Product Specs
- Action:
- Maintained
- Actuator:
- Flush, Button
- Bezel:
- Black
- Button Color:
- Green
- Environmental Rating:
- IP67, IP69K, NEMA 4x, 13
- Illumination:
- Illuminated
- Notes:
- Includes contact block mounting adapter.
- Operating Cycles:
- 1,000,000 operations
- Series:
- M22
- Department:
- Electrical
- Product Type:
- Pushbutton
- Product Size:
- 22.5 mm
- Product Length:
- 1.17 IN
- Product Details:
- Pushbutton
- Product Height:
- .39 IN
- Product Weight:
- .995 LB
- Product Width:
- 1.17 IN
B-LINE M22S-DRL-G – Frequently Asked Questions
1) What panel hole size does the B-Line M22S-DRL-G pushbutton mount in?
The M22S-DRL-G is a 22.5 mm operator, so it drops into the standard 22.5 mm panel cutout used across the M22 modular line. The operator body itself measures 1.17 in by 1.17 in by .39 in, so allow for that footprint behind and around the hole when you are laying out a crowded enclosure door.
2) Does the M22S-DRL-G pushbutton come with contact blocks?
No. The M22S-DRL-G is the operator head only. It ships with the contact block mounting adapter, but the actual contact blocks (and the LED element for the illumination) are ordered separately. Plan your order around the number of N.O. and N.C. contacts the circuit needs.
3) Is the M22S-DRL-G a momentary or maintained pushbutton?
Maintained. Press it and the green flush button stays latched until it is pressed again, so it suits on/off or run/enable duty rather than jog or momentary start. If you need the button to spring back on release, a momentary M22 operator is the one to specify instead.
4) Can this green illuminated pushbutton be used in a washdown area or outdoors?
Yes. The M22S-DRL-G carries IP67, IP69K and NEMA 4X and 13 environmental ratings, which covers high pressure and high temperature washdown, dust, and oil exposure. That makes it workable for food processing lines, car washes, and outdoor enclosures, provided the enclosure and the panel gasket are rated to match.
5) Is the M22S-DRL-G button illuminated, and does that need a separate lamp?
It is an illuminated operator, so the green button lights from behind rather than relying on a separate pilot light in the panel. The LED element is a separate M22 module that stacks behind the operator on the mounting adapter, so specify the LED at the voltage your control circuit runs at when you order.
6) How long will an M22 pushbutton last on a machine that gets cycled all shift?
The M22S-DRL-G operator is rated for 1,000,000 mechanical operations. On a line where an operator hits it a few hundred times a shift, that is years of service before the head itself is the wear item. Contact block life is a separate figure and depends on the block and the load you switch through it.
7) Can I use the M22S-DRL-G as an emergency stop?
No. It is a green flush maintained pushbutton, not an E-stop. Emergency stop duty calls for a red mushroom head operator with a dedicated self-monitoring contact block, and the flush green button here is intended for start, run, or enable functions. Specify a proper E-stop operator for that circuit.
8) What does the button and bezel look like on the M22S-DRL-G for matching an existing panel?
Green flush button in a black bezel. Flush means the button sits level with the bezel ring rather than standing proud, so it will not be knocked accidentally by a passing cart or sleeve. If the rest of your panel uses chrome or silver bezel M22 operators, this one will not visually match.
