MS Sedco MS Sedco S-TRX-J ClearPath Spectrum Wireless Radio Control System MSS-S-TRX-J

MS Sedco S-TRX-J ClearPath Spectrum Wireless Radio Control Transceiver with Digital Two-Way Communication

(No reviews yet) Write a Review

Model: S-TRX-J

In Stock (leaves warehouse same day if ordered before 3pm ET)

$175.00
$131.70
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

MS Sedco S-TRX-J ClearPath Spectrum Wireless Radio Control Transceiver with Digital Two-Way Communication

The MS Sedco S-TRX-J is a ClearPath™ Spectrum Wireless Radio Control Transceiver designed for reliable, wireless activation of automatic doors in commercial applications. Operating at 2.4 GHz — a frequency with wavelengths more than 5 times shorter than commonly-used frequencies — the S-TRX-J delivers superior signal penetration through cracks and barriers, continuously attempting to contact the S-COR Coordinator until an acknowledgement is received. The transceiver comes prewired and installed with a battery in a mounting box, sharing the same printed circuit board (PCB) as other ClearPath™ transmitters, and features a 3-year battery life for low-maintenance operation.

Key Features

  • 2.4 GHz Operating Frequency: Operates at 2.4 GHz, producing wavelengths more than 5 times shorter than commonly-used frequencies for superior penetration through cracks and barriers.
  • Digital Two-Way Communication: Bidirectional digital communication ensures greater security and confirms successful signal transmission between the S-TRX-J and the S-COR Coordinator.
  • Persistent Signal Transmission: Upon switch activation, the transceiver continuously attempts to contact the Coordinator until it receives an acknowledgement, maximizing reliability.
  • 3-Year Battery Life: The S-TRX-J features a 3-year battery life, reducing maintenance requirements and ensuring long-term dependable operation.
  • Real-Time Device Diagnostics: Upon switch activation, the transceiver communicates device ID, signal strength, and battery monitoring data displayed on the S-COR's LCD screen for quick status checks.
  • Multi-Transceiver Pairing: Supports pairing of multiple S-TRX-J Transceivers with S-COR Coordinators, enabling scalable system configurations for larger facilities.
  • Pre-Wired, Ready-to-Install Design: Comes prewired and installed with a battery in a mounting box, sharing the same PCB as other ClearPath™ transmitters for simplified installation and system consistency.
  • S-COR Coordinator Compatibility: Functions in conjunction with the S-COR Coordinator, which provides an LCD screen for quick and easy programming and two built-in outputs.

Certifications & Compliance

  • Commercial-Grade Electronic Access Control
  • Part of the MS Sedco ClearPath™ Spectrum Wireless System — Industry-First Digital Two-Way Communication Platform

Technical Specifications

  • System: ClearPath Spectrum wireless radio control transceiver
  • Mounting: Jamb-style surface mounting box
  • Operating Frequency: 2.4 GHz
  • Communication: Digital two-way with S-COR coordinator
  • Battery Life: Approximately 3 years

Typical Applications

  • Commercial Office Building Automatic Door Activation
  • Healthcare Facility Hands-Free Door Control Systems
  • Educational Institution Wireless Access Control
  • Retail Establishment Automatic Entrance Systems
  • Industrial and Warehouse Facility Door Automation
  • Government and Municipal Building Access Control
  • Multi-Tenant Residential Property Entry Systems

Why MS Sedco S-TRX-J?

The MS Sedco S-TRX-J ClearPath™ Spectrum Wireless Transceiver delivers professional-grade reliability through industry-first digital two-way communication operating at 2.4 GHz, ensuring signal integrity even in challenging environments with physical barriers. Engineered for demanding commercial door automation applications, the S-TRX-J's persistent acknowledgement-based transmission protocol and 3-year battery life make it a dependable, low-maintenance choice for facilities requiring consistent, secure wireless door activation.

Product Specs

Product Group:
Electronic Access Controls
Series:
Spectrum Radio Controls
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Type:
Radio Control
Subcategory:
Radio Control
Commercial/Residential:
Commercial
Electronic:
Yes
Product Model:
S-TRX-J
Product Category:
Electronic Access Controls
Department:
Door Hardware

MS Sedco S-TRX-J – Frequently Asked Questions

1) Does the MS Sedco S-TRX-J transceiver work on its own, or do I need something else to open the door?
The S-TRX-J is only half the system. It transmits to the S-COR Coordinator, and the Coordinator is what carries the two built-in outputs that fire the door operator. Order an S-COR with the transceiver if there isn't one already on the job. Once paired, the S-TRX-J keeps trying to reach the Coordinator after a switch activation until it gets an acknowledgement back.
2) How is the S-TRX-J mounted, and does it need to be wired to the door controller?
It mounts in a jamb-style surface box and ships prewired with the battery already installed. There's no control wire back to the operator, the link to the S-COR Coordinator is wireless, so you're not pulling conduit across the opening. The switch wiring into the transceiver is the wiring you do.
3) Will a 2.4 GHz wireless door actuator hold signal through a metal frame or a wall?
That's the reason for the frequency choice. The S-TRX-J runs at 2.4 GHz, whose wavelengths are more than five times shorter than the frequencies usually used for door radio controls, which gets the signal through cracks and barriers rather than around them. It also runs digital two-way communication, so a transmission is confirmed rather than assumed, and it keeps retrying until the Coordinator acknowledges.
4) Can I put more than one wireless actuator on the same door system with the S-TRX-J?
Yes. Multiple S-TRX-J transceivers pair to S-COR Coordinators, so a vestibule with a push plate on each side, or a building with several activation points, runs off the same coordinator setup. That is how these scale in larger facilities.
5) How often will maintenance have to change the battery in a ClearPath Spectrum transceiver?
About every three years. Battery life on the S-TRX-J runs roughly 3 years, and you don't have to guess when it's getting close: on each activation the transceiver reports its battery status and signal strength to the S-COR, which displays it on an LCD screen. A tech can read the whole fleet's condition off the coordinator instead of pulling covers.
6) What is the difference between a one-way radio door transmitter and the S-TRX-J transceiver?
A plain transmitter sends the open signal and never learns whether it landed. The S-TRX-J is a transceiver, so the traffic runs both directions: it confirms the signal reached the S-COR Coordinator, and it sends device ID, signal strength and battery data back on every activation. For an opening where a missed activation means someone standing at a closed door, that acknowledgement is the difference worth paying for.
7) Is the MS Sedco S-TRX-J suitable for a hospital or school entrance, or is it a residential device?
Commercial grade, and built for exactly that kind of traffic: healthcare hands-free door control, school and campus access, office lobbies, retail entrances, warehouse door automation, government buildings and multi-tenant residential entries. It is not a homeowner garage-style remote.
8) Does the S-TRX-J use the same board as the other ClearPath transmitters?
Yes, it shares the printed circuit board used across the ClearPath Spectrum transmitters. For an integrator standardizing a campus, that means one programming routine and one set of spare parts across mixed actuator styles, with the S-TRX-J being the jamb-mount box version.
