MS Sedco MS Sedco CP/STX-P ClearPath Vestibule Post Sequencing Transmitter for 608 Series Bollard MSS-CP/STX-P

MS Sedco CP/STX-P ClearPath Vestibule Post Sequencing Transmitter with HDRC, 300 MHz & 390 MHz

(1 review) Write a Review

Model: CP/STX-P

In Stock (leaves warehouse same day if ordered before 3pm ET)

$130.00
$96.74
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

MS Sedco CP/STX-P ClearPath Vestibule Post Sequencing Transmitter with HDRC, 300 MHz & 390 MHz

The MS Sedco CP/STX-P is a ClearPath's vestibule sequencing transmitter pre-wired with a wire harness and 9V battery, installed on a mounting platform designed to span the top of a 608 Series post assembly. This bollard transmitter is capable of transmitting two separate signals with an adjustable time delay between them, enabling sequential activation of vestibule doors one after the other from either direction. It features three selectable frequencies — HDRC's (High Definition Radio Control's), 300 MHz, and 390 MHz — in a single device, providing unmatched flexibility and backward compatibility with previous MS Sedco products and many other manufacturers' systems. FCC licensed and engineered for commercial applications, the CP/STX-P delivers the most reliable wireless automatic door activation available.

Key Features

  • Vestibule Door Sequencing: Transmits two separate signals with an adjustable time delay between them to sequence vestibule doors one after the other from either direction, ideal for controlled entry management.
  • Three Selectable Frequencies: Incorporates HDRC's, 300 MHz, and 390 MHz in a single device — a simple slide of a switch enables interchangeable use with all past MS Sedco products and compatible third-party systems.
  • High Definition Radio Control's (HDRC's) Technology: Transmits a fixed frequency signal that will not distort due to outside interference, processed through a proprietary electronic filter in the receiver to guarantee door activation.
  • SignalLock's Technology: Guarantees that a radio signal is transmitted every time the switch is activated, eliminating missed activations in demanding environments.
  • Signal Enhancing Antenna: Boosts the radiating strength of the transmitter signal to ensure long-distance door activation reliability.
  • Extended Battery Life: Power-saving circuitry design lowers battery drain by 50%, effectively doubling battery life for reduced maintenance requirements.
  • 608 Series Bollard Compatibility: Mounts on a platform that spans the top of a 608 Series post assembly, arriving pre-wired with wire harness and 9V battery installed for streamlined deployment.
  • Shared PCB Architecture: ClearPath's transmitters share the same printed circuit board (PCB), ensuring consistent performance and simplified serviceability across the product line.

Certifications & Compliance

  • FCC Licensed
  • Compatible with previous MS Sedco devices and many other manufacturers' products operating at 300 MHz and 390 MHz

Technical Specifications

  • Operating Frequency: User-selectable 300MHz, 390MHz or HDRC (filtered 390MHz)
  • Function: Two-output sequencing transmitter with adjustable delay between activations
  • Input Power: 9V alkaline battery
  • Mounting: Post mount for MS Sedco 608 Series bollards
  • Certification: FCC
  • Housing: Blue ABS plastic

Typical Applications

  • Commercial Building Vestibule Entry Systems
  • Healthcare Facility Automatic Door Access
  • Educational Institution Controlled Entry Points
  • Retail Establishment Automatic Door Activation
  • Government and Municipal Building Entrances
  • Industrial Facility Access Control
  • Multi-Tenant Commercial Property Lobbies

Why MS Sedco CP/STX-P?

The MS Sedco CP/STX-P ClearPath's Vestibule Post Sequencing Transmitter delivers professional-grade wireless door activation backed by proprietary HDRC's technology that eliminates interference-related failures — guaranteed to work where conventional RF systems fall short. Arriving pre-wired with a wire harness and 9V battery on a 608 Series bollard-compatible mounting platform, this FCC-licensed transmitter is engineered for demanding commercial environments where dependable, sequential door activation is essential.

Product Specs

Product Group:
Electronic Access Controls
Series:
300/390/HDRC Radio Control
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Type:
Bollard Transmitter
Subcategory:
Radio Control
Commercial/Residential:
Commercial
Electronic:
Yes
Lock Function:
Vestibule
Product Model:
CP/STX-P
Product Function:
Vestibule
Product Category:
Electronic Access Controls
Department:
Door Hardware

MS Sedco CP/STX-P – Frequently Asked Questions

1) Will the MS Sedco CP/STX-P transmitter mount on a 608 Series bollard I already have installed?
Yes. The CP/STX-P comes on a mounting platform built to span the top of a 608 Series post assembly, so it drops onto an existing MS Sedco 608 Series bollard. It ships pre-wired with the wire harness and a 9V alkaline battery already installed, so there is no power run to pull and no low-voltage wiring back to a panel. If your posts are not 608 Series, this platform is not the one to order.
2) How do I sequence two vestibule doors so the inner one opens after the outer one?
That is exactly what the CP/STX-P is built for. It transmits two separate signals with an adjustable time delay between them, so one switch activation opens the first door and then the second after your set delay, working from either direction of travel. You set the delay on the transmitter, so a deep vestibule gets a longer gap and a shallow one a shorter gap. Each door leaf still needs its own ClearPath receiver at its operator, tuned to the frequency you select on the transmitter.
3) What frequency does the MS Sedco CP/STX-P run on, and will it talk to my older MS Sedco receivers?
Three frequencies are built into the one unit and you pick with a slide switch: 300 MHz, 390 MHz, or HDRC, which is a filtered 390 MHz. That is what gives it backward compatibility with previous MS Sedco products and with other manufacturers' equipment running 300 MHz or 390 MHz. So if you are adding a vestibule post to a building already on legacy 300 MHz receivers, set the switch to 300 and it works with what is on the doors. HDRC is the mode to use on new work, since the receiver runs the signal through a proprietary filter so outside RF does not distort it.
4) Do I need to run power or conduit to a wireless vestibule bollard transmitter?
No line voltage and no conduit to the post. The CP/STX-P runs off a single 9V alkaline battery, which is why a bollard can go in the middle of a walkway or an island with no trenching. Power-saving circuitry cuts battery drain by 50 percent compared to the older design, roughly doubling service life between battery changes. The receiver at each door still needs its own power, but the post itself does not.
5) What exactly comes in the box with the MS Sedco CP/STX-P?
You get the sequencing transmitter itself in a blue ABS plastic housing, pre-wired with its wire harness, a 9V battery installed, and the mounting platform that spans the top of the post. What you supply is the 608 Series bollard and push plate assembly, and a ClearPath receiver at each door operator. The transmitter is only half the link.
6) Is the CP/STX-P a whole bollard or just the transmitter head?
Just the transmitter head. The CP/STX-P is the electronics module on a mounting platform, not a complete post. The bollard tube, base, and push plate come from the 608 Series heavy duty push plate activation switch bollard line, and you specify those separately. Ordering this alone leaves you with a transmitter and nothing to stand it on.
7) Should I use a sequencing transmitter or two separate single-door transmitters for a vestibule?
Use one sequencing unit when both doors are activated from the same push plate. The CP/STX-P sends both signals off a single activation with a delay you set between them, so a person hits one plate and walks straight through. Two independent transmitters means the user has to press again at the second door, which defeats the point of an automatic vestibule and is a problem for anyone in a wheelchair or pushing a cart. Where the two doors are genuinely independent openings and not a vestibule pair, separate single-output ClearPath transmitters are the right call.
8) Is the CP/STX-P FCC licensed for commercial building use?
FCC licensed, yes. That is stated on the CP/STX-P, and it is a commercial-rated device rather than a residential one, which matters on healthcare, government, and education work where the AHJ or facilities standard cares about what RF gear is permitted in the building.
9) Our wireless door activation drops out sometimes. Will the ClearPath transmitter fix missed activations?
Two things in the CP/STX-P address that. SignalLock guarantees a radio signal goes out every time the switch is pressed, so a fast or partial press does not get swallowed. HDRC transmits a fixed frequency that will not distort from outside interference, and the receiver filters it, so nearby RF traffic does not swamp the activation. There is also a signal enhancing antenna to hold range on longer runs between the post and the door. If your existing failures are on a plain 300 or 390 MHz link in a noisy building, switching the post to HDRC and pairing it with an HDRC receiver is the fix.
10) Can I service a ClearPath transmitter without swapping the whole assembly?
ClearPath transmitters share the same printed circuit board across the line, so a facility running several of them is dealing with one board and one set of behaviors rather than a different unit at every opening. For maintenance staff the routine item is the 9V battery, which the power-saving circuit stretches to roughly twice the life of the older design.
