MS Sedco CP/TX ClearPath Radio...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$84.00
$61.60
MS Sedco CP/TX ClearPath transmitter open housing showing PCB, Energizer battery, and wiring - interior view

MS Sedco CP/TX ClearPath Radio Control Wall Mount Transmitter with HDRC, 300 MHz & 390 MHz and 5 Programming Modes

(No reviews yet) Write a Review

Model: CP/TX
Selected Faceplate is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$84.00
$61.60
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

MS Sedco CP/TX ClearPath Radio Control Wall Mount Transmitter: Three Selectable Frequencies and HDRC Technology

The MS Sedco CP/TX is the ClearPath Radio Control Wall Mount Transmitter engineered for reliable wireless activation of automatic doors. This transmitter features three selectable frequencies - HDRC (High Definition Radio Control), 300 MHz, and 390 MHz - built directly into the device, allowing compatibility with previous MS Sedco products and many other manufacturers' systems. The unit comes prewired and installed with a 9V battery in a surface mounting box, complete with integrated signal enhancing antennas and wire harness, and measures a compact 4"L x 2"W x 1"H for easy surface mounting.

Key Features

  • Three Selectable Frequencies: Built-in HDRC, 300 MHz, and 390 MHz frequencies allow a simple slide of a switch to change modes, ensuring interchangeability with all past MS Sedco products and other manufacturers' products operating at these frequencies.
  • High Definition Radio Control (HDRC): MS Sedco's latest advancement in RF signal transmission uses sophisticated componentry to transmit a fixed frequency signal that will not distort due to outside interference, passed through a proprietary electronic "filter" in the receiver to ensure reliable door activation.
  • 5 Programming Modes: Mode 1 (standard receiver), Mode 2 (receiver with adjustable time delay: 5, 10, 15, or 20 seconds), Mode 3 (dual channel receiver, requires CP/RXM module), Mode 4 (receiver with sequenced outputs, requires CP/RXM module), and Mode 5 (receiver with ratchet relay, requires CP/RXR module) for maximum operational flexibility.
  • Compact Form Factor: Measures 4"L x 2"W x 1"H, making it suitable for surface mounting in space-constrained locations without sacrificing performance.
  • Complete Ready-to-Install Package: Includes wall mount transmitter, integrated signal enhancing antennas, wire harness, and 9V battery pre-installed in a surface mounting box. No additional components required for standard installation.
  • Shared PCB Architecture: ClearPath transmitters share the same printed circuit board (PCB) and come prewired, simplifying installation and reducing setup time.
  • Interference Resistance: ClearPath radio control switches with HDRC solve problems caused by interference and stray signals, guaranteed to work where conventional RF systems fail.
  • FCC Licensed: ClearPath products are FCC licensed, ensuring regulatory compliance for commercial deployments across the United States.

Certifications and Compliance

  • FCC Licensed
  • Compatible with previous MS Sedco devices and many other manufacturers' products operating at 300 MHz and 390 MHz
  • Commercial Grade

Technical Specifications

  • Operating Frequency: User-selectable 300 MHz, 390 MHz, or HDRC (filtered 390 MHz)
  • Input Power: 9V alkaline battery
  • Mounting: Wall mount with MS Sedco #1020 surface box
  • Certification: FCC
  • Housing: Blue ABS plastic

Typical Applications

  • Commercial Office Building Automatic Door Activation
  • Healthcare Facility Hands-Free Door Access
  • Educational Institution Accessible Entry Systems
  • Retail Establishment Automatic Door Control
  • Industrial and Warehouse Facility Access Points
  • Government and Municipal Building Entry Systems
  • Multi-Tenant Residential and Hospitality Properties

Why MS Sedco ClearPath?

MS Sedco ClearPath transmitters deliver professional-grade wireless door activation through proprietary HDRC technology that eliminates signal distortion caused by outside interference, a limitation of conventional RF systems. The CP/TX's three selectable frequencies and five programming modes provide broad compatibility and operational flexibility, while FCC licensing and backward compatibility with existing MS Sedco and third-party 300 MHz and 390 MHz systems protect existing infrastructure investment.

Product Specs

Product Group:
Electronic Access Controls
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Type:
Radio Control
Subcategory:
Radio Control
Commercial/Residential:
Commercial
Electronic:
Yes
Series:
300/390/HDRC Radio Control
Product Model:
CP/TX
Product Category:
Electronic Access Controls
Department:
Door Hardware

MS Sedco CP/TX – Frequently Asked Questions

1) Will the MS Sedco CP/TX transmitter work with my existing 300 MHz door receivers?
Yes. The CP/TX ClearPath wall mount transmitter has three frequencies built into the same unit, selected by sliding a switch: HDRC, 300 MHz, and 390 MHz. That covers older MS Sedco radio control gear and other manufacturers' equipment running at 300 MHz or 390 MHz, so you can drop it onto an existing installation without swapping the receiver. Set the switch to match whatever the receiver on the door is running.
2) What is HDRC on the MS Sedco ClearPath transmitter, and when should I use it instead of 300 or 390 MHz?
HDRC stands for High Definition Radio Control, and on the ClearPath transmitter it is a filtered 390 MHz signal. The transmitter sends a fixed frequency that resists distortion from outside interference, and the receiver runs it through a proprietary filter before it will activate the door. Use HDRC on any new install, and especially on sites where stray RF is knocking the door open or preventing activation. Use plain 300 MHz or 390 MHz only when you are matching an existing receiver that does not read the HDRC filter.
3) Does the CP/TX wall transmitter need to be hardwired or run to power?
No wiring to the transmitter. The CP/TX runs on a 9V alkaline battery, and it ships with the battery already installed, prewired in a surface mounting box with the antennas and wire harness in place. That means no conduit, no low voltage run, and no cutting into the wall on the push side. Power and wiring are only a concern at the receiver end.
4) Do I need any extra modules with the MS Sedco ClearPath CP/TX transmitter, or is the box complete?
For a standard one-door, one-button setup, the box is complete: transmitter, signal enhancing antennas, wire harness, and 9V battery in the surface mounting box. Extra modules come in only at the receiver, and only for the more advanced programming modes. Mode 3 (dual channel) and Mode 4 (sequenced outputs) each need the CP/RXM module, and Mode 5 (ratchet relay) needs the CP/RXR module. Modes 1 and 2 need nothing added.
5) How much wall space does the MS Sedco CP/TX take, and how does it mount?
The transmitter measures 4 x 2 x 1 inches and mounts to the surface of the wall using the MS Sedco #1020 surface box it comes in. Nothing is recessed, so you do not need a back box in the wall or a cut-in. That footprint is what lets it go on a narrow jamb return, a column, or a wall section where a standard recessed actuator will not fit.
6) Can I set a hold-open delay on a ClearPath radio control door activation?
Yes, through Mode 2, which runs the receiver with an adjustable time delay of 5, 10, 15, or 20 seconds. That is the setting to use where traffic needs the leaf held longer, a wheeled cart or a bed is coming through, or the approach to the opening is long. Mode 1 is the plain receiver with no delay. No extra module is needed for either one.
7) Can one MS Sedco CP/TX transmitter operate two doors or trigger a vestibule sequence?
Two doors, yes, with the right mode and module at the receiver. Mode 3 makes it a dual channel receiver, so one transmitter can address two separate outputs, and Mode 4 gives sequenced outputs, which is what a vestibule needs when the outer leaf has to move before the inner one. Both modes require the CP/RXM module. Mode 5 uses the CP/RXR module for a ratchet relay, which alternates the output state on each activation.
8) What faceplate choices does the MS Sedco CP/TX come with?
Three ways to order it. Blue background with white legend is the standard printed plate that reads as an accessible entry actuator. Stainless steel with blue legend suits lobbies and healthcare corridors where the rest of the hardware is stainless. There is also a no-faceplate option, which is what you take when you are fitting your own engraved or facility-standard plate over the unit. The transmitter itself is the same in all three; the housing is blue ABS plastic.
9) I have several buildings on mixed MS Sedco radio gear. Can I standardize on one transmitter part number?
That is what the CP/TX is built for. Because all three frequencies (HDRC, 300 MHz, and 390 MHz) are inside every unit and picked with a slide switch, one stocked part covers a site running old 300 MHz receivers, another running 390 MHz, and new openings running HDRC. You configure at install rather than ordering a different transmitter per building. ClearPath transmitters also share the same printed circuit board and come prewired, so the install procedure is the same across the fleet.
10) Is the MS Sedco CP/TX approved for commercial use in the US?
The ClearPath transmitter is FCC licensed and rated commercial grade, which is the compliance point that matters for a commercial deployment in the United States. It is used on office building entries, healthcare doors, school accessible entries, retail, warehouse access points, government buildings, and multi-tenant residential and hospitality.
