Eaton Type BR 70A 2-Pole Plug-On Circuit Breaker 120/240V with 10 kAIC Interrupt Rating

Eaton Type BR 70A 2-Pole Plug-On Circuit Breaker 120/240V with 10 kAIC Interrupt Rating

Professional electrical protection with UL 489 certification and reliable plug-on installation

The Eaton Type BR 70A 2-Pole Plug-On Circuit Breaker delivers dependable electrical protection for residential and commercial applications. Designed for Type BR Loadcenters, this 120/240V circuit breaker features a 10 kAIC interrupt rating and common breaker trip functionality. The plug-on mounting method ensures secure installation while accommodating #8-1/0 AWG Cu/Al wire sizes for versatile electrical connections.

Professional Features & Benefits

• 70A Amperage Rating: Provides robust current capacity for high-demand electrical circuits and equipment protection.
• 10 kAIC Interrupt Rating: Delivers reliable fault current interruption capability for enhanced electrical safety and system protection.
• Two-Pole Configuration: Enables simultaneous protection of both hot conductors in 240V applications with common trip functionality.
• Plug-On Mounting: Simplifies installation and replacement with secure connection to Type BR Loadcenters without additional hardware.
• UL 489 Certification: Meets rigorous safety and performance standards for molded case circuit breakers in electrical installations.
• 120/240V Voltage Rating: Compatible with standard residential and light commercial electrical systems for versatile application use.
• Cu/Al Wire Compatibility: Accepts both copper and aluminum conductors from #8-1/0 AWG for flexible wiring options.

Technical Specifications

• Amperage Rating: 70A
• Certifications: UL 489
• Circuit Breaker Type: BR
• Compliances: Federal Specifications Classification W-C375
• Interrupt Rating: 10 kAIC
• Main Circuit Breaker: BR
• Mounting Method: Plug-on
• Number Of Poles: Two-pole
• Trip Type: Common breaker trip
• Used With: Type BR Loadcenters
• Voltage Rating: 120/240V
• Wire Size: #8-1/0 AWG Cu/Al

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Residential electrical panels and distribution systems
• Commercial building electrical protection
• Light industrial facility power distribution
• Multi-unit residential properties
• Professional office electrical systems
• Retail establishment power management
• Service and maintenance electrical upgrades

Why Choose Eaton Quality?

Eaton circuit breakers deliver proven reliability with UL 489 certification and Federal Specifications Classification W-C375 compliance. The Type BR design ensures compatibility with existing Eaton loadcenters while providing dependable electrical protection for demanding applications.
