Leviton AFTR1 Tamper-Resistant AFCI Receptacle, 15-Amp 125-Volt NEMA 5-15R Decora SmartlockPro

Leviton AFTR1 Tamper-Resistant AFCI Receptacle, 15-Amp 125-Volt NEMA 5-15R Decora SmartlockPro

(No reviews yet) Write a Review

Model: AFTR1-W
Selected Color is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$40.13
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Leviton AFTR1 Tamper-Resistant AFCI Receptacle

The Leviton AFTR1 Residential Grade Outlet Branch Circuit AFCI Receptacle is engineered to deliver reliable arc-fault protection right at the outlet, combining tamper-resistant shutters with Decora SmartlockPro styling and terminal technology. Rated 15-Amp, 125-Volt with a NEMA 5-15R configuration, this receptacle is built for standard residential branch circuits where Outlet Branch Circuit AFCI protection is required by code. The Decora-profile face gives it a clean, modern look that blends into any room, while the SmartlockPro terminal design is intended to support a secure, dependable wire connection during installation. This listing is available in Ivory and White finishes, letting homeowners and electricians match existing wall plates and trim throughout a residence.

Key Features

  • Electrical Rating: 15-Amp, 125-Volt rating suited to standard residential branch circuits and general-purpose household loads.
  • Receptacle Configuration: NEMA 5-15R configuration accepts common two-pole, three-wire grounding plugs used throughout residential wiring.
  • Outlet Branch Circuit AFCI Protection: Built-in Arc-Fault Circuit Interrupter technology at the outlet is designed to help detect and interrupt dangerous arcing conditions on the branch circuit, supporting fire-safety code requirements.
  • Residential Grade Tamper-Resistant Design: Integrated tamper-resistant shutters help block insertion of foreign objects into the receptacle openings, an important child-safety feature in living spaces.
  • Decora Styling: The Decora face design offers a sleek, rectangular profile that coordinates with Decora-style wallplates and switches for a coordinated look throughout the home.
  • SmartlockPro Terminal Technology: SmartlockPro connection technology is engineered to support a secure, code-compliant wire termination that helps resist loosening over time.
  • Color Options: Offered in Ivory and White so installers can select the finish that best matches the surrounding decor, device plates, and trim.

Technical Specifications

  • Product Type: Receptacle

Typical Applications

  • Residential Branch Circuit Wiring Requiring AFCI Protection
  • Bedrooms, Living Rooms, and Family Rooms
  • New Construction Electrical Rough-In and Trim-Out
  • Remodel and Renovation Wiring Upgrades
  • Code-Required Replacement of Existing Standard Receptacles
  • General-Purpose Household Outlet Installations

Why Leviton?

Leviton's AFTR1 Residential Grade AFCI Receptacle brings together tamper-resistant construction, Decora styling, and SmartlockPro terminal engineering to deliver a receptacle built for dependable, code-compliant performance in the branch circuit. For electricians and homeowners who need outlet-level arc-fault protection without sacrificing the clean look of a Decora-style device, the AFTR1 pairs recognizable Leviton wiring-device quality with the safety features today's residential codes call for. Choosing Leviton means choosing a wiring device designed to hold up to daily use while helping keep the branch circuit protected.

Manufacturer Resources

Product Specs

Product Type:
Duplex Receptacle
Voltage Rating:
125V
Amperage Rating:
15A
Configuration:
Decora
Series:
SmartlockPro
Department:
Electrical
Product Group:
Wiring Devices
Product Subgroup:
Receptacles & Outlets

Leviton AFTR1-W – Frequently Asked Questions

1) Does the Leviton AFTR1 give me arc-fault protection without an AFCI breaker in the panel?
That is what it is for. The AFTR1 is an outlet branch circuit AFCI receptacle, so the arc-fault detection sits in the device at the outlet rather than in the panel. It is the usual route when the existing breaker panel can't take an AFCI breaker, or on a remodel where you are replacing a standard receptacle to satisfy an arc-fault requirement. It is rated 15A, 125V on a NEMA 5-15R face.
2) Can I put the Leviton AFTR1 on a 20-amp circuit?
No. The AFTR1 is a 15-amp device with a NEMA 5-15R face, so it belongs on a 15-amp branch circuit. A 20-amp circuit needs a 20A-rated AFCI device; this one won't accept a 20-amp T-slot plug either.
3) Is the AFTR1 tamper resistant, or do I need a separate TR receptacle for a bedroom?
Tamper resistance is built in. The AFTR1 has integrated TR shutters that block foreign objects from being pushed into the slots, so it covers both the tamper-resistant and the arc-fault requirement in one device. No second TR receptacle needed downstream of it at that box.
4) Is the AFTR1 the same thing as a GFCI receptacle?
No, and they protect against different hazards. The AFTR1 is an AFCI, built to detect and interrupt arcing faults in the branch circuit wiring, a fire-safety function. A GFCI interrupts ground-fault current to protect people from shock. Kitchens, baths, garages and exterior locations that call for GFCI protection still need a GFCI device; this one does not substitute for it.
5) What colors does the Leviton AFTR1 come in, and will it match my existing Decora plates?
Two colors: Ivory (AFTR1-I) and White (AFTR1-W). The face is a Decora rectangular profile, so it takes a standard Decora/decorator-style wallplate and lines up with Decora switches on the same gang.
6) Is the Leviton AFTR1 rated for commercial or just residential use?
Residential grade. The AFTR1 is built for standard household branch circuits, bedrooms, living and family rooms, new-construction trim-out and remodel work. For high-traffic commercial or institutional openings, a property manager or MRO buyer should be specifying a commercial or spec-grade device instead.
7) Can I use the AFTR1 to replace a plain receptacle on an older circuit and bring it up to code?
Yes, that is one of its intended uses: code-required replacement of an existing standard receptacle where arc-fault protection is now called for. It takes the same NEMA 5-15R plugs the old device did, so nothing plugged in changes. The circuit must be 15-amp, 125-volt for this device to be the right one.
8) What do SmartlockPro terminals mean for wiring up the AFTR1?
SmartlockPro is Leviton's terminal design on this device, intended to hold a secure termination that resists loosening over time. It is still a conventional terminal wiring job on a 15A, 125V two-pole three-wire grounding circuit, so line, load and ground land in the usual places at rough-in or trim-out.
