Milbank 200A 1-Phase Ringless ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$659.57
Milbank 5.125x26.5x14 G90 Galvanized Steel Ringless Meter Socket,4 Terminal, Horn Bypass, Rochester Gas Electric

Milbank 200A 1-Phase Ringless Meter Socket with Horn Bypass - G90 Galvanized Steel Surface Mount

(No reviews yet) Write a Review

Model: U1252-R-KK-RGE

In Stock (leaves warehouse same day if ordered before 3pm ET)

$659.57
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Milbank 200A 1-Phase Ringless Meter Socket with Horn Bypass - G90 Galvanized Steel Surface Mount

Professional utility metering solution with durable galvanized construction

The Milbank 200A continuous ampere ringless meter socket delivers reliable utility metering with professional-grade G90 galvanized steel construction and powder coat finish. This 1-phase, 300V AC rated unit features 4-terminal configuration with horn bypass provision and Type 3R enclosure rating for versatile indoor and outdoor installations. Surface mount design with ground lug equipment grounding provides secure installation and code compliance.

Professional Features & Benefits

  • 200A Continuous Rating: Handles substantial electrical loads for residential and light commercial applications with reliable amperage capacity.
  • G90 Galvanized Steel Construction: Provides superior corrosion resistance and long-term durability in various environmental conditions.
  • Horn Bypass Provision: Enables utility service continuity during meter maintenance without interrupting customer power supply.
  • Type 3R Enclosure Rating: Offers protection against rain, sleet, and ice formation for dependable outdoor installation performance.
  • 4-Terminal Configuration: Accommodates standard utility metering connections with 3/8 inch stud terminals for secure wire termination.
  • UL Listed Certification: Meets rigorous safety and performance standards for professional electrical installations.
  • Ringless Design: Simplifies meter installation and removal while maintaining secure electrical connections.

Technical Specifications

  • Amperage Rating: 200 Continuous Ampere
  • Application: Meter Socket
  • Brand Name: Milbank
  • Bypass Provision: Horn Bypass
  • Departent: Electrical
  • Equipment Ground: Ground Lug
  • Frequency Rating: 60 Hertz
  • Hub Closing Plate: Large Hub Opening
  • Insulation: Glass Polyester
  • Load Side Wire Range: 6 AWG - 350 kcmil
  • Main Breaker Size: No Main Breaker
  • Number Of Jaws: 4 Terminal
  • Number Of Main Breakers: 0
  • Number Of Receptacles: 0
  • Phase: 1 Phase
  • Product Family Code: G200
  • Product Length: 5.125 IN
  • Product Material: G90 Galvanized Steel with Powder Coat Finish
  • Product Mounting: Surface Mount
  • Product Type: Ringless Meter Socket
  • Standard: UL Listed;Type 3R
  • Terminal: 3/8 Inch Stud
  • Unspsc Number: 39121102
  • Voltage Rating: 300 Volts Alternating Current

Professional Applications

  • Residential Service Entrance Metering
  • Small Commercial Building Utility Connections
  • Multi-Unit Residential Properties
  • Professional Office Buildings
  • Retail Establishments
  • Light Industrial Facilities
  • Municipal and Institutional Buildings

Why Choose Milbank Quality?

Milbank meter sockets deliver proven reliability with UL Listed certification and Type 3R environmental protection. The G90 galvanized steel construction with powder coat finish ensures long-term performance in demanding utility applications, while the horn bypass provision supports professional utility maintenance practices without service interruption.

Manufacturer Resources

Product Specs

Amperage Rating:
200 Continuous Ampere
Application:
Meter Socket
Brand Name:
Milbank
Bypass Provision:
Horn Bypass
Equipment Ground:
Ground Lug
Frequency Rating:
60 Hertz
Hub Closing Plate:
Large Hub Opening
Insulation:
Glass Polyester
Load Side Wire Range:
6 AWG - 350 kcmil
Main Breaker Size:
No Main Breaker
Number Of Jaws:
4 Terminal
Number Of Main Breakers:
0
Number Of Receptacles:
0
Phase:
1 Phase
Product Family Code:
G200
Product Length:
5.125 IN
Product Type:
Ringless Meter Socket
Standards:
UL Listed;Type 3R
Terminal:
3/8 Inch Stud
Unspsc Number:
39121102
Voltage Rating:
300 Volts Alternating Current
Product Material:
G90 Galvanized Steel with Powder Coat Finish
Product Mounting:
Surface Mount
Amps:
200
Department:
Electrical
Product Subgroup:
Electrical
Insulation Type:
Glass Polyester
Hub Style:
Large Hub Opening
Installation Category:
Surface Mount
Terminal Type:
3/8 Inch Stud
Number of Phases:
1
Product Details:
Ringless Meter Socket
Frequency:
60 hertz
Number of Terminations:
4
Product Group:
Metering & Service Entrance

Milbank U1252-R-KK-RGE – Frequently Asked Questions

1) Will a ringless meter socket work if my utility requires a sealing ring?
No. The Milbank U125 series socket is a ringless design, meaning the cover clamps and seals without a separate ring. Utilities specify one style or the other, and they are not interchangeable in the field. This one is built to Rochester Gas and Electric requirements, so confirm your serving utility accepts a ringless 4-terminal, 200A horn bypass socket before ordering.
2) What does the position number mean on a Milbank U125 meter socket, 2 through 6?
Position is the number of metered positions in the assembly, and it is the choice you make on the order form. Five are built: 2 position (U1252-R-KK-RGE), 3 position (U1253-R-KK-RGE), 4 position (U1254-R-KK-EX-RGE), 5 position (U1255-R-KK-EX-RGE) and 6 position (U1256-R-KK-EX-RGE). One position per metered tenant or unit. The 4, 5 and 6 position units carry the EX designation the smaller two do not.
3) Can I land 4/0 aluminum or 350 kcmil service conductors in this Milbank meter socket?
Yes. The load side wire range is 6 AWG through 350 kcmil, which covers 4/0 aluminum and copper service conductors for a 200A run as well as smaller feeders. Terminations are 3/8 inch stud type, so ring or compression lugs sized to that stud are what you land on.
4) Does this Milbank multi-position meter socket include a main breaker or main disconnect?
No breaker. The U125 socket ships with no main breaker and zero breaker positions, so it is a metering enclosure only. Overcurrent protection and the service disconnect have to come from separate gear downstream, or from a main-breaker style socket if your installation requires the disconnect in the same enclosure. There are also no convenience receptacles built in.
5) Can a 200A ringless meter socket with horn bypass be mounted outdoors on an exterior wall?
Yes. Type 3R rating covers rain, sleet and ice, and the enclosure is G90 galvanized steel with a powder coat finish for corrosion resistance. It is a surface mount unit, so it fastens to the wall face rather than recessing into it. The socket is UL Listed.
6) What is horn bypass and do I need it on a meter socket?
Horn bypass lets the utility carry load around the meter while the meter is pulled, so power to the customer stays on during a meter change or test. Utilities that require bypass on 200A services will reject a plain non-bypass socket, and many require lever bypass instead of horn. The Milbank U125 is horn bypass, 4 terminal, 1 phase. Match the bypass style your utility specifies, because the socket cannot be converted after the fact.
7) Is a 4-terminal 1-phase meter socket right for 120/240V single phase, or do I need a 3-phase socket?
The 4 terminal, 1 phase configuration is the standard single phase service arrangement, rated 300V AC at 60 Hertz. For a 3-phase service you need a different socket entirely, typically 7 jaw. Four jaws will not accept a 3-phase meter.
8) How much wall space do I need for a Milbank U125 multi-position meter socket, and how deep does it stand off the wall?
Depth off the wall is 5.125 inches. The enclosure measures 5.125 x 26.5 x 14 inches overall. Being surface mount, that full depth projects from the finished wall face, so allow for it where the socket sits near a walkway, a gate swing, or a required working clearance in front of the gear.
9) Does this Milbank socket come with a hub for conduit entry, or do I have to add one?
The socket is supplied with a large hub opening and closing plate arrangement. That means the top entry is sized for a large hub, and the hub itself is selected to match your service conduit size and type; the closing plate covers the opening where no hub is used. Order the hub separately against your conduit trade size.
10) How is the equipment ground landed in a Milbank ringless meter socket, and does it accept a bonded neutral?
Grounding is via a ground lug provided in the enclosure. Jaw insulation is glass polyester. Whether the neutral is bonded to the can at this point depends on where the service disconnect sits, since this socket has no main breaker in it, so the bonding jumper normally belongs at the first means of disconnect downstream.
11) What is the UNSPSC code for a Milbank ringless meter socket for our purchasing system?
UNSPSC 39121102 covers the Milbank U125 ringless meter socket. Product family code is G200, and the brand is Milbank. For a purchase order, cite the position-specific part number, for example U1253-R-KK-RGE for the 3 position unit.
