Eaton CCV2060 Series – Tenant Main Circuit Breaker – 60A, 10 kAIC, 2-Pole, 120/240 V

Eaton CCV2060 Series Tenant Main Circuit Breaker 60A 2-Pole 120/240V 10kAIC

(No reviews yet) Write a Review

Model: CCV2060

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,095.71
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CCV2060 Series Tenant Main Circuit Breaker 60A 2-Pole 120/240V 10kAIC

Professional Tenant Main Protection for Multi-Unit Applications

The Eaton CCV2060 Series Tenant Main Circuit Breaker delivers reliable electrical protection for multi-unit residential and commercial tenant applications. This 60A, 2-pole circuit breaker operates at 120/240V with a 10kAIC interrupt rating, featuring the proven CCV frame design for dependable service in Type ECC Unit Enclosures. UL 489 certified for professional installations requiring robust tenant main protection.

Professional Features & Benefits

  • 60A Rating: Provides adequate capacity for typical tenant electrical loads while maintaining safe operation limits.
  • 10kAIC Interrupt Rating: Delivers reliable fault current interruption capability for enhanced electrical system protection.
  • 2-Pole Configuration: Enables simultaneous disconnection of both hot conductors for complete tenant main isolation.
  • 120/240V Operation: Compatible with standard residential and light commercial voltage systems.
  • CCV Frame Design: Engineered for reliable performance in tenant main applications with proven Eaton quality.
  • UL 489 Certification: Meets rigorous safety and performance standards for professional electrical installations.
  • Type ECC Compatibility: Specifically designed for use with Type ECC Unit Enclosures for seamless integration.

Technical Specifications

  • Amperage Rating: 60 A
  • Certifications: UL 489
  • Circuit Breaker Frame Type: CCV
  • Interrupt Rating: 10 kAIC
  • Number Of Poles: Two-pole
  • Product Details: Tenant main circuit breaker
  • Product Height: 5.5 in
  • Product Length Depth: 8 in
  • Product Width: 4.5 in
  • Used With: Type ECC Unit Enclosures
  • Voltage Rating: 120/240 V
  • Wire Size: #2/0 AWG-300 kcmil Cu/Al

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Multi-Unit Residential Properties
  • Apartment Complex Tenant Services
  • Condominium Individual Unit Protection
  • Commercial Tenant Spaces
  • Mixed-Use Development Tenant Mains
  • Property Management Electrical Systems
  • Residential Electrical Service Upgrades

Why Choose Eaton Quality?

Eaton circuit breakers deliver proven reliability and durability backed by UL 489 certification and precision CCV frame engineering. The compact 5.5" x 4.5" x 8" design ensures efficient installation in Type ECC Unit Enclosures while accommodating #2/0 AWG-300 kcmil Cu/Al conductors for versatile wiring applications.

Manufacturer Resources

Product Specs

Amperage Rating:
60 A
Certifications:
UL 489
Circuit Breaker Frame Type:
CCV
Interrupt Rating:
10 kAIC
Number Of Poles:
Two-pole
Product Details:
Tenant main circuit breaker
Product Height:
5.5 in
Product Length Depth:
8 in
Product Width:
4.5 in
Used With:
Type ECC Unit Enclosures
Voltage Rating:
120/240 V
Wire Size:
#2/0 AWG-300 kcmil Cu/Al
Department:
Electrical
Product Group:
Circuit Breakers
Product Type:
Circuit Breaker
