Emtek Stainless Steel Long Door Pulls
Built for commercial and high-traffic applications, Emtek's Stainless Steel Long Door Pulls deliver a clean, contemporary profile in solid stainless steel. Available in Round and Square bar profiles across four lengths — 24", 36", 48", and 72" — with three mounting configurations and four finish options, these pulls are a single-source solution for storefronts, glass doors, office entries, and multi-family common areas.
Key Features
- Solid stainless steel construction for strength, corrosion resistance, and long-term durability
- Round or Square bar profile — specify the look that matches your project
- Three mounting options: Standard Thru-Bolt with decorative caps, Back-to-Back (BTB) for double-door applications, or Concealed Surface (CS) mount for a clean face
- Optional 1-1/2" diameter, 1/8" thick disc base included with standard mount
- Reversible handing — installs on any door swing
- Covered by Emtek's limited lifetime warranty
Specifications
- Material: Solid Stainless Steel
- Profile: Round or Square
- Available Lengths: 24", 36", 48", 72"
- Width: 1-1/8"
- Projection: 2-5/8"
- Door Thickness: 1-3/4" – 2-1/4"
- Handing: Reversible
- Mount: Standard Thru-Bolt with Decorative Caps | BTB Back-to-Back | CS Concealed Surface
Available Finishes
- Brushed Stainless Steel (SS)
- Polished Stainless Steel (PSS)
- Flat Black (US19)
- Satin Brass Stainless Steel – Lifetime (SSPVD4)
Resources
Download the Emtek Door Pulls Dimensions & Technical Specifications (PDF) for full dimensional drawings and installation details.
Manufacturer Resources
Emtek Door Pulls Dimensions
Product Specs
- Subcategory:
- Pulls and Push Plates
- Collection:
- Stainless Steel
- Product Type:
- Door Pulls
- Product Group:
- Door Trim and Accessories
- Product Subgroup:
- Door Pulls, Push and Pull Plates
- Commercial/Residential:
- Commercial
- Series:
- Stainless Steel Long Door Pulls
- Theme:
- Contemporary
- Electronic:
- No
- Handle Type:
- Door or Appliance Pull
- Keyed Function:
- Non-Keyed
- MAP Policy:
- Yes
- Tags:
- emtek door pulls, modern door pulls
- Product Style:
- Contemporary
- Product Material:
- Stainless Steel
- Product Category:
- Door Trim and Accessories
- Product Substrate:
- Stainless Steel
- Department:
- Door Hardware
Emtek 86189-US19 – Frequently Asked Questions
1) Will an Emtek stainless steel long door pull fit a 1-3/4 inch commercial door?
Yes on 1-3/4 inch, and up to 2-1/4 inch. The Emtek Stainless Steel Long Door Pulls are specified for a door thickness range of 1-3/4 to 2-1/4 inches, which covers the standard commercial leaf as well as the heavier clad and insulated entries above it. Because the standard configuration is a thru-bolt, the actual thickness of the leaf is what the mounting hardware has to match, so measure the door rather than assuming 1-3/4 inch on an older or built-up opening.
2) My doors are 1-3/8 inch thick. Can I use Emtek's stainless long door pulls on them?
No. Emtek's stainless long pulls start at 1-3/4 inch door thickness and run to 2-1/4 inch, so a 1-3/8 inch leaf falls under the range and the thru-bolt mounting will not land correctly. For that thickness, the Deltana OHP620 off-set handle pull is sold as a back-to-back set with a stated door thickness range of 1-1/8 to 1-3/8 inches, which is the band a 1-3/8 inch door sits in. 1-3/8 inch is the common older interior and residential thickness, so this comes up often on retrofit work in converted buildings.
3) What is the difference between the Standard, BTB and CS mounting options on Emtek long door pulls?
Three ways to attach the pull, and you pick one at order time. Standard is a thru-bolt with decorative caps, and it comes with the optional 1-1/2 inch diameter, 1/8 inch thick disc base. BTB is the back-to-back configuration, which Emtek calls out for double-door applications. CS is concealed surface mount, where the fasteners do not show on the face of the pull. The mounting choice drives how the door gets prepped, so settle it before the doors are drilled, not after.
4) How much hand clearance is there behind an Emtek stainless long door pull?
About 1-1/2 inches of grip room. The pull projects 2-5/8 inches off the face of the door and the bar itself is 1-1/8 inches wide, which leaves roughly 1-1/2 inches between the back of the bar and the door. That is the same clearance Ives publishes on its 8102HD heavy duty straight pull, so it grabs like a normal commercial pull, including with a work glove on. Worth checking against anything mounted nearby, since 2-5/8 inches of projection is what sticks into the traffic path when the door stands open.
5) What is the closest cross-brand equivalent to an Emtek stainless steel round long door pull?
The Emtek Stainless Steel Long Door Pulls in the Round profile are solid stainless bar pulls measuring 1-1/8" wide with a 2-5/8" projection, offered in 24", 36", 48", and 72" lengths with standard thru-bolt mounting and decorative caps. The nearest straight round-bar commercial equivalents are the Ives 8103HD, a heavy duty straight door pull with a 1" round bar and through bolt mounting, and the Ives 8102HD, a heavy duty straight pull with a 3/4" round bar and 1-1/2" clearance. All three are straight bar pulls fastened through the door face; the difference is bar size and the Emtek's four fixed lengths against the Ives heavy duty bar sizes.
6) My door is 1-3/8" thick and I need a back-to-back pull set. Will an Emtek long door pull work?
The Emtek Stainless Steel Long Door Pulls are built for doors 1-3/4" to 2-1/4" thick, including the BTB back-to-back configuration, so a 1-3/8" door falls below that range. For a door in that thinner band, the Deltana OHP620 off-set handle pull is sold as a back-to-back set with a door thickness range of 1-1/8" to 1-3/8". The OHP620 is an offset handle pull rather than a straight bar, so the appearance changes along with the thickness fit.
7) Do I have to order an Emtek long door pull handed for a left or right swing?
No handing to call out. The stainless long pulls are reversible and go on either swing, so one part number covers left hand and right hand openings and you can stock a single spare for a building. What does have to be right on the order is the door thickness, since the pull mounts through the door and is built for a 1-3/4 to 2-1/4 inch range, plus the profile, finish, length and mounting configuration.
8) I need a door pull length other than 24, 36, 48 or 72 inches. What are my options?
Four fixed lengths on the Emtek stainless long pulls: 24, 36, 48 and 72 inches, with nothing in between. If the opening genuinely needs an off size, the ABH AB3330 series offset round end pull is offered with custom length options. Before going custom, check whether the 72 inch will do the job on a full-height leaf, since it is the tallest of the Emtek run and most storefront and glass entry work lands on one of the four standard sizes.
9) Can I standardize Emtek stainless long pulls across every entry in a building with different door sizes?
That is what the range is set up for. Lengths run 24, 36, 48 and 72 inches, the bar comes as a Round or a Square profile, and there are four finishes: Brushed Stainless Steel (SS), Polished Stainless Steel (PSS), Flat Black (US19), and Satin Brass Stainless Steel Lifetime (SSPVD4). Spec one profile and one finish for the property, then order the length each opening calls for, and the lobby, the office entries and the common-area doors all read as one hardware family. Emtek lists the line as commercial, so it is the right traffic level for shared entries.
10) I want an offset door pull rather than a straight bar. What should I look at instead of the Emtek long pull?
Emtek's stainless long pulls are straight bars only, Round or Square, so an offset shape means a different product. The Ives 8145EZHD is a 45 degree offset pull that Ives lists as ADA compliant in its EZ series with heavy duty mounting hardware. The Ives 8169 is a C style offset solid pull at 1 inch diameter. The ABH AB3310 is an offset flat end pull for surface mount, and the ABH AB3330 is an offset round end version with custom lengths. For a 24 inch offset in a back-to-back set, Deltana offers the SSPOBB24 modern offset and the SSPORBB24 round offset.
11) Does the Emtek stainless long door pull take a lock cylinder or tie into access control?
Non-keyed and non-electronic. The Emtek stainless long pull is grip only, with no cylinder prep and nothing to wire, so the locking on that opening still comes from the exit device, mortise lock or electric strike behind it. If what you actually need is a pull with a cylinder in it for a night latch function, the Cal-Royal PUL-175 night latch cylinder pull is that part, 3-1/2 inch height in stainless steel construction.
12) Is a Trimco push plate an alternative to an Emtek long door pull?
No. The Emtek Stainless Steel Long Door Pulls are grab bars standing 2-5/8" off the door face in 24" to 72" lengths. The Trimco 1001-1 is a heavy duty push plate measuring 3" x 12" and the Trimco 1041 is a half-round push plate measuring 8" x 16" — flat plates that protect the door face on the push side and give nothing to grip. The Trimco 1070 Series classic push/pull plates at 3-1/2" x 15" are the plate-format product that includes a pull. A push plate and a long bar pull are commonly specified on opposite faces of the same door, not as one in place of the other.
13) I need something shorter than a 24-inch pull for an office door. What is a smaller alternative to the Emtek long pull?
The Emtek Stainless Steel Long Door Pulls start at 24" and run up through 36", 48", and 72". For a shorter contemporary pull, the Deltana SSP1210 is a 12" contemporary pull mounted on a single side. That covers a door where a full-height bar is more pull than the opening needs, while keeping a contemporary bar look.
14) What is the alternative if the 1-1/8" Emtek bar feels too thick for the hand?
The Emtek Stainless Steel Long Door Pulls use a 1-1/8" wide bar in either the Round or the Square profile. For a slimmer grip in solid stainless, the ABH AB7200 is a flat end pull handle of 7/8" diameter with through-bolt mounting, and the ABH AB3300 is a straight flat end commercial door pull of 1.00" diameter. Both are straight commercial pulls through-bolted to the door, sized between 7/8" and 1" against the Emtek 1-1/8" section.
15) For a pair of doors needing 24-inch back-to-back pulls, how does the Emtek compare with the Deltana back-to-back sets?
The Emtek Stainless Steel Long Door Pulls are offered at 24" in the BTB back-to-back configuration, in Round or Square straight bar profile, for doors 1-3/4" to 2-1/4" thick. The Deltana SSPOBB24 is a 24" back-to-back modern offset door pull set and the Deltana SSPORBB24 is a 24" back-to-back round offset door pull set. All three give a matched pull on both faces at 24"; the Emtek runs as a straight bar while both Deltana sets are offset pulls.
16) Which pull should I specify when I do not want visible thru-bolts on the face of the door?
The Emtek Stainless Steel Long Door Pulls offer a CS concealed surface mount alongside the standard thru-bolt with decorative caps and the BTB back-to-back set, so the concealed surface version keeps the opposite face clean. Among the commercial alternatives, the ABH AB3310 is an offset flat end door pull handle in a commercial grade surface mount, while the Ives 8103HD and the ABH AB7200 are both through-bolt pulls that carry fasteners to the other side. Match the mounting to whether the back of the door can be drilled and whether hardware may show there.
17) Will Emtek stainless long door pulls hold up on an exterior storefront entry?
Solid stainless steel is the whole point of the line. Emtek lists both the material and the substrate as stainless steel, not plated zinc over a core, which is what gives it corrosion resistance on a weather-exposed entry. The line is classified commercial rather than residential, so it is built for the cycle count a storefront, office entry or multi-family common-area door sees rather than a house front door.
18) Can a Cal-Royal PUL-175 be used in place of an Emtek long door pull?
They do different jobs. The Emtek Stainless Steel Long Door Pulls are non-keyed bar pulls, 24" to 72", for pulling the door open. The Cal-Royal PUL-175 is a night latch cylinder pull of 3-1/2" height in stainless steel construction — a short pull that mounts at the cylinder on a night latch installation. If the requirement is a graspable bar across the door, the PUL-175 is not a substitute for it.
19) Is an Emtek long door pull the right choice for a restroom door?
The Emtek Stainless Steel Long Door Pulls are solid stainless commercial pulls suited to storefronts, glass doors, office entries, and multi-family common areas. For a restroom opening specifically, the Trimco 1035 Ultimate Restroom Pull is the heavy duty pull built for that application. The Emtek remains a straight bar pull in four lengths from 24" to 72"; the 1035 is purpose-made for the restroom door.
