Eaton CH Series Class A GFCI Circuit Breaker with Pigtail

Eaton CH Series Class A GFCI Circuit Breaker with Pigtail

(No reviews yet) Write a Review

Model: CHFN130GF
$117.45

In Stock (leaves warehouse same day if ordered before 3pm ET)

$117.45
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CH Series Class A GFCI Circuit Breaker with Pigtail

The Eaton CH Series Class A GFCI Circuit Breaker with Pigtail delivers reliable ground-fault protection for residential and light commercial branch circuits. Built with a flexible pigtail lead connection, this breaker provides Class-A GFCI protection with 5 mA personnel-protection sensitivity and a 10kAIC interrupt rating. UL Listed for code-compliant installations, it is engineered as a direct-fit CH-type breaker for panelboards requiring dependable ground-fault detection. This CH Series breaker is available across a range of pole counts and amperage ratings, so you can select the configuration that matches your specific branch-circuit requirements.

Key Features

  • Class-A GFCI Protection: Trips at 5 mA for reliable personnel protection against ground faults.
  • Interrupt Rating: 10kAIC interrupt rating for dependable fault-current handling in the panel.
  • Pigtail Connection: A flexible pigtail lead simplifies wiring compared to bolt-on or plug-on styles.
  • CH Circuit Breaker Type: Direct-fit compatibility with CH-series load centers and panelboards.
  • Multiple Configurations: Offered in a range of pole counts and amperage ratings to suit standard branch-circuit loads.

Certifications & Compliance

  • UL Listed

Technical Specifications

  • Connection: Pigtail
  • Interrupt Rating: 10kAIC
  • Type: GFCI Circuit Breaker
  • Circuit Breaker Type: CH
  • Certifications: UL Listed

Typical Applications

  • Residential and Light Commercial Panelboards
  • Ground-Fault Personnel Protection Circuits
  • Kitchen, Bathroom, and Outdoor Receptacle Branch Circuits
  • Panelboard and Load Center Wiring Upgrades
  • Renovation and New Construction Electrical Work

Why Eaton?

Eaton's CH Series GFCI circuit breakers combine Class-A ground-fault sensitivity with a 10kAIC interrupt rating and UL Listing to deliver code-compliant personnel protection for demanding electrical environments. The pigtail connection makes installation straightforward for licensed electricians, while direct-fit CH-series compatibility ensures dependable performance in panelboards built for long-term reliability. Whether upgrading an existing load center or wiring new branch circuits, this Eaton CH Series breaker provides the ground-fault protection required for kitchens, bathrooms, and outdoor receptacles under the National Electrical Code.

Manufacturer Resources

Product Specs

Product Type:
GFCI/AFCI Circuit Breaker
Series:
CH Series
Connection Type:
Pigtail
Listing:
UL Listed
Department:
Electrical
Product Group:
Circuit Protection
Product Subgroup:
Circuit Breakers

Eaton CHFN130GF – Frequently Asked Questions

1) Will an Eaton CHFN GFCI breaker fit my existing panel, or do I need a CH load center?
The CHFN GFCI breaker is a CH-type breaker, so it goes into Eaton CH load centers and panelboards only. It is not interchangeable with Eaton BR-type panels, and it will not fit a Square D, Siemens, or GE panel. Check the label inside your panel door: if it does not call for CH breakers, this is the wrong part. CH and BR panels look similar from the outside, which is where most wrong orders come from.
2) What amperage and pole configurations does the Eaton CHFN GFCI breaker come in?
Two-pole versions run 15, 20, 25, 30, 35, 40, 45, and 50 amps, ordered as CHFN215GF through CHFN250GF. Single-pole versions come in 30 and 60 amp, CHFN130GF and CHFN260GF. Two-pole is what you use for a 240V load like a spa, well pump, or range circuit; single-pole covers a 120V branch circuit.
3) Is the Eaton CHFN a Class A GFCI that meets code for people protection, or is it equipment protection only?
Class A, tripping at 5 mA of ground-fault current. That is the personnel-protection threshold the NEC requires for receptacle circuits in kitchens, bathrooms, garages, and outdoors. A 30 mA equipment-protection device (sometimes sold as GFPE) does not satisfy those requirements. The CHFN is also UL Listed.
4) What is the pigtail on an Eaton CHFN GFCI breaker for, and where does it land?
The white pigtail lead is the breaker's neutral connection, and it lands on the panel's neutral bar. The circuit's own neutral does not go to the neutral bar; it terminates on the breaker's marked load-neutral terminal. Get those two reversed and the breaker trips the moment you energize it. This is the standard wiring difference between a GFCI breaker and a plain thermal-magnetic breaker, which has no pigtail at all.
5) Does a 2-pole CHFN GFCI breaker work on a 240V circuit with no neutral, like a spa or a water heater?
Yes. On a 240V two-wire load, both hot legs land on the breaker and the circuit neutral terminal stays empty. The breaker's own white pigtail still has to go to the panel neutral bar, because that is what powers the ground-fault sensing electronics. Skip the pigtail and the GFCI function will not work. If the load is 120/240V, such as a range or dryer, the circuit neutral lands on the breaker's load-neutral terminal instead.
6) Should I use a GFCI breaker at the panel or a GFCI receptacle at the outlet?
A GFCI receptacle is cheaper and easier when one device can protect the outlets downstream of it. The CHFN breaker is the better choice when the receptacle location is hard to reach for monthly testing, when the load has no receptacle at all (a spa disconnect, a well pump, a dishwasher), when you need the whole branch circuit protected from the first inch of wire, or when the circuit is 240V, where receptacle-style GFCIs are not an option. Note that the breaker's test button is at the panel, so testing means a trip to the load center.
7) Is the Eaton CHFN a GFCI only, or does it also have AFCI arc-fault protection?
Ground-fault only. The CHFN is a Class A GFCI at 5 mA and carries no arc-fault function. If your inspector is calling for combination AFCI/GFCI protection, which the NEC requires on a number of dwelling-unit circuits, this breaker will not satisfy that on its own. For a straight 240V equipment circuit like a spa or a pump, GFCI-only is normally what is required.
8) I manage apartments and want the same GFCI breaker across all my panels. Can I standardize on the CHFN?
Across CH-equipped units, yes. The CHFN family spans 15 through 50 amp two-pole plus 30 and 60 amp single-pole, so one breaker line covers bathroom and kitchen circuits through to a range or spa feed. What breaks the standardization is panel type: any building with Eaton BR panels, or another manufacturer's panels, needs a different breaker for those units. Walk the panels first and sort them by type.
9) What do I order for a hot tub or spa disconnect, and does the CHFN cover it?
Spa circuits are 240V and require GFCI protection, so a 2-pole CHFN sized to the spa's nameplate is the usual answer. The common sizes are on hand: 40 amp is CHFN240GF, 50 amp is CHFN250GF, 60 amp for a single-pole application is CHFN260GF. Size the breaker to the equipment nameplate, not to a rule of thumb. The breaker only fits if the panel it lands in is a CH panel.
10) Which exact Eaton part number is the 20 amp 2-pole GFCI breaker?
CHFN220GF is the 20 amp two-pole. The naming runs in a straight pattern across the family: CHFN, then the pole count, then the amperage, then GF. So CHFN215GF is 2-pole 15A, CHFN230GF is 2-pole 30A, and CHFN130GF is the 1-pole 30A. Order by the full part number, since the pole digit is the easy one to miss.
