil Cu/Al

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Multi-tenant residential buildings and complexes
  • Commercial tenant spaces and office buildings
  • Retail tenant electrical distribution
  • Mixed-use development electrical systems
  • Property management electrical infrastructure
  • Professional tenant electrical service upgrades

Why Choose Eaton Quality?

Eaton circuit breakers deliver proven reliability and durability with UL 489 certification ensuring professional-grade performance. The CCV frame design provides dependable overcurrent protection while standard lug terminals offer installation flexibility for copper or aluminum conductors, making this tenant main circuit breaker an ideal choice for professional electrical distribution applications.

Manufacturer Resources

Product Specs

Amperage Rating:
125 A
Catalog Notes:
Terminals-standard lugs (wire connectors) suitable for copper or aluminum wire.
Certifications:
UL 489
Circuit Breaker Frame Type:
CCV
Interrupt Rating:
10 kAIC
Main Circuit Breaker:
CCV
Number Of Poles:
Two-pole
Product Details:
Tenant main circuit breaker
Product Width:
4.5 in
Used With:
Type ECC Unit Enclosures
Voltage Rating:
120/240 V
Wire Size:
#2/0 AWG-300 kcmil Cu/Al
Department:
Electrical
Product Group:
Circuit Breakers
Product Type:
Circuit Breaker
