Emtek 3017 Brisbane Brass Mortise Entrance Handleset - Dummy

Dummy only. The Brisbane 3017 is a non-keyed, non-latching trim set, so there is no latchbolt or cylinder and nothing operates. It is meant for an inactive leaf of a pair of doors or a door that is held shut by other means. If you need a working entrance function, order the keyed mortise entrance version of the Brisbane instead.

Yes, handing is required on all Emtek mortise sets, and the Brisbane is ordered as either LH or RH. Both hands are offered in all six finishes. Stand outside the door: if the hinges are on your left it is a left hand, hinges on the right is a right hand.

It takes a standard mortise pocket cut to ANSI A115.1, with a 2-1/2 inch or 2-3/4 inch backset. That means a rectangular mortise in the edge of the door, not a 2-1/8 inch cross bore, so it is not a drop-in for a tubular handleset prep.

The Emtek 3017 Brisbane is a dummy-function brass mortise handleset, and its inside trim is chosen from the knob or lever list, so a lever such as the Stuttgart or Athena can be specified on the Brisbane itself. If you want a factory-paired lever dummy instead, the Weslock 2815 Hillcrest is a dummy handleset supplied with the New Heaven lever in the Premiere Essentials series. The Weslock covers a 1-3/8 inch to 2 inch door thickness range, while the Brisbane is built around a 1-3/4 inch door as standard with thicker doors specified at order.

The 3017 Brisbane is a dummy, so it neither latches nor locks. For a keyed opening in a similar handleset format, the Schlage Residential F60 Addison is a single cylinder keyed entry handleset with the Accent lever, Grade 2, for doors 1-3/8 inch to 1-3/4 inch thick. If you want to stay with mortise trim, the Baldwin Estates 6542 Tremont is offered in single cylinder and double cylinder entry mortise trim for 1-3/4 inch doors.

A dummy such as the 3017 Brisbane is surface-mounted trim with no latching, suited to an inactive or fixed leaf. If the door swings and needs to latch without a key, the Schlage Residential JE285 Barcelona handleset with the Seville lever is a non-keyed entry function, Grade 2, for 1-3/8 inch to 1-3/4 inch doors.

The 3017 Brisbane is built for a 1-3/4 inch door as standard, with a thicker door specified at the time of order. If you prefer a product whose range already spans thicker doors, the Weslock 1411 Traditionale Colonial handleset covers 1-3/4 inch to 2-1/4 inch, and the Weslock 2810 Hillcrest covers 1-3/8 inch to 2 inch.

Use the 3017 Brisbane dummy on the fixed leaf, where its non-latching trim is the point, and put an operating handleset on the active leaf. The Pamex FS7P31 Lexington is a single cylinder entry handleset for 1-3/8 inch to 1-3/4 inch doors, and the Sure-Loc Madison is a keyed entry handleset with adjustable backset. Both handlesets on the pair can be ordered in a matching finish family such as satin nickel.

Yes, and it is a required choice at order. The inside trim can be any Emtek brass knob or lever, from levers like Stuttgart, Helios, Athena, Luzern and Cortina to knobs such as The Ace, Spoke, Round, Egg and the crystal knobs like Bristol and Windsor. The set ships complete with the exterior handle and the interior trim you selected.

Six: Oil Rubbed Bronze (US10B), Satin Nickel (US15), Flat Black (US19), Polished Chrome (US26), Unlacquered Brass (US3NL) and Satin Brass (US4). All six are available in both left and right hand. Unlacquered brass is a living finish and will patina over time, so pick it only if you want that change.

The Brisbane brass mortise entrance handlesets are cut to the Schlage C keyway, so a keyed version keys into an existing Schlage C system. The 3017 dummy itself has no cylinder and is non-keyed.

A tubular-prep dummy handleset avoids the mortise pocket entirely. The Weslock 2815 Hillcrest dummy handleset with New Heaven lever and the Weslock 6695 Belmont dummy handleset with Impresa knob are both dummy function and both list a 1-3/8 to 2 inch door thickness range, which is wider than the Brisbane's 1-3/4 inch standard. You give up the solid brass mortise construction and the Emtek trim selection.

No, they solve different problems. The 3017 Brisbane is a non-electronic dummy with no key and no latch. If the opening calls for electronic access, the Yale Real Living BYRD226CBARX pairs a Wi-Fi and Bluetooth touchscreen deadbolt with the Ridgefield handleset for 1-3/4 inch to 2-1/4 inch doors, and the Kwikset 815SCEHFL-CP913CNT San Clemente pairs a SmartCode keypad electronic deadbolt with a Halifax lever interior for 1-3/4 inch doors.

Handing must be specified on the 3017 Brisbane because it is a mortise lock, and the product is stocked in left hand and right hand versions across its finishes. Tubular alternatives are ordered differently: the Sure-Loc Alta is a tubular handleset with an adjustable backset, and the Sure-Loc Aspen, Coral and Madison handlesets are likewise built with adjustable backset rather than a fixed mortise prep.

Both are mortise-prepped brass trim. The 3017 Brisbane is a dummy handleset sold as a complete set with the inside knob or lever chosen at order, in left or right hand, over a standard ANSI A115.1 mortise prep with 2-1/2 inch or 2-3/4 inch backset. The Baldwin Estates 6542 Tremont is entrance function and is offered as single cylinder or double cylinder entry mortise trim for 1-3/4 inch doors.

They are not interchangeable. The Kwikset 687AMD Amador is a single cylinder keyed entry handleset supplied as exterior trim only, Grade 3, for 1-3/4 inch doors, and it is an SC1 SmartKey keyed product. The Emtek 3017 Brisbane is a non-keyed dummy sold as a complete set including the interior knob or lever you select.

The Brisbane is brass construction but dummy function. For solid brass entry handlesets, Deltana offers the 803871B Hanover, the 815871 St. Ann and the 825871 Kingston, all entry function in solid brass, and the 810871 Montego handleset covers doors 1-3/8 inch to 2 inch thick.

The 3017 Brisbane is a residential brass mortise handleset carrying a UL 180 minute fire rating and an ANSI F20 or F13 UL function over a standard ANSI A115.1 mortise prep. Peers state grade instead: the Schlage Residential F60 Addison and JE285 Barcelona are Grade 2, the Master Lock HDLB Series single cylinder deadbolt handleset is Grade 2, and the Kwikset 687BW Belleview is Grade 3.

The 3017 Brisbane is specified with a Schlage C keyway, though as a dummy it is supplied non-keyed. Among keyed alternatives, the Kwikset 687AMD Amador is offered in an SC1 keyway SmartKey version, which is the same Schlage-style keyway family, as well as a standard SmartKey version.

It is catalogued as a residential product. For a commercial opening needing a graded lock, a Schlage Residential F60 Addison is Grade 2, and the Master Lock HDLB Series single cylinder deadbolt handleset is also Grade 2, though neither is a mortise set. The Brisbane's strength is solid brass construction and finish selection on a home or high-end residential door.

Solid brass throughout, from Emtek's Brass collection, in a contemporary design. That matters for an exterior door because brass holds up outdoors and takes the plated and patina finishes offered here.
