Eaton CL Ground Fault Breakers- Classified 1-Inch GFCI -1-Inch (25.4 mm) per Pole, 10 kAIC

Eaton CL Ground Fault Circuit Breaker 15A 120/240V Single-Pole GFCI with 10 kAIC Interrupt Rating

(No reviews yet) Write a Review

Model: CLGF115

In Stock (leaves warehouse same day if ordered before 3pm ET)

$116.71
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CL Ground Fault Circuit Breaker 15A 120/240V Single-Pole GFCI with 10 kAIC Interrupt Rating

Professional Ground Fault Protection for Residential & Commercial Applications

The Eaton CL Ground Fault Circuit Breaker delivers reliable ground fault circuit interruption with 15A trip rating and 120/240V voltage compatibility. This single-pole GFCI breaker features plug-on connection design with 10 kAIC interrupt rating and trip-to-center functionality for enhanced safety and performance in electrical panel installations.

Professional Features & Benefits

  • 15A Trip Rating: Provides precise overcurrent protection for branch circuits while maintaining reliable operation under normal load conditions.
  • Ground Fault Circuit Interrupter: Delivers essential GFCI protection to prevent electrical shock hazards in wet locations and sensitive applications.
  • 10 kAIC Interrupt Rating: Ensures safe fault current interruption capability for residential and light commercial electrical systems.
  • Single-Pole Design: Compact 1-inch width maximizes panel space utilization while providing dedicated circuit protection.
  • Plug-On Connection: Simplifies installation with secure mechanical and electrical connection to panel bus bars.
  • Trip-to-Center Functionality: Provides clear visual indication of tripped condition for faster troubleshooting and system restoration.
  • 120/240V Voltage Rating: Compatible with standard residential and commercial voltage systems for versatile application flexibility.

Technical Specifications

  • Certifications: Contact Manufacturer
  • Circuit Protection: Ground fault circuit interrupter
  • Connection: Plug-on
  • Indicators: GFI
  • Interrupt Rating: 10 kAIC
  • Main Circuit Breaker: CLGF
  • Mounting Method: Plug-on
  • Number Of Poles: Single-pole
  • Product Details: Ground fault circuit breaker
  • Product Height: 1 in
  • Product Length Depth: 4 in
  • Product Weight: .45 lb
  • Product Width: 3.5 in
  • Trip Rating: 15 A
  • Trip Type: Trip-to-center
  • Voltage Rating: 120/240 V
  • Wire Size: #14-8 AWG

Professional Applications

  • Residential Kitchen and Bathroom Circuits
  • Commercial Wet Location Protection
  • Outdoor Electrical Installations
  • Pool and Spa Equipment Circuits
  • Workshop and Garage Applications
  • Medical and Healthcare Facilities
  • Educational Institution Safety Systems

Why Choose Eaton Quality?

Eaton CL Ground Fault Circuit Breakers provide dependable electrical protection with proven plug-on connection technology and compact single-pole design. The 10 kAIC interrupt rating and trip-to-center operation ensure reliable performance and clear fault indication for professional electrical installations requiring ground fault protection.

Manufacturer Resources

Product Specs

Certifications:
Contact Manufacturer
Circuit Protection:
Ground fault circuit interrupter
Connection:
Plug-on
Indicators:
GFI
Interrupt Rating:
10 kAIC
Main Circuit Breaker:
CLGF
Mounting Method:
Plug-on
Number Of Poles:
Single-pole
Product Details:
Ground fault circuit breaker
Product Height:
1 in
Product Length Depth:
4 in
Product Weight:
.45 lb
Product Width:
3.5 in
Trip Rating:
15 A
Trip Type:
Trip-to-center
Voltage Rating:
120/240 V
Wire Size:
#14-8 AWG
Department:
Electrical
Product Group:
Circuit Protection
Product Type:
Circuit Breaker
Product Subgroup:
Circuit Breakers

Eaton CLGF115 – Frequently Asked Questions

1) Will the Eaton CLGF GFCI breaker fit my existing panel, or do I need a specific loadcenter?
The CLGF is a plug-on breaker that mounts by snapping onto the panel bus, and it takes 1 inch of panel space per pole. CL breakers are the classified 1-inch type, so what decides the job is whether your loadcenter accepts a 1-inch plug-on breaker in that slot. If your panel uses twin/tandem breakers in that position or a bolt-on interior, this is the wrong body style. Check the panel label for the accepted breaker list before you buy a case of them.
2) What amp ratings does the Eaton CLGF ground fault breaker come in?
Three: 15A (CLGF115), 20A (CLGF120) and 30A (CLGF130). Pick by the branch circuit conductor, not by the load. 15A goes on 14 AWG, 20A on 12 AWG, and 30A on 10 AWG for a general circuit. The 30A is the one people reach for on a spa or well pump; the 20A covers most kitchen and bath receptacle circuits.
3) Can I use a single-pole Eaton CLGF on a 240V circuit?
No. The CLGF is a single-pole breaker, so it lands on one hot leg and gives you a 120V circuit. The 120/240V rating describes the system it can be installed in, not a two-wire 240V load. A 240V GFCI load such as a spa heater, a well pump, or an EV charger needs a two-pole GFCI breaker instead. Use the single-pole for 120V circuits: receptacles, lighting, and single-hot equipment.
4) Does a GFCI breaker need a neutral connection, or does it wire like a standard breaker?
A GFCI breaker is not a two-wire swap for a standard breaker. Ground fault sensing works by comparing current out on the hot against current back on the neutral, so the circuit neutral has to terminate on the breaker itself rather than on the panel neutral bar, and the breaker's own pigtail goes to the neutral bar. Budget the extra wire management: if you are converting existing circuits in a crowded panel, you will be pulling neutrals off the bar and re-landing them one circuit at a time.
5) What wire size can I land in an Eaton CLGF breaker lug?
The lug accepts #14 through #8 AWG, which covers every conductor you would run on the 15A, 20A and 30A versions with room to spare. That #8 top end also means you can land an oversized conductor on a long run without an in-panel splice or a reducer.
6) Should I use a GFCI breaker at the panel or just install GFCI receptacles?
A breaker protects the whole circuit from the panel out, including the cable in the wall and every device on it. GFCI receptacles protect from that device downstream only. The breaker wins when the circuit feeds hard-wired equipment with no receptacle to protect at, when the outlets are outdoors or otherwise awkward to reach for the monthly test, or when a property manager wants all resetting done at one place instead of hunting a bathroom wall. The receptacle wins when you want the reset at the point of use and you do not want to give up a neutral landing in the panel. On a circuit with several outdoor receptacles, one CLGF at the panel replaces several devices.
7) How do I tell a tripped Eaton CLGF apart from a ground fault trip versus an overload?
The CLGF is a trip-to-center breaker with a GFI indicator, so the handle parks midway between ON and OFF when it trips, which reads clearly down a row of breakers, and the indicator flags a ground fault trip specifically. That distinction saves diagnostic time: an indicator showing means you are chasing a leakage path, not a load that pulled too much current. Reset needs the handle driven fully to OFF first, then back to ON.
8) Which Eaton CLGF amperage do I need for a kitchen or bathroom receptacle circuit?
Kitchen small-appliance and bathroom receptacle circuits are normally 20A on 12 AWG, so the CLGF120 is the one that goes in. Reach for the CLGF115 for a 15A general lighting or single-outlet circuit on 14 AWG. Do not put a 20A breaker on a circuit wired in 14 AWG to get more capacity, the conductor sets the ceiling.
9) What is the exact part number for the Eaton 20 amp GFCI breaker?
CLGF120 is the 20A single-pole. The family runs CLGF115 for 15A and CLGF130 for 30A, all under the Eaton CL ground fault line. The pattern is CLGF, then 1 for the pole count, then the amperage, which is handy when you are writing up a panel schedule and need to call out several ratings at once.
10) How much panel space do three Eaton CLGF GFCI breakers take up?
One inch each. The CLGF is 1 inch per pole, so three of them consume three single-pole spaces, the same footprint as three standard single-pole breakers. Full body dimensions are 1 x 4 x 3.5 inches at .45 lb apiece. That 4 inch depth figure is the one to check against a shallow flush-mounted panel can where the cover has to close over landed conductors.
11) Will a GFCI breaker nuisance trip on a refrigerator or freezer circuit?
It can, and that is worth planning around before you standardize. Ground fault protection responds to small leakage current, and motor loads with long runs or aging windings, plus some electronics with line filters, can put enough leakage on the neutral to trip a GFCI device. On a dedicated appliance circuit where an unnoticed trip means spoiled stock, that is a real operating cost. The CLGF suits receptacle circuits, wet locations, outdoor circuits, and pool and spa equipment where the shock protection is the requirement.
