Emtek 3019 Brisbane Brass Mortise Entrance Lockset - Dummy

No latch. The 3019 Brisbane is a dummy function, so the knob or lever is fixed and there is no working latchbolt or keyed cylinder. Use it on the inactive leaf of a pair of doors, on a closet or pantry door held by a ball catch or roller catch, or wherever you need the look of the mortise set on a door that does not need to latch. If the door has to stay shut on its own, you need a catch or a functioning lockset instead.

Yes, handing is required on all Emtek mortise locks, and it is ordered as left hand or right hand. There is no field-reversible option here, so you pick LH or RH at the time of order in whichever finish you want. Stand outside the door: if the hinges are on your left, it is left hand.

The Brisbane mortise set is offered in 2-1/2 inch and 2-3/4 inch backset, and the door prep is standard mortise per ANSI A115.1. If the door already carries an ANSI A115.1 mortise pocket, measure from the door edge to the centerline of the knob or lever hole to work out which backset you have, then order to match. A 2-1/2 inch set will not line up on a pocket cut for 2-3/4 inch.

Three choices make the order: handing (LH or RH), finish, and the knob or lever style for the inside trim. The trim menu is long, running from contemporary levers like Stuttgart, Helios and Athena through traditional knobs such as Providence, Waverly and Victoria, and on to crystal and porcelain options including Windsor, Bristol, Old Town and Ice White. It ships as a complete set once those are specified, and there is a door thickness field if the door is not 1-3/4 inch.

Both are dummy, non-keyed mortise-family trim with no latch operation. The Emtek 3019 Brisbane is a brass, residential-collection dummy set ordered handed and configured with a knob, crystal, porcelain, or lever inside trim in finishes including Oil Rubbed Bronze (US10B), Satin Nickel (US15), Flat Black (US19), Polished Chrome (US26), Unlacquered Brass (US3NL), and Satin Brass (US4). The Schlage L0170 is a Grade 1 heavy duty L Series non-keyed lever dummy trim for 1-3/4 inch doors. Choose the Emtek where the decorative brass trim needs to match other Emtek openings, and the L0170 where the door already carries L Series trim.

The Emtek 3019 Brisbane is a dummy set, so it is pull-only trim with no latching. For a latching non-keyed mortise unit, the Schlage PM010 is a Grade 1 passage latch mortise lock for 1-3/4 inch doors, the Falcon MA101 is a Grade 1 heavy duty passage mortise lock with field reversible operation, and the Hager 3810S is a 3800 Series Grade 1 passage mortise lock with rose and a 2-3/4 inch backset for doors 1-3/4 inch to 2-1/2 inch. All three operate a latch; the Brisbane dummy does not.

The Brisbane 3019 is non-keyed dummy trim and will not secure an opening. For a keyed entrance mortise lock body on a residential-style door, the Baldwin 6301 is an entry/apartment mortise lock body with a 2-1/2 inch backset for doors 1-3/4 inch and over, offered knob by knob or lever by lever as the 6301LS. The Baldwin 6310 is an entry/storeroom mortise lock body with a 2-1/2 inch backset for doors 1-3/8 inch and over. The apartment function and the storeroom function differ in how the outside trim is left locked or unlocked, so pick by how the tenant door is used.

The Brisbane 3019 is a residential dummy set with no locking function, so it does not answer a corridor opening. Grade 1 options with the functions those doors are usually written for include the Corbin Russwin ML2003 Grade 1 classroom mortise lockset for 1-3/4 inch doors, the Cal-Royal NM8070 Grade 1 classroom mortise lockset with auxiliary deadlatch for 1-3/4 inch doors, the Cal-Royal NM8050 Grade 1 office/entrance mortise lockset with auxiliary deadlatch, and the Accentra 8805FL Grade 1 storeroom mortise lock with Arcadia lever from the 8800 Series.

Yes. The Emtek 3019 Brisbane requires handing to be specified left or right, and it is stocked in LH and RH across its finishes, so the hand is fixed at the time of order. Some commercial mortise bodies are handled differently: the BEST 45H Series heavy duty public entrance mortise lock body is field reversible, the Falcon MA101 Grade 1 passage mortise lock is field reversible, and the Kaba Ilco 185 Series mortise lock takes no handing. If the hand may change on site, those behave differently from the Brisbane.

The Emtek 3019 Brisbane is built around a 1-3/4 inch standard door thickness with standard mortise ANSI A115.1 prep, which a thin metal stile will not accept. For 1 inch ornamental iron doors, the Marks USA 21AC is an entrance double cylinder Unilock ornamental iron mortise lock with round knob and the Marks USA 22AC is the same style of entrance double cylinder ornamental iron mortise lock. For an all-glass door, the Kaba Ilco BR Series glass door bottom rail lock is the product built for that rail.

Six: Oil Rubbed Bronze (US10B), Satin Nickel (US15), Flat Black (US19), Polished Chrome (US26), Unlacquered Brass (US3NL) and Satin Brass (US4). All six are available in both left and right hand. The body of the set is solid brass, and the Unlacquered Brass is a living finish that will darken and patina with handling rather than staying bright.

Emtek lists the Brisbane as residential. For a school corridor, a hospital wing or a high-traffic commercial opening, a Grade 1 commercial mortise lock is the right call: the Corbin Russwin ML2003 in the ML2000 Series is a Grade 1 classroom mortise for a 1-3/4 inch door, the Cal-Royal NM8050 is a Grade 1 entrance/office mortise with an auxiliary deadlatch, and the Hager 3810S in the 3800 Series is a Grade 1 passage mortise on a 2-3/4 inch backset. The Brisbane is meant for residential and light-use openings where the decorative brass trim matters.

The Brisbane mortise family uses the Schlage C keyway, so keyed members of the line will key into a Schlage C system alongside the rest of a building's cylinders. The 3019 itself is the dummy, non-keyed version, so it takes no cylinder at all; order the keyed function of the family for the doors that need to lock and keep the dummy on the inactive leaves.

The Schlage L0170 is the commercial answer: a Grade 1 heavy duty non-keyed half dummy trim in the L Series for a 1-3/4 inch door. If the dummy trim is going on an exit device rather than a mortise-prepped door, the Falcon MESC600DT is a dummy escutcheon lever trim for M9900 Series exit devices and carries a fire rating. Pick the Emtek Brisbane when the opening is residential and the decorative brass knob or crystal trim is the point.

A mortise dummy like the Brisbane installs into the same standard ANSI A115.1 mortise pocket as the working locks in the family, so on a pair of doors where the active leaf carries a mortise entrance set, the inactive leaf gets identical trim depth, projection and rose alignment. A surface dummy screws to the face of an undrilled door and is the cheaper route when the door has no mortise prep and never will. If the leaves have to look identical, prep them both and use the mortise dummy.

No. Both carry a dummy function, but they mount to different things. The Falcon MESC600DT is dummy escutcheon lever trim made for M9900 Series exit devices, so it belongs on a door that is running an exit device. The Emtek 3019 Brisbane is a brass mortise set prepped to standard mortise ANSI A115.1 door prep with a 2-1/2 inch or 2-3/4 inch backset. A door mortised for the Brisbane will not take the Falcon exit device trim, and the reverse is also true.

Only if you are also changing the door prep. The Emtek 3019 Brisbane uses standard mortise ANSI A115.1 prep, which is a pocket cut into the door edge. The Schlage PC10 is a Grade 1 non-keyed passage cylindrical lock with rose for 1-3/4 inch doors and uses a bored cylindrical prep instead. On a door already mortised, staying with a mortise product such as the Schlage PM010 Grade 1 passage latch mortise lock keeps the existing cutout.

A dummy set cannot latch or privacy-lock, so it does not suit a bath or bedroom door. Mortise privacy options include the Hager 3840S 3800 Series Grade 1 privacy mortise lock with a 2-3/4 inch backset for doors 1-3/4 inch to 2 inch, and the Cal-Royal NM8440 Grade 1 privacy mortise lockset with deadbolt for 1-3/4 inch doors. Both give the inside thumbturn function the Brisbane dummy does not have.

No. Electronic mortise locks are built to control an opening: the Schlage CO-100 is a standalone electronic mortise lock with a keypad reader in privacy function for 1-3/4 inch doors, and the TownSteel FME-2000 is a Grade 1 heavy duty classroom mortise lockset with RFID for 1-3/4 inch doors. The Emtek 3019 Brisbane is non-electronic dummy trim intended for the inactive leaf or a pull-only door, where there is no credential or latch to manage.

The Brisbane 3019 is a full dummy set with knob or lever trim and no bolt. Where only a bolt is wanted, the Sargent 4874 is a double cylinder mortise deadbolt with a 2-3/4 inch backset from the 4870 Series, and the Kaba Ilco 185 Series mortise lock is a deadbolt function supplied with no handing required. Neither carries operating trim, so pair with a pull if the door still needs something to grab.

The Emtek 3019 Brisbane is brass with contemporary decorative trim. Anti-ligature openings use different trim entirely: the TownSteel MRX-L-01 is a stainless steel Grade 1 heavy duty anti-ligature lever mortise lockset in passage function for 1-3/4 inch doors, the TownSteel MRX-A-01 is a Grade 1 heavy duty passage mortise lockset with satin stainless ligature resistant arch trim, and the Marks USA 5PDN is a Grade 1 hospital passage mortise push/pull paddleset that is ligature resistant and ADA compliant in satin stainless steel.

The Emtek 3019 Brisbane is UL 180 minute rated. Among mortise peers, the Falcon MA101 Grade 1 heavy duty passage mortise lock carries a fire rating, and the Schlage Electronics LEMD-GRW Grade 1 ENGAGE Series wireless mortise lock and the LEBMB-ADD mobile-enabled mortise lock are both rated at 3 hours. Confirm the rating against the label on the door assembly you are working on before you commit.

The Emtek 3019 Brisbane is a non-keyed dummy set specified with a Schlage C keyway for the family it belongs to, which matters when the rest of the opening keys alike. Where a facility keys on interchangeable cores instead, the Cal-Royal NM8080 is a Grade 1 storeroom mortise lockset with an interchangeable core option for 1-3/4 inch doors, and the Accentra 8805FL is a Grade 1 storeroom mortise lock in the 8800 Series. Match the keying system across the openings before you split brands.

ANSI F20 or F13 covers the Brisbane mortise entrance family. F20 is the entry function with a deadbolt thrown by the inside turn and retracted by key outside; F13 is the apartment/entrance variant. The 3019 is the dummy version of the set, so it carries the family's trim and prep without the working function.

They are not interchangeable. The Sargent 130KB is a standard duty mortise thumbturn from the 8200 Series and the Sargent 130W is a standard duty mortise thumbturn with a round backplate from the 7800 Series; both are small operating parts that fit an existing lock body. The Emtek 3019 Brisbane is a complete set with knob or lever trim, sold as a full assembly rather than a single turn piece.
