Milbank 3-Position Ringless Meter Socket with Main Breaker Provision 125A 240V Surface Mount

Milbank 3-Position Ringless Meter Socket with Main Breaker Provision 125A 240V Surface Mount

Professional multi-position metering solution for residential and commercial applications

The Milbank 3-Position Ringless Meter Socket delivers reliable electrical metering and distribution with 125 continuous ampere capacity and up to 240V AC operation. Featuring G90 galvanized steel construction with powder coat finish and Type 3R rating, this surface mount unit provides durable performance for overhead or underground cable entry applications with main breaker provision capability.

Professional Features & Benefits

• 125 Continuous Ampere Rating: Handles substantial electrical loads for multi-unit residential and commercial metering applications
• 3-Position Configuration: Accommodates multiple meter installations in a single compact enclosure for efficient space utilization
• 4 Terminal Ringless Design: Simplifies installation and maintenance with secure jaw connections for reliable meter interface
• Type 3R Enclosure Rating: Provides weather-resistant protection for outdoor installations with rain and sleet resistance
• G90 Galvanized Steel Construction: Ensures long-term durability with corrosion-resistant galvanized steel and protective powder coat finish
• Flexible Cable Entry: Supports both overhead and underground service connections for versatile installation options
• UL Listed Compliance: Meets rigorous safety standards for professional electrical installations

Technical Specifications

• Amperage Rating: 125 Continuous Ampere
• Application: Meter Socket With Main
• Brand Name: Milbank
• Cable Entry: Overhead or Underground
• Departent: Electrical
• Equipment Ground: Ground Lug
• Frequency Rating: 60 Hertz
• Hub Closing Plate: Large Closing Plate
• Insulation: Glass Polyester
• Line Side Wire Range: 6 AWG - 350 kcmil
• Main Breaker Size: Breaker Provision
• Number Branch Circuits: 3
• Number Of Jaws: 4 Terminal
• Number Of Meter Positions: 3 Positions
• Number Of Receptacles: 0
• Phase: 1 Phase
• Product Family Code: CU12
• Product Height: 37 IN
• Product Material: G90 Galvanized Steel with Powder Coat Finish
• Product Mounting: Surface Mount
• Product Type: Ringless Meter Socket
• Special Features: Commonwealth Edison Chicago Housing Authority
• Standard: UL Listed;Type 3R
• Unspsc Number: 39121102
• Voltage Rating: Up to 240 Volts Alternating Current
• Width: 18 IN

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Multi-Unit Residential Properties
• Apartment Buildings and Condominiums
• Commercial Facilities
• Mixed-Use Developments
• Retail Establishments
• Professional Offices
• Light Industrial Applications

Why Choose Milbank Quality?

Milbank delivers proven reliability with UL Listed compliance and Type 3R weather-resistant construction. The G90 galvanized steel with powder coat finish ensures long-term durability, while the glass polyester insulation and ground lug equipment grounding provide safe, professional-grade electrical distribution for demanding metering applications.
