Hager 960B Square Tip Pull- BTB Mounting

Hager 960B Square Tip Door Pull with BTB Mounting - 16" Commercial Grade

(No reviews yet) Write a Review

Model: 960B US4
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,117.38
$997.75
Adding to cart… The item has been added
Bulk Pricing:
Buy in bulk and save

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 11 - 16 and get 2% off
  • Buy 17 - 21 and get 4% off
  • Buy 22 - 32 and get 6% off
  • Buy 33 or above and get 8% off
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Hager 960B Square Tip Door Pull with BTB Mounting - 16" Commercial Grade

Professional Square Tip Door Pull Solution

The Hager 960B Square Tip Door Pull delivers commercial-grade performance with BTB (back-to-back) mounting for glass doors and applications requiring through-door installation. This 16" pull features a 1" diameter grip with 1-3/4" clearance and 12" center-to-center spacing. Constructed from durable brass and bronze materials with a 3-1/4" projection, the 960B provides reliable operation and ADA compliant accessibility.

Professional Features & Benefits

  • Commercial Door Pull Dimensions: 16" height with 1" diameter grip and 1-3/4" pull clearance for comfortable operation.
  • BTB Mounting System: Back-to-back mounting configuration with included fasteners for secure glass door installation.
  • Heavy-Duty Construction: Brass and bronze materials provide exceptional durability for high-traffic commercial applications.
  • ADA Compliant Design: Meets accessibility requirements with proper clearance and ergonomic grip dimensions.
  • Professional Spacing: 12" center-to-center mounting provides balanced door operation and visual appeal.
  • Multiple Finish Options: Available in US3, US4, US10B, US15A, US19, US26, and US26D finishes to match existing hardware.
  • Complete Pull Set: Includes pair of 960P pulls with all necessary fasteners for BTB mounting applications.

Technical Specifications

  • ADA Compliant: Yes
  • Base Diameter: 1-1/4" (32 mm)
  • Box Quantity: 1
  • Case Quantity: 12
  • Clearance: 1-3/4"
  • Commercial/Residential: Commercial
  • Finishes: US3, US4, US10B, US15A, US19, US26, US26D
  • Height: 16" (406 mm)
  • Material: Brass, Bronze
  • Notes: 960Bis pair of 960Pwith fasteners for BTB mounting
  • Projection: 3-1/4" (83 mm)
  • Pull Clearance: 1-3/4" (45 mm)
  • Pull CTC: 12" (305 mm)
  • Pull Diameter: 1" (25 mm)
  • Subcategory: Door Pulls, Push and Pull Plates

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness and material compatibility for BTB mounting applications.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on both sides of the door for proper alignment.
  3. Prepare door by drilling required through-holes as specified in manufacturer instructions for BTB fastener installation.
  4. Install mounting hardware and secure both pulls to opposite sides of door using provided BTB fasteners per manufacturer torque specifications.
  5. Adjust pull alignment to ensure proper positioning and verify 1-3/4" clearance is maintained for ADA compliance.
  6. Test pull operation to verify secure mounting and smooth operation. Refer to manufacturer documentation for complete installation details and finish care instructions.

Professional Applications

  • Commercial Office Buildings
  • Retail Store Entrances
  • Healthcare Facility Doors
  • Educational Institution Access Points
  • Hotel and Hospitality Venues
  • Government and Municipal Buildings
  • Glass Door Storefronts

Why Choose Hager Quality?

Hager door pulls deliver professional-grade reliability with brass and bronze construction engineered for demanding commercial applications. The 960B model provides ADA compliant accessibility with durable materials and precise manufacturing for consistent performance. Designed for high-traffic environments where dependable door hardware operation is essential.

Manufacturer Resources

Product Template

Product Specs

Product Group:
Door Trim and Accessories
Product Subgroup:
Door Pulls, Push and Pull Plates
Subcategory:
Door Pulls, Push and Pull Plates
Product Type:
Door Pulls
Commercial/Residential:
Commercial
Clearance:
1-3/4"
ADA Compliant:
Yes
Product Model:
960B
Product Projection:
3-1/4"
Product Substrate:
Brass, Bronze
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Hager 960B US4 – Frequently Asked Questions

1) What are the mounting hole centers on the Hager 960B pull?
12 inches center to center, over a 16 inch overall pull height. That CTC is what your through-holes get drilled to, so if you're matching an existing prep on a storefront or a pair of glass doors, the prep has to be on 12 inch centers.
2) Can I use this Hager pull on a glass storefront door?
Yes. The 960B uses back-to-back through-door fasteners, which is exactly the mounting method glass doors take since there's nothing to thread into. Mark both faces from the template, drill the through-holes on 12 inch centers, then draw the two pulls together with the supplied BTB fasteners.
3) What is the closest back-to-back door pull alternative to the Hager 960B?
The Hager 960B ships as a pair of 960P pulls with fasteners for back-to-back mounting, 16 inch height, 1 inch grip diameter and 1-3/4 inch clearance in brass and bronze. For another back-to-back set, the Deltana SSPOBB24 is a 24 inch back-to-back modern offset pull and the Deltana SSPORBB24 is a 24 inch back-to-back round offset pull, both longer and offset rather than straight with square tips. The Sure-Loc PL-2KN is a double-sided knurled long pull if a textured grip is wanted instead of a smooth round bar.
4) How does the Hager 960B compare with the Ives 8103HD?
Both are straight commercial pulls with a 1 inch round grip. The Hager 960B has square tips, 16 inch overall height, 12 inch center-to-center, 1-3/4 inch clearance and a 3-1/4 inch projection, in brass and bronze. The Ives 8103HD is a heavy duty straight pull, 1 inch round, with through bolt mounting. The Ives 8102HD is the same straight family with a 3/4 inch round bar and 1-1/2 inch clearance if a slimmer grip suits the door better.
5) The opening needs an offset pull rather than a straight one. What are the options next to the Hager 960B?
The Hager 960B is a straight square tip pull with a 3-1/4 inch projection and 12 inch center-to-center spacing. If the door calls for an offset shape, the Ives 8145EZHD is a 45 degree offset pull with heavy duty mounting hardware and ADA compliant design, the Ives 8169 is a C style offset solid pull with a 1 inch diameter grip, and the ABH AB3310 is an offset flat end pull for surface mount. The ABH AB3330 series is an offset round end pull available in custom lengths.
6) I need a back-to-back pull for a thin 1-3/8 inch door. Does the Hager 960B suit, or is there another option?
The Hager 960B is a commercial back-to-back set in brass and bronze with 1-3/4 inch clearance and a 16 inch height. For a set specifically rated to thinner doors, the Deltana OHP620 is an off-set handle pull supplied as a back-to-back set for door thicknesses of 1-1/8 inch to 1-3/8 inch. Confirm the drilled through-hole layout matches the door you are working with in either case.
7) How far does the Hager 960B stick out from the door?
Projection is 3-1/4 inches from the door face to the outside of the grip, with 1-3/4 inches of that being open hand clearance and a 1-1/4 inch base diameter at the posts. Worth checking on a narrow vestibule or where a door swings back against a wall, since the pull projects on both faces in a BTB set.
8) What finishes does the Hager 960B square tip pull come in?
Six finishes are orderable: 605 bright brass, 606 satin brass, 613 oil-rubbed satin bronze, 620 antique nickel, 625 bright chrome, and 626 satin chrome. The pulls are brass and bronze underneath, so the plated and oiled finishes sit on a solid non-ferrous base rather than steel.
9) What other back-to-back door pull sets could I use instead of the Hager 960B?
If you want a straight round-bar pull with through-bolts rather than square tips, the Ives 8103HD is a 1 inch round heavy duty pull with through-bolt mounting, and the ABH AB7200 is solid stainless at 7/8 inch diameter with through-bolt mounting. For offset rather than straight, Deltana makes the SSPOBB24 and SSPORBB24 as 24 inch back-to-back offset sets. The Deltana OHP620 offset BTB set is limited to doors 1-1/8 to 1-3/8 inches thick, so it isn't a fit for standard 1-3/4 inch commercial doors.
10) Do I need a push plate on the other side if I use the Hager 960B?
No. The 960B puts a pull on both faces of the door, which is the usual setup for a double-acting or pull-pull opening. If your opening is push on one side and pull on the other, you'd use a single pull plus a push plate instead, for example a Trimco 1001-1 heavy duty push plate at 3 by 12 inches or a Trimco 1070 Series push/pull plate at 3-1/2 by 15 inches.
11) Is a stainless steel pull available instead of the brass and bronze Hager 960B?
The Hager 960B is built in brass and bronze and offered in finishes including 605 bright brass, 606 satin brass, 613 satin bronze oil-rubbed, 620 antique nickel, 625 bright chrome and 626 satin chrome. If solid stainless is preferred, the ABH AB7200 is a solid stainless steel flat end pull handle with a 7/8 inch diameter grip and through-bolt mounting, and the Cal-Royal PUL-175 is stainless steel construction.
12) Which products look like substitutes for the Hager 960B but will not do the same job?
The Hager 960B is a 16 inch grip pull sold as a back-to-back pair for through-door mounting. Push and pull plates are not interchangeable with it: the Trimco 1001-1 is a 3 inch by 12 inch heavy duty push plate, the Trimco 1041 is an 8 inch by 16 inch half-round push plate, and the Trimco 1070 series is a 3-1/2 inch by 15 inch push/pull plate. The Cal-Royal PUL-175 is a 3-1/2 inch night latch cylinder pull, which serves a cylinder opening rather than a full-length door grip, and the Trimco 1035 is a restroom-specific pull.
13) Is there a template for drilling the door for the Hager 960B?
Yes, Hager publishes a 960P/960B dimensional drawing you can work from for hole locations. Mark both faces of the door off the template so the two pulls line up before you drill the through-holes, since a BTB set has no adjustment once the holes are bored.
