Emtek 2060 Keyed Patio Door Bolts
The Emtek 2060 is a keyed patio door bolt in the American Classic collection, constructed from solid brass. It is sold as a complete set and is available in four finishes: Silver, Bronze, White, and Black.
Specifications
- Model: 2060
- Material: Brass
- Lock Type: Tubular
- Keyed Function: Single Cylinder
- Lock Function: Entry
- Collection: American Classic
- Sold as a complete set
Finish Options
- Silver
- Bronze
- White
- Black
Manufacturer Resources
Emtek Knobsets nad Leversets Designs
Product Specs
- Subcategory:
- Patio Door Bolts
- Collection:
- Brass
- Product Type:
- Patio Door Bolts
- Product Group:
- Door Trim and Accessories
- Product Subgroup:
- Auxiliary and Rim Locks
- Commercial/Residential:
- Residential
- Series:
- Patio Door Bolts
- Theme:
- American Classic
- Electronic:
- No
- Keyed:
- Yes
- Lock Function:
- Entry
- Keyed Function:
- Single Cylinder
- Lock Type:
- Tubular
- MAP Policy:
- Yes
- Product Model:
- 2060
- Product Function:
- Entry
- Product Style:
- American Classic
- Product Material:
- Brass
- Product Category:
- Door Trim and Accessories
- Product Substrate:
- Brass
- Department:
- Door Hardware
Emtek EMTEK-206017 – Frequently Asked Questions
1) What is an Emtek keyed patio door bolt and where does it go on a sliding door?
The Emtek 2060 patio door bolt is an auxiliary bolt that mounts on a patio slider to lock the panel independently of the main handle set. It's a keyed entry function, so it throws and retracts with a key rather than a thumbturn on the outside. Emtek sells it as a complete set, so you're not sourcing a separate strike or bolt body.
2) Is the Emtek 2060 patio bolt single cylinder or double cylinder?
Single cylinder. One key cylinder, so it operates by key on one side only. That's the usual choice for a patio slider where you want an outside key but no key needed on the inside face.
3) Is the Emtek patio door bolt rated for commercial use?
No. Emtek lists the 2060 patio bolt as residential. For an apartment unit slider, a condo, or a single-family rental it's the right class of hardware. For a storefront or a commercial entry under real traffic, specify commercial-rated hardware instead.
4) Does the Emtek 2060 replace the main lock on a sliding patio door or is it an add-on?
It's an add-on. The 2060 is an auxiliary keyed bolt, meant to supplement the slider's existing latch, not replace it. Keep the primary handle set in place and use the bolt as the secondary lock point. If you're looking to replace the whole slider latch mechanism, this isn't that part.
5) What finishes do the Emtek keyed patio door bolts come in?
Four: silver (206011), bronze (206012), white (206016), and black (206017). Silver and bronze read as metal tones against an aluminum or bronze-anodized slider; white and black are the ones that disappear on painted vinyl or clad frames. Pick by what the door frame already is, since this bolt sits out on the face of the panel.
6) Can I key the Emtek patio bolt to match my other Emtek door locks?
The 2060 is a keyed single-cylinder bolt, so it takes a key on the exterior. Whether it can be keyed alike with the rest of your doors depends on the cylinder and keyway on those locks, so match keyway before you assume a fleet of units will run one key. Property managers standardizing a building should confirm the keying arrangement at order time rather than after installation.
7) What is the Emtek 2060 patio bolt made of, and will it hold up on an exterior door?
Brass, both the material and the substrate. Brass is the standard body material for exterior residential door hardware because it doesn't rust the way plain steel does. The finish over it is what determines how it weathers, and you have four to choose from.
8) Is the Emtek patio door bolt electronic or does it need wiring?
Purely mechanical. No power, no wiring, no battery. It installs as a standalone key-operated bolt, which is why it works on a slider where there's no way to run cable into a moving panel.
