Milbank 200A 1-Phase Ring Type...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$2,263.34
Milbank U8567-O-200 4 Terminal Ring Type Plain Top Pedestal 1-200 Ampere Main Breaker

Milbank 200A 1-Phase Ring Type Meter Socket with Main Breaker Pedestal

(No reviews yet) Write a Review

Model: U8567-O-200

In Stock (leaves warehouse same day if ordered before 3pm ET)

$2,263.34
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Milbank 200A 1-Phase Ring Type Meter Socket with Main Breaker Pedestal

Professional electrical metering and main breaker protection for residential and commercial applications

The Milbank 200A 1-Phase Ring Type Meter Socket with Main Breaker Pedestal delivers reliable electrical service entrance protection with integrated metering capability. This UL Listed pedestal-mounted unit features G90 galvanized steel construction with powder coat finish for superior weather resistance, 4-terminal ring type design for secure connections, and Type 3R enclosure rating for outdoor installation. The single 200 ampere main breaker provides overcurrent protection while the glass polyester insulation ensures long-term electrical integrity.

Professional Features & Benefits

  • 200 Continuous Ampere Rating: Handles substantial electrical loads for residential and light commercial applications with reliable capacity.
  • 1-Phase 240V AC Operation: Compatible with standard residential electrical service requirements and utility connections.
  • G90 Galvanized Steel Construction: Provides exceptional corrosion resistance and structural durability for long-term outdoor service.
  • Type 3R Enclosure Rating: Engineered for outdoor installation with protection against rain, sleet, and ice formation.
  • 4-Terminal Ring Type Design: Ensures secure, reliable connections with accommodated wire ranges from 6 AWG to 350 kcmil line side.
  • Integrated Main Breaker Protection: Single 200 ampere main breaker provides essential overcurrent protection and service disconnect capability.
  • UL Listed Certification: Meets rigorous safety and performance standards for professional electrical installations.

Technical Specifications

  • Amperage Rating: 200 Continuous Ampere
  • Application: Meter Socket With Main
  • Brand Name: Milbank
  • Bypass Provision: No Bypass
  • Cable Entry: Underground
  • Departent: Electrical
  • Equipment Ground: Quadplex Ground
  • Frequency Rating: 60 Hertz
  • Hub Closing Plate: Plain Top
  • Insulation: Glass Polyester
  • Line Side Wire Range: 6 AWG - 350 kcmil
  • Load Side Wire Range: 6 - 2/0 AWG
  • Main Breaker Size: One 200 Ampere Main Breaker
  • Number Of Jaws: 4 Terminal
  • Number Of Main Breakers: 1
  • Number Of Meter Positions: 1 Position
  • Number Of Receptacles: 0
  • Phase: 1 Phase
  • Product Family Code: UPMC
  • Product Height: 42 IN
  • Product Length: 8 IN
  • Product Material: G90 Galvanized Steel with Powder Coat Finish
  • Product Mounting: Pedestal
  • Product Size: 8L x 12W x42H
  • Product Type: Ring Type Meter Socket
  • Standard: UL Listed;Type 3R
  • Terminal: Single Mechanical
  • Unspsc Number: 39121102
  • Voltage Rating: Up to 240 Volts Alternating Current
  • Width: 12 IN

Professional Applications

  • Residential Service Entrance
  • Small Commercial Buildings
  • Multi-Unit Properties
  • Professional Offices
  • Retail Establishments
  • Light Industrial Facilities
  • Utility Metering Applications

Why Choose Milbank Quality?

Milbank delivers proven reliability with UL Listed certification and Type 3R weather protection for demanding outdoor installations. The G90 galvanized steel construction with powder coat finish ensures long-term durability, while the glass polyester insulation and quadplex grounding system provide superior electrical integrity for professional electrical service applications.

Manufacturer Resources

Product Specs

Amperage Rating:
200 Continuous Ampere
Application:
Meter Socket With Main
Brand Name:
Milbank
Bypass Provision:
No Bypass
Cable Entry:
Underground
Equipment Ground:
Quadplex Ground
Frequency Rating:
60 Hertz
Hub Closing Plate:
Plain Top
Insulation:
Glass Polyester
Line Side Wire Range:
6 AWG - 350 kcmil
Load Side Wire Range:
6 - 2/0 AWG
Main Breaker Size:
One 200 Ampere Main Breaker
Number Of Jaws:
4 Terminal
Number Of Main Breakers:
1
Number Of Meter Positions:
1 Position
Number Of Receptacles:
0
Phase:
1 Phase
Product Family Code:
UPMC
Product Height:
42 IN
Product Length:
8 IN
Product Size:
8L x 12W x42H
Product Type:
Ring Type Meter Socket
Standards:
UL Listed;Type 3R
Terminal:
Single Mechanical
Unspsc Number:
39121102
Voltage Rating:
Up to 240 Volts Alternating Current
Product Material:
G90 Galvanized Steel with Powder Coat Finish
Product Mounting:
Pedestal
Amps:
200
Product Width:
12 IN
Department:
Electrical
Product Subgroup:
Electrical
Product Group:
Metering & Service Entrance

Milbank U8567-O-200 – Frequently Asked Questions

1) Will the Milbank U8567-O-200 meter pedestal work for an underground service lateral?
Underground is exactly what it's built for. The U8567-O-200 pedestal is configured for underground cable entry, and the top is a plain top with no hub opening, so there is no provision to bring a service mast or overhead conductors into the top of the can. If the utility is dropping an overhead service, this is the wrong unit and you want a socket with a hub opening or hub closing plate provision instead.
2) Does the Milbank U8567-O-200 pedestal include the main breaker, or do I buy that separately?
The breaker is in the unit. One 200 ampere main breaker comes installed, giving you both overcurrent protection and the service disconnect in the same enclosure, so you are not adding a separate disconnect downstream of the meter. There is only the one breaker, no branch spaces and no receptacles, so any branch distribution has to live in a separate panel fed from the load side.
3) Is a ring type meter socket the right choice, or do I need ringless?
That call belongs to the serving utility, not the installer. The U8567-O-200 is a 4 terminal ring type socket, meaning the meter is retained by a sealing ring around the rim rather than by a ringless cover that clamps the meter. Utilities standardize on one or the other and will refuse to set a meter in the wrong style. Check the utility's approved equipment list before ordering; if they specify ringless, this unit will not be accepted.
4) Can I use this Milbank pedestal on a 208V three phase service?
No. It is a single phase socket rated up to 240 volts AC at 60 Hertz with 4 terminal jaws, which is the residential and light commercial 120/240 single phase configuration. A three phase service needs a 7 jaw socket. Using a 4 jaw single phase socket on three phase is not a matter of derating, the jaw arrangement simply does not match the meter.
5) Does the Milbank U8567-O-200 have a meter bypass for hot socket work?
No bypass provision on this one. There is no lever or horn bypass, so the meter cannot be pulled or set with the socket energized under a bypass. Utilities that require linemen to work the socket live, or that mandate bypass on all new installs, will want a bypass-equipped socket instead. If your utility does not require it, the no-bypass unit is the simpler install.
6) Can this meter socket pedestal be installed outdoors, and will it hold up in a wet climate?
Type 3R rated, so it is built for outdoor use against rain, sleet and ice. The shell is G90 galvanized steel with a powder coat finish over it, which is what gives it corrosion life on a pad exposed to weather year round. The whole unit is UL Listed. Type 3R is not a washdown or dust-tight rating, so it is not the enclosure for a pressure-washed or corrosive process area.
7) Can I meter two units or tenants from one Milbank U8567-O-200 pedestal?
No, it is a single position socket. One meter, one 200 amp main, one service. Metering two tenants separately takes a multi-position socket or a meter stack, one metered position per tenant. This pedestal suits a single detached service point, a well house, a barn, or one dwelling fed underground.
8) What grounding provisions come in the Milbank 200A pedestal meter socket?
It ships with a quadplex ground, a four-hole equipment ground bar, so you have landing points for the grounding electrode conductor and equipment grounding conductors without adding a separate ground bar kit. Bonding of the neutral at the service disconnect still has to be made up per the utility and the NEC for the service entrance location.
9) What is the Milbank part number for the 200 amp ring type pedestal with main breaker?
Milbank U8567-O-200 is the catalog number, a 4 terminal ring type plain top pedestal with one 200 ampere main breaker. It sits in Milbank's UPMC product family. Quote it by that full number, the O and the 200 suffix are what separate it from the other U8567 variants.
10) What insulates the meter jaws in the Milbank U8567-O-200 socket?
Glass polyester carries the jaws. That is the molded thermoset base material used behind the meter jaws, chosen for dimensional stability and dielectric strength over the long term in an outdoor enclosure that sees heat cycling from a 200 amp continuous load.
