Ives 046XY Half Surface Geared Continuous Hinge with XY Adjustability for 450 lb Doors

(No reviews yet) Write a Review

Model: IVE-046XY-83-628
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$828.40
$480.16
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Ives 046XY Half Surface Geared Continuous Hinge with XY Adjustability for 450 lb Doors

Professional Half Surface Continuous Hinge for Retrofit and New Construction

The Ives 046XY Half Surface Geared Continuous Hinge delivers professional-grade performance for doors weighing up to 450 pounds without reinforcing, or 600 pounds with reinforcing. This wide door leaf design features a 1-7/8" frame leaf depth and 9/32" door inset, with patented center-loaded interlocking bearing design for extended life. ANSI 156.26 Grade 1 certified and UL10C rated for 90-minute fire applications, this non-handed hinge provides XY (lateral and vertical) adjustability during installation.

Professional Features & Benefits

  • Heavy-Duty Load Capacity: Supports doors up to 450 pounds without reinforcing, 600 pounds with reinforcing for demanding commercial applications.
  • Precision Dimensions: 1-7/8" frame leaf depth with 9/32" door inset designed for wide door leaf applications and retrofit installations.
  • Patented Bearing Design: Center-loaded, interlocking bearing system provides smooth operation and extended service life in high-traffic environments.
  • XY Adjustability: Lateral and vertical adjustment capability while hanging the door simplifies installation and ensures proper alignment.
  • Safety Enhancement: Eliminates pinch points between cover and door while preventing finger entrapment between hinge sections.
  • Retrofit Compatibility: Extended frame guidance lip covers existing heavy-weight architectural hinge preparations for seamless upgrades.
  • Professional Certifications: ANSI 156.26 Grade 1 and UL10C 90-minute fire rating ensure code compliance for commercial applications.
  • Manufacturer Warranty: Limited lifetime warranty provides long-term confidence and protection for your investment.

Technical Specifications

  • ANSI/BHMA: ANSI 156.26
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Hand Direction: Non-Handed
  • Door Weight: 450
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Model: 046XY
  • Product Size: 48"
  • Product Subgroup: Continuous Hinges
  • Product Type: Continuous Geared Hinges
  • Subcategory: Hinges and Pivots

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Ives Quality?

Ives continuous hinge products deliver professional-grade reliability with patented center-loaded interlocking bearing design rated for doors up to 450 pounds without reinforcing. Limited lifetime warranty coverage provides added confidence for demanding commercial applications. Engineered for high-use and high-traffic doors where dependable performance and constant door alignment are essential.

Product Specs

Product Group:
Door Hinges and Pivots
Subcategory:
Hinges and Pivots
Product Subgroup:
Continuous Hinges
Product Type:
Continuous Geared Hinges
ANSI/BHMA:
ANSI 156.26
Door Weight:
450
Commercial/Residential:
Commercial
Product Model:
046XY
Door Hand Direction:
Non-Handed
Product Size:
48"
Product Category:
Door Hinges and Pivots
Department:
Door Hardware

Ives IVE-046XY-83-628 – Frequently Asked Questions

1) Will the Ives 046XY continuous hinge carry a 400 lb door without reinforcing?
Yes. The 046XY half surface geared continuous hinge handles doors up to 450 pounds with no reinforcing, and up to 600 pounds when the door is reinforced. That covers most heavy commercial openings, lead-lined doors, and high-traffic entries where butt hinges keep sagging.
2) Do I have to order a left hand or right hand Ives 046XY hinge?
Handing is not a factor. The 046XY is non-handed, so one part number works on a left hand or right hand opening. On top of that it offers XY adjustment, lateral and vertical, while the door is hanging, so you can pull the door into alignment on site instead of shimming.
3) Can the Ives 046XY be installed over an existing butt hinge prep without patching the frame?
That is what the half surface design is for. The 046XY has an extended frame guidance lip that covers existing heavy weight architectural hinge preps, so you can pull three worn butts off a frame and mount the continuous hinge over the cutouts. Frame leaf depth is 1-7/8 inches with a 9/32 inch door inset, so check the strike side clearance before you commit.
4) Is the Ives 046XY hinge approved for a 90 minute fire rated door?
The 046XY is UL10C rated for 90 minute fire applications and certified to ANSI 156.26 Grade 1. For an institutional buyer standardizing on fire rated openings, that pairs with a labeled door and frame assembly rated 90 minutes or less.
5) What finishes does the Ives 046XY geared continuous hinge come in?
Three anodized finishes: 628 clear anodized aluminum, 710 dark bronze anodized, and 711 black anodized. All three are available in every length, so a property manager matching a run of storefront or aluminum entrances can hold one finish across 83, 85, 95 and 119 inch doors.
6) Half surface versus full surface continuous hinge, which one do I need?
Half surface means the frame leaf mortises into the frame while the door leaf mounts to the face of the door. The 046XY is the half surface version, with a 1-7/8 inch frame leaf depth and a wide door leaf. Pick it when the frame is already prepped for butt hinges and you want to cover that prep. Go full surface instead when the frame cannot be mortised at all, such as a wrapped or previously damaged frame where both leaves need to sit on the surface.
7) Is a geared continuous hinge worth it over three heavy weight butt hinges on a high traffic door?
On a door that gets abused, yes. The 046XY spreads the load down the full height of the opening rather than through three points, so the door stays in alignment and the frame does not tear out. The patented center loaded interlocking bearing design carries the weight, and the hinge eliminates the pinch point between cover and door plus finger entrapment between hinge sections, which matters in schools and healthcare.
8) Where can I get the install template for the Ives 046XY XY adjustable hinge?
Ives publishes installation instructions for the XY surface continuous hinge, and the Ives full line architectural hardware catalog carries the mounting details. Use the manufacturer template to lay out the fastener holes on the door face and frame before drilling, since the XY adjustment corrects alignment but not a mislocated hole line.
