Eaton 480V, 60Hz Coil for D26 Series Relays

Eaton 480V, 60Hz Coil for D26 Series Relays

(No reviews yet) Write a Review

Model: 9-1989-3

In Stock (leaves warehouse same day if ordered before 3pm ET)

$602.16
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton 480V, 60Hz Coil for D26 Series Relays

The Eaton 480V, 60Hz Coil is a genuine Eaton renewal part engineered specifically for use with Eaton D26 series relays. Designed as a direct replacement component, this coil restores proper relay operation on 480V, 60Hz control circuits, helping maintain the reliability of the switching and control systems that keep industrial and commercial electrical equipment running. As an Eaton renewal part, it is built to match the fit, form, and function of the original coil it replaces, so maintenance and facilities teams can service existing D26 series relays without sourcing an entirely new relay assembly. Keeping a stock of Eaton renewal coils on hand can help minimize downtime when a relay coil reaches the end of its service life.

Key Features

  • Electrical Rating: Rated for 480V at 60Hz, matching the control voltage and frequency of the relay circuit it serves.
  • Compatibility: Designed specifically for use with Eaton D26 series relays, ensuring proper fit and reliable operation when installed as a replacement.
  • Renewal Part: Classified as a Renewal Parts/Accessories component, intended as a direct replacement to restore relay function without replacing the entire relay assembly.
  • Eaton Quality: Manufactured by Eaton to the same standards as the original equipment coil, supporting consistent, code-compliant relay performance.
  • Simple Replacement: Enables maintenance teams to service D26 series relays quickly by swapping the coil rather than sourcing an entirely new relay.
  • Genuine OEM Fit: Sourced directly from Eaton, giving buyers confidence that the coil is engineered to the same specifications as the original D26 series relay coil.

Technical Specifications

  • Department: Electrical
  • Product Type: Coil
  • Voltage: 480V
  • Frequency: 60 Hz
  • Used With: D26 Series Relays
  • Part Category: Renewal Parts/Accessories

Typical Applications

  • Maintenance and Repair of Eaton D26 Series Relays
  • Commercial and Industrial Control Panels
  • Motor Control and Switching Circuits
  • Relay Renewal and Retrofit Projects
  • Panelboard and Control System Servicing
  • Facility and Plant Electrical Maintenance Programs

Why Eaton?

Eaton renewal parts, like this 480V, 60Hz coil for D26 series relays, are built to the same specifications as original equipment, giving maintenance professionals a dependable way to keep existing Eaton relays in service. Choosing a genuine Eaton coil helps ensure the replacement part integrates correctly with the D26 series relay it is designed for, supporting continued reliable performance in electrical control applications. For facilities standardized on Eaton control equipment, sourcing genuine Eaton renewal coils is a straightforward way to extend the service life of installed D26 series relays while maintaining consistent electrical performance across a facility.

Manufacturer Resources

Product Specs

Department:
Electrical
Product Length/Depth:
.01 in
Product Height:
.01 in
Product Width:
.01 in
Certifications:
Not Applicable
Product Type:
Contactor Coil
Voltage Rating:
480V
Product Group:
Motor Control & Automation
Product Subgroup:
Contactors & Relays
Product Weight:
0.01 lb
Product Length:
0.01 in

Eaton 9-1989-3 – Frequently Asked Questions

1) Will this Eaton coil work on a D26 series relay running a 480V control circuit?
Yes. The Eaton renewal coil is rated 480V at 60Hz and is made for Eaton D26 series relays. Match both numbers on your existing coil before you pull it: a coil wound for 480V will not hold in on a 120V or 240V control circuit, and putting 480V across a lower-voltage coil burns it. If your D26 relay is fed from a 480V, 60Hz control source, this is the matching renewal part.
2) Which Eaton coil part number do I order, 9-1989-3 or 9-2404-4?
Both are sold under the same 480V/60Hz D26 coil, as configuration options 3 and 4. Configuration 3 is MPN 9-1989-3 and configuration 4 is MPN 9-2404-4. Read the number stamped on the coil you are replacing and order the matching one, since the two are not interchangeable choices, they are distinct Eaton part numbers.
3) Can I just replace the coil instead of buying a whole new Eaton D26 relay?
That is exactly what this part is for. It is an Eaton renewal part built to the fit, form, and function of the original D26 coil, so a maintenance tech can swap the coil and put the relay back in service rather than pulling and rewiring a complete relay assembly. For plants standardized on Eaton control gear, keeping a spare 480V coil on the shelf shortens the outage when a coil fails.
4) Will this 60Hz coil run on 50Hz power?
It is specified as a 480V, 60Hz coil, so it is intended for 60Hz control circuits, the standard in North America. Frequency changes the coil's impedance, so do not assume a 60Hz coil is a drop-in for a 50Hz application. If your panel runs 50Hz, source the coil wound for that frequency.
5) Where is a coil like this typically used in a building or plant?
It goes into commercial and industrial control panels, motor control and switching circuits, panelboard and control system servicing, and relay renewal or retrofit work. Practically, any Eaton D26 relay sitting in a control panel on a 480V, 60Hz circuit is a candidate when its coil has reached end of life.
