Locinox USA SLIMSTONE Weather ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$350.26
Locinox USA SLIMSTONE Weather Resistant Keypad with Smart Heating System

Locinox USA SLIMSTONE Weather Resistant Keypad with Smart Heating System

(No reviews yet) Write a Review

Model: SLIMSTONE-9005
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$350.26
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Locinox USA SLIMSTONE Weather Resistant Keypad with Smart Heating System

The Locinox USA SLIMSTONE Weather Resistant Keypad is an electronic access control keypad engineered for reliable year-round performance in gate and door applications. Operating on 12/24 VDC with a 1 A current draw, this keypad supports up to 100 programmable user codes and features a built-in smart heating system that keeps the unit frost-free in cold climates. Constructed with an aluminum housing and durable stainless steel push buttons, finished in RAL 9005 Black (matte), it delivers a sleek, compact profile measuring 0.93" wide, 2.12" in length, and 5.39" in height.

Key Features

  • Compact Dimensions: Measures 0.93" wide, 2.12" length, and 5.39" height for streamlined mounting on gates and access points.
  • Electrical Specifications: Operates on 12/24 VDC with a 1 A current draw for compatible integration with standard access control power supplies.
  • Smart Heating System: Built-in heating element keeps the keypad frost-free in cold climates, ensuring reliable operation year-round.
  • Weather-Resistant Design: Engineered for year-round reliability in outdoor and exposed installations.
  • Heavy-Duty Construction: Aluminum housing paired with durable stainless steel push buttons for long-lasting performance in commercial applications.
  • Programmable User Codes: Supports up to 100 programmable user codes for flexible access management.
  • Adjustable LED Lighting: Energy-efficient white LED lights with adjustable brightness for visibility in varied lighting conditions.
  • Included Components: Ships with a 2 m connection cable for straightforward wiring during installation.

Certifications & Compliance

  • 2 Year Manufacturer Warranty

Technical Specifications

  • Product Group: Door Trim and Accessories
  • Product Subgroup: Gate Latches and Locks
  • Product Type: Gate Lock
  • Subcategory: Gate Lock
  • Commercial/Residential: Commercial
  • Door Hand Direction: Non-Handed
  • Product Category: Electric Strikes
  • Department: Door Hardware

Typical Applications

  • Commercial Property Perimeter Security
  • Industrial Facility Access Points
  • Multi-Unit Residential Complexes
  • Parking Facility Entry Systems
  • Warehouse and Distribution Centers
  • Educational Institution Access Control
  • Healthcare Facility Access Points

Why Locinox USA SLIMSTONE?

Locinox USA SLIMSTONE keypad products combine an aluminum housing with stainless steel push buttons and a built-in smart heating system to deliver dependable performance even in cold, weather-exposed conditions. Engineered for commercial access control applications, this keypad offers programmable code flexibility and weather-resistant construction for demanding gate and entry installations.

Product Specs

Product Group:
Door Trim and Accessories
Product Subgroup:
Gate Latches and Locks
Product Type:
Gate Lock
Subcategory:
Gate Lock
Commercial/Residential:
Commercial
Product Voltage:
12/24 VDC
Door Hand Direction:
Non-Handed
Product Category:
Electric Strikes
Department:
Door Hardware

Locinox USA SLIMSTONE-9005 – Frequently Asked Questions

1) What voltage does the Locinox SLIMSTONE gate keypad run on, and can I power it from my existing access control supply?
The SLIMSTONE keypad runs on 12/24 VDC and draws 1 A. That means it drops onto most standard access control power supplies without a separate transformer, but size the supply for the full 1 A, not for a typical keypad load. The draw is high because the built-in heating element is part of the same circuit. If your existing panel supply is already near capacity feeding strikes and maglocks, add headroom or run the keypad off its own supply.
2) Will a keypad on an exterior gate keep working through a freezing winter?
The SLIMSTONE is built for it. It carries a smart heating system that keeps the unit frost-free in cold climates, which is the failure point on most outdoor keypads, buttons ice over or the electronics stall. Housing is aluminum with stainless steel push buttons, so the exposed surfaces are the parts that stand up to weather. This is the reason for the 1 A draw at 12/24 VDC; the heat is powered, not passive.
3) Does the Locinox SLIMSTONE keypad lock the gate by itself, or do I need a strike or lock too?
The keypad is the credential reader only. It is a 12/24 VDC access control keypad that switches a circuit; the physical securing is done by the electric gate lock, strike or maglock you wire it to, and you supply that separately along with the power supply. Plan the order as three parts: keypad, electric locking device, and supply. A 2 m connection cable ships with the keypad for the run back to the lock or controller.
4) How many people can I give codes to on the Locinox SLIMSTONE keypad?
Up to 100 programmable user codes. For a property manager that is enough to give every unit in a small to mid-size complex its own code, so you revoke one tenant without re-coding the gate for everyone else. Past 100 doors you are into re-using codes by building or zone, or into a credential-based system instead.
5) Does the SLIMSTONE keypad need to be ordered left hand or right hand for my gate?
No handing to specify. The SLIMSTONE is non-handed, so the same unit works on a left or right swinging gate and on either leaf of a pair. Mount it on whichever side the traffic approaches from.
6) Is the SLIMSTONE keypad readable at night at a parking gate or delivery entrance?
Yes, it uses white LED lighting on the buttons with adjustable brightness, so you can turn it up for an unlit service entrance or down where the keypad sits under a lit canopy and full brightness would glare. The LEDs are the energy-efficient type, which matters when the unit is already pulling 1 A with the heater.
7) What color and finish does the Locinox SLIMSTONE keypad come in?
One finish, RAL 9005 Black in matte. That is the standard black Locinox uses across its gate hardware line, so a SLIMSTONE keypad matches Locinox gate closers, locks and handles already on the property without a color mismatch on the same post. If your gates are powder coated to a different RAL, the keypad will read as black against them.
8) Is the SLIMSTONE keypad rated for commercial traffic or is it a residential unit?
It is specified as commercial. The construction backs that up, an aluminum housing with stainless steel push buttons rather than molded plastic keys, which is the difference that shows up after a few thousand code entries at a warehouse yard or apartment vehicle gate. Typical placements are perimeter gates, industrial access points, parking entries and multi-unit residential complexes.
How fast can I get the Locinox USA SLIMSTONE-9005 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Locinox USA SLIMSTONE-9005 come with a warranty?
Absolutely. The Locinox USA SLIMSTONE-9005 is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Locinox USA SLIMSTONE-9005?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
Why buy the Locinox USA SLIMSTONE-9005 from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.
!
