Eaton Crouse-Hinds DSD933 Explosion-Proof Snap Switch Cover & Device Sub-Assembly - 20 A, 120/277 V, 1-Pole, Copper-Free Aluminum

Crouse-Hinds DSD933 Explosion-Proof Snap Switch Cover & Device Sub-Assembly - 20A, 120/277V, Single-Pole, Class I Division 1

(No reviews yet) Write a Review

Model: DSD933

In Stock (leaves warehouse same day if ordered before 3pm ET)

$404.91
$402.46
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Crouse-Hinds DSD933 Explosion-Proof Snap Switch Cover & Device Sub-Assembly

Professional hazardous location switching solution with Class I Division 1 certification

The Crouse-Hinds DSD933 Explosion-Proof Snap Switch Cover & Device Sub-Assembly delivers reliable switching control for hazardous and classified locations. This single-pole unit features a robust 20A rating at 120/277V and meets stringent Class I Division 1 requirements. Constructed with durable Feraloy iron alloy material and NEMA 3 rating, this explosion-proof switch assembly provides dependable performance in demanding industrial environments where safety and compliance are critical.

Professional Features & Benefits

  • 20A Amperage Rating: Handles substantial electrical loads with reliable switching capacity for industrial applications
  • 120/277V Dual Voltage: Compatible with standard commercial and industrial voltage systems for versatile installation flexibility
  • Class I Division 1 Certification: Meets the highest hazardous location safety standards for explosive atmosphere protection
  • Feraloy Iron Alloy Construction: Provides exceptional durability and corrosion resistance in harsh industrial environments
  • NEMA 3 Rating: Offers protection against weather, windblown dust, and external ice formation for outdoor applications
  • Single-Pole Configuration: Delivers precise control for dedicated circuit switching with simplified wiring requirements
  • NEC/CEC Standards Compliance: Ensures installation meets North American electrical code requirements for professional installations

Technical Specifications

  • Amperage Rating: 20A
  • Area Classification: Hazardous/Classified Locations
  • Configuration: 1-pole
  • Nec Hazardous Rating: Class I, Division 1
  • Nema Rating: 3
  • Number Of Poles: Single-pole
  • Product Height: 6.7 in
  • Product Length Depth: 5.3 in
  • Product Material: Feraloy iron alloy
  • Product Weight: 2.5 lb
  • Product Width: 4.6 in
  • Standards Type: NEC/CEC
  • Voltage Rating: 120/277 Vac

Professional Applications

  • Petrochemical Processing Facilities
  • Oil and Gas Production Sites
  • Chemical Manufacturing Plants
  • Paint and Solvent Storage Areas
  • Grain Handling and Processing
  • Pharmaceutical Manufacturing
  • Hazardous Material Storage Facilities

Why Choose Crouse-Hinds Quality?

Crouse-Hinds explosion-proof switching solutions provide uncompromising safety and reliability in the most demanding hazardous environments. With Class I Division 1 certification, NEMA 3 weather protection, and durable Feraloy iron alloy construction, this switch assembly delivers the professional-grade performance required for critical industrial applications where safety cannot be compromised.

Manufacturer Resources

Product Specs

Amperage Rating:
20A
Area Classification:
Hazardous/Classified Locations
Configuration:
1-Pole
Nec Hazardous Rating:
Class I, Division 1
Nema Rating:
3
Number Of Poles:
Single-pole
Product Height:
6.7 in
Product Length Depth:
5.3 in
Product Material:
Feraloy iron alloy
Product Weight:
2.5 lb
Product Width:
4.6 in
Standards Type:
NEC/CEC
Voltage Rating:
120/277 Vac
Department:
Electrical
Product Type:
Hazardous Location Switch
Product Subgroup:
Switches
Product Group:
Wiring Devices

Crouse-Hinds DSD933 – Frequently Asked Questions

1) Is the Crouse-Hinds DSD933 a complete switch, or do I still need an enclosure body?
The DSD933 is a cover and device sub-assembly, meaning it is the snap switch and its cover together, not a finished enclosure. It mounts onto a hazardous-location device body of the matching Crouse-Hinds line, so plan on a body and the conduit hubs for the run as separate line items. Electrically the assembly itself is complete: single-pole, 20A, 120/277 Vac.
2) Can the DSD933 explosion-proof snap switch be used in a Class I Division 1 area?
Yes. The DSD933 carries a Class I, Division 1 hazardous rating, so it is suited to areas where flammable gas or vapor is present under normal operating conditions, such as process areas in petrochemical, chemical, and solvent-handling facilities. It is built to NEC/CEC standards for North American installations. If your area is classified Division 2 only, this switch still applies, since a Division 1 device is acceptable in a Division 2 location.
3) Will a 20A explosion-proof snap switch handle my 277V lighting circuit?
Yes, within its ratings: 20A at 120/277 Vac, which covers a standard 277V branch lighting circuit as well as 120V control and receptacle circuits. It is a single-pole device, so it switches one ungrounded conductor. For a 480V load, or for switching both legs of a 208/240V circuit, this is the wrong device and you need a two-pole or higher-voltage rated unit.
4) Do I need an explosion-proof switch like this, or is a standard weatherproof switch acceptable?
That is decided by the area classification, not by preference. In a location classified Class I, Division 1, the switch has to be rated for it, because a standard snap switch arcs at the contacts and that arc is the ignition source the classification exists to contain. The DSD933 is rated Class I, Division 1 and built to NEC/CEC requirements. Outside a classified area, a general-purpose or weatherproof switch is the correct and far simpler choice, and the heavy iron-alloy assembly buys you nothing.
5) Can this Crouse-Hinds explosion-proof switch be mounted outdoors?
NEMA 3 is the enclosure rating, so the assembly is built for outdoor service against rain, windblown dust, and external ice formation. That covers exterior process areas, tank farms, and loading racks. NEMA 3 is not a washdown or hosedown rating, so if the location gets pressure-washed regularly, specify a device rated for direct water jets instead.
6) How much room do I need to allow for the DSD933 switch assembly?
Allow for a footprint of 6.7 inches high, 4.6 inches wide, and 5.3 inches deep. The depth is what usually catches people out on a crowded rack or inside a guardrail, since the operating lever and cover sit well off the mounting surface. Weight is 2.5 lb, light enough to hang on a strut or a conduit-supported body without extra bracing.
7) Is the DSD933 switch body corrosion resistant enough for a coastal or chemical plant?
Feraloy iron alloy is the construction material, an iron alloy Crouse-Hinds uses on hazardous-location fittings for its strength and corrosion resistance, and it takes the plant's protective finish system. Combined with the NEMA 3 rating it is intended for exposed industrial service. In severely corrosive process areas, plants often standardize on the aluminum-bodied equivalents instead, so match whatever the rest of your conduit system is built from to avoid dissimilar metal problems at the hubs.
