Spec Sheet
Product Specs
- Amperage Rating:
- 175A
- Circuit Breaker Frame Type:
- Complete breaker
- Circuit Breaker Type:
- FD
- Frame:
- F-frame
- Frequency Rating:
- 50-60 Hz
- Interrupt Rating:
- 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
- Number Of Poles:
- Two-pole
- Series:
- Series C
- Terminals:
- Line and load
- Trip Type:
- Fixed thermal, fixed magnetic
- Voltage Rating:
- 600 Vac, 250 Vdc
- Department:
- Electrical
- Product Length:
- 3.38 IN
- Product Height:
- 2.75 IN
- Product Weight:
- 4.5 LB
- Product Width:
- 2.75 IN
B-LINE FD2175 – Frequently Asked Questions
1) What is the interrupting rating of the Eaton FD2175 circuit breaker at 240V and 480V?
The FD2175 F-frame breaker interrupts 65 kAIC at 240 Vac and 35 kAIC at 480 Vac. If your panel schedule calls for a higher AIC at 480 volts, this standard-interrupting FD will not meet it and you need a higher-rated frame or a series-rated combination documented for the panel.
2) Is the FD2175 a two-pole 175 amp breaker, and what voltage can it be used on?
Two poles, 175 amps, rated 600 Vac and 250 Vdc, at 50-60 Hz. That covers 240V and 480V three-phase line-to-line two-pole applications as well as 250 volt DC use.
3) Is the trip unit on the Eaton FD2175 adjustable?
No. The FD2175 uses a fixed thermal, fixed magnetic trip unit, so neither the long-time nor the instantaneous pickup can be dialed in. If your coordination study requires an adjustable instantaneous or an electronic trip, this breaker will not satisfy it.
4) Does the FD2175 come as a complete breaker with terminals, or do I have to order lugs separately?
It ships as a complete breaker, and the listed terminals are line and load, so the breaker arrives with terminations on both ends rather than as a bare frame needing a separate trip unit or lug kit.
5) Can the FD2175 be used on a 250 volt DC circuit?
Yes. Its rating covers 250 Vdc in addition to 600 Vac, so it can serve DC applications such as battery or drive circuits at or below 250 volts, at 175 amps across two poles.
6) What are the dimensions and weight of the Eaton FD2175 breaker for panel space planning?
The FD2175 measures 3.38 x 2.75 x 2.75 inches (length, width, height) and weighs 4.5 pounds. Useful for confirming gutter space and mounting depth before you set it in an enclosure or panelboard interior.
