Leviton Decora Plus Rocker AC Quiet Switch, 120/277V, 20A, 2-Pole

Leviton Decora Plus Rocker AC Quiet Switch, 120/277V, 20A, 2-Pole

(No reviews yet) Write a Review

Model: 5601-2W

In Stock (leaves warehouse same day if ordered before 3pm ET)

$2.75
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Leviton Decora Plus Rocker AC Quiet Switch, 120/277V, 20A, 2-Pole

The Leviton is a Commercial/Specification Grade Rocker AC Quiet Switch from the Decora Plus™ line, built for durable, code-compliant performance in demanding electrical environments. Rated 120/277V AC and 20A with a 2-Pole configuration, this switch (model 5622-2W) delivers reliable circuit control in a clean white finish. The quiet rocker mechanism combines the familiar Decora Plus aesthetic with commercial-grade internal components suited to high-traffic switching applications.

Key Features

  • Voltage Rating: 120/277V AC for use across standard and high-voltage commercial circuits.
  • Amperage Rating: 20A capacity supports demanding commercial and specification-grade switching loads.
  • 2-Pole Configuration: Enables independent control of two circuits or higher-load switching arrangements from a single device.
  • Quiet Rocker Operation: AC quiet switch design minimizes operational noise for office, healthcare, and hospitality environments.
  • Decora Plus™ Styling: Sleek rocker paddle design coordinates with the broader Decora Plus device and wallplate family.
  • Commercial/Specification Grade: Engineered to specification-grade standards for long-term reliability in professional installations.
  • White Finish: Clean, neutral color for consistent appearance across commercial interiors.
  • Model Family Options: Available in related configurations including 5621-2W-P, 5622-2W-P, 5603-2W-P, 5601-2W-P, and 5621-2I-P to match project pole and color requirements.

Technical Specifications

  • Voltage: 120/277V
  • list_batch: LEV-VARMACHINE-20260803

Typical Applications

  • Commercial and Office Building Lighting Control
  • Specification-Grade Electrical Retrofits
  • Healthcare and Hospitality Switching Applications
  • Multi-Pole Circuit Control in Professional Installations
  • New Construction and Renovation Wiring Projects

Why Leviton?

Leviton's Decora Plus Commercial/Specification Grade switches are engineered for the reliability that professional electricians and specifiers depend on, combining a 120/277V, 20A, 2-Pole rating with quiet rocker operation for demanding commercial environments. Choosing Leviton for switching devices means consistent performance backed by a widely recognized specification-grade product line trusted across commercial electrical projects.

Manufacturer Resources

Product Specs

Voltage Rating:
120/277V
Product Type:
Switch
Department:
Electrical
Product Group:
Switches
Product Subgroup:
Switches & Receptacles

Leviton 5601-2W – Frequently Asked Questions

1) What does the 2-pole rating on the Leviton Decora Plus 5622-2W switch actually let me control?
A 2-pole switch breaks both hot legs of a circuit at once from a single paddle. On the Leviton Decora Plus rocker, that means you can switch a 240V or 277V two-wire load, or kill two ungrounded conductors together, rather than the single leg a standard single-pole device opens. It is the device you use when the load or the code requires simultaneous disconnect of both lines, not the one you use to control a light from two locations (that is a 3-way).
2) Will the Leviton Decora Plus rocker switch work on a 277V lighting circuit?
Yes. The Decora Plus rocker is rated 120/277V AC, so it drops straight onto a 277V commercial lighting branch as well as standard 120V. That dual rating is why it shows up on office and warehouse fixture circuits where the panel is 277/480V, and it means one part number covers both voltages on a mixed building.
3) Is a 20A switch required, or can I use a 15A switch on a 20A circuit?
The Decora Plus rocker is rated 20A, which means it can be used on either a 15A or a 20A branch circuit. A 15A-rated switch is not permitted to carry a 20A load, so speccing the 20A device across a building avoids the situation where the wrong box gets opened on a 20A lighting or motor-load circuit. For MRO buyers standardizing a stock room, the 20A device is the one that covers both.
4) Which Leviton 56xx model do I order for a single-pole versus a 3-way versus a 2-pole switch?
The Decora Plus commercial rocker family splits by pole count in the model number: 5601-2W is the single pole, 5603-2W is the 3-way, 5621-2W is the 4-way, and 5622-2W is the 2-pole. Pick by how the box is wired, not by looks, since all four share the same rocker paddle and white face. The 5621 is also offered as 5621-2I in ivory.
5) Can I use the Leviton 5622-2W 2-pole switch to control a light from two different doorways?
No. Controlling one load from two locations takes a pair of 3-way switches, which is the 5603-2W in this family. The 5622-2W is a double pole device: it opens two hot legs together from one location. Adding a third control point means a 4-way in the middle, the 5621-2W, wired between two 3-ways.
6) Does the Leviton Decora Plus switch come with a wallplate?
No. The Decora Plus rocker ships as the device only. You need a Decora/GFCI style rectangular-opening wallplate sized to the gang count of the box, plus the mounting screws that come on the strap. Standard toggle plates will not fit the rocker opening.
7) Why choose a commercial spec grade switch like the Decora Plus over a residential grade rocker?
Two reasons that matter on a job: the 120/277V dual rating, which a residential-grade device does not carry, and internal components built for repeated switching on high-traffic openings. If the circuit is 120V only and the traffic is light, a residential-grade device does the job. On office, healthcare and hospitality lighting, where a switch gets thrown dozens of times a day and the panel may be 277V, the spec-grade device is the one written into the drawings.
8) What color options does the Leviton Decora Plus commercial rocker come in?
White on the 5601, 5603, 5621 and 5622, with the 5621 four-way also offered in ivory as 5621-2I. If you are matching existing devices across a floor, the white is the default commercial spec finish here.
9) What is an AC quiet switch and does it matter in a hospital or hotel corridor?
An AC quiet switch uses a mechanism that dampens the snap you hear on a standard toggle. On the Decora Plus rocker that is the point of the design, and it is why these get specified in patient rooms, guest rooms, and open offices where a loud click at 2am is a complaint. Electrically it behaves the same as any other switch of the same rating.
