Ives 054XY Half Surface Continuous Geared Hinge with XY Adjustability for 450 lb Doors

(No reviews yet) Write a Review

Model: IVE-054XY-83-628
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$601.60
$348.72
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Ives 054XY Half Surface Continuous Geared Hinge with XY Adjustability for 450 lb Doors

Professional Half Surface Continuous Hinge for Retrofit and New Construction

The Ives 054XY Half Surface Continuous Geared Hinge delivers professional-grade performance for doors weighing up to 450 pounds without reinforcing or 600 pounds with reinforcing. This narrow door leaf design features a 1-7/8" frame leaf depth and patented center-loaded, interlocking bearing design with XY (lateral and vertical) adjustability for precise installation. The non-handed configuration accommodates custom cut lengths with standard lengths available in 83", 85", 95", and 119" options, making it ideal for gasketing and weatherstripping applications.

Professional Features & Benefits

  • Heavy-Duty Weight Capacity: Supports doors up to 450 pounds without reinforcing and 600 pounds with reinforcing for demanding commercial applications.
  • XY Adjustability: Patented lateral and vertical adjustment capability while hanging the door ensures precise alignment and smooth operation.
  • Narrow Door Leaf Design: 1-7/8" frame leaf depth with 1/8" door inset optimizes space utilization and accommodates gasketing applications.
  • Retrofit-Ready Construction: Extended frame guidance lip covers existing heavy weight architectural hinge preparations for seamless retrofit installations.
  • Safety-Enhanced Design: Eliminates pinch points between cover and door while preventing finger entrapment through continuous hinge spacing elimination.
  • Patented Bearing System: Center-loaded, interlocking bearing design with rounded gear configuration provides extended life and smooth operation over time.
  • Flexible Length Options: Non-handed design allows custom cutting with standard lengths of 83", 85", 95", and 119" to accommodate various door heights.
  • ANSI Certified Performance: Meets ANSI 156.26 Grade 1 standards and UL10C 90-minute fire rating for code compliance and reliability.

Technical Specifications

  • ANSI/BHMA: ANSI 156.26
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Hand Direction: Non-Handed
  • Door Weight: 450
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Model: 054XY
  • Product Size: 48"
  • Product Subgroup: Continuous Hinges
  • Product Type: Continuous Geared Hinges
  • Subcategory: Hinges and Pivots

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Ives Quality?

Ives continuous geared hinges deliver professional-grade reliability with patented center-loaded, interlocking bearing design rated for doors up to 450 pounds without reinforcing. ANSI 156.26 Grade 1 certification and UL10C 90-minute fire rating ensure code compliance and long-term performance. Engineered for demanding commercial applications where dependable performance and door alignment are essential.

Product Specs

Product Group:
Door Hinges and Pivots
Subcategory:
Hinges and Pivots
Product Subgroup:
Continuous Hinges
Product Type:
Continuous Geared Hinges
ANSI/BHMA:
ANSI 156.26
Door Weight:
450
Commercial/Residential:
Commercial
Product Model:
054XY
Door Hand Direction:
Non-Handed
Product Size:
48"
Product Category:
Door Hinges and Pivots
Department:
Door Hardware

Ives IVE-054XY-83-628 – Frequently Asked Questions

1) Will the Ives 054XY continuous hinge cover the old hinge cutouts when I retrofit a door that had butt hinges?
That's what the extended frame guidance lip is for. The 054XY half surface geared hinge covers existing heavy weight architectural hinge preparations on the frame, so you don't have to fill and refinish the old mortises when you swap butt hinges out for a continuous hinge. The frame leaf runs 1-7/8 inches deep and the door leaf sits with a 1/8 inch door inset.
2) How heavy a door can the Ives 054XY hinge carry?
Up to 450 pounds with no reinforcing, and up to 600 pounds if the door and frame are reinforced. That covers most commercial hollow metal and heavy wood doors, and it is the number to check first on lead-lined, insulated, or oversized doors where weight is the reason butt hinges failed in the first place.
3) Do I need to order a left hand or right hand version of the Ives 054XY?
No handing to specify. The 054XY is non-handed, so one part number works on a left hand or right hand opening, and on a pair of doors you order two of the same hinge. For a property manager standardizing across a building, that means a single SKU per length and finish instead of a handed pair.
4) Can I use the Ives 054XY on a 90 minute fire rated opening?
Yes. The 054XY carries a UL10C 90 minute fire rating and meets ANSI 156.26 Grade 1. For an institutional or MRO buyer specifying across a facility, those are the two lines that matter on the hardware schedule for rated corridor and stairwell doors.
5) What does the XY adjustability on the Ives 054XY actually do on the job?
It lets you move the door laterally and vertically while it is hanging, rather than pulling the hinge and re-shimming. On a racked frame or an existing opening that has settled, that is how you close up an uneven gap and get the door to meet the stop without touching the frame. It is the main reason to pick the XY version over a fixed continuous hinge.
6) Should I use a half surface continuous hinge like the Ives 054XY or a full surface one?
Half surface means the frame leaf mounts to the face of the frame and the door leaf mortises into the door edge, so the door has to be prepped. That is the choice when you want the narrower 1-7/8 inch frame leaf profile, room for gasketing and weatherstripping, and coverage of old frame hinge prep. A full surface hinge mounts entirely on the faces of both door and frame and needs no door edge prep, which is the one to use when you cannot machine the door.
7) Will the Ives 054XY leave room for weatherstripping and gasketing on the hinge side?
Yes, that is one of the reasons for the narrow door leaf. The 1-7/8 inch frame leaf depth and 1/8 inch door inset keep the hinge out of the way of perimeter gasketing, which matters on smoke rated and exterior openings where the seal has to run continuous up the hinge jamb.
8) What finishes does the Ives 054XY half surface hinge come in, and will it match my storefront?
Three anodized aluminum finishes: 628 clear anodized, 710 dark bronze anodized, and 711 black anodized. All three are offered in every standard length, so the 83, 85, 95 and 119 inch sizes can be matched across a building. Clear anodized 628 is the usual match for aluminum storefront, and 710 dark bronze for bronze storefront systems.
9) Is a continuous geared hinge like the Ives 054XY safer for a school or daycare door than butt hinges?
It removes the gaps butt hinges leave between leaves, which is where fingers get caught on the hinge side, and the cover-to-door design has no pinch point. On high-traffic educational and healthcare openings that is usually the reason the continuous hinge gets specified over three or four butt hinges.
10) Why does a continuous hinge hold up better than butt hinges on a high traffic commercial door?
Load is spread over the full height of the door instead of concentrated at three or four points, so the frame and door edge don't wear out at the hinge locations. The 054XY uses a patented center-loaded interlocking bearing with a rounded gear profile, and it is rated commercial, ANSI 156.26 Grade 1. On doors that sag, drag, or tear out their hinge screws, that is the fix.
11) How do I write the part number for an Ives 054XY hinge on a purchase order?
Ives model 054XY, then length, then finish. A 95 inch dark bronze anodized unit is 054XY-95-710; an 83 inch clear anodized is 054XY-83-628. There is no handing digit because the hinge is non-handed, so length and finish are the only two things to specify.
