MS Sedco MS Sedco S-TRX-V ClearPath Spectrum Wireless Radio Control System MSS-S-TRX-V

MS Sedco S-TRX-V ClearPath Spectrum Wireless Radio Control Transceiver for Automatic Door Activation

(No reviews yet) Write a Review

Model: S-TRX-V

In Stock (leaves warehouse same day if ordered before 3pm ET)

$250.00
$236.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

MS Sedco S-TRX-V ClearPath Spectrum Wireless Radio Control Transceiver for Automatic Door Activation

The MS Sedco S-TRX-V is a ClearPath's Spectrum Wireless Radio Control Transceiver engineered to deliver the most reliable wireless activation of automatic doors available. Operating at 2.4 GHz — a wavelength more than 5 times shorter than commonly-used frequencies — the S-TRX-V passes signals through cracks and barriers with greater ease, and continuously attempts to contact the S-COR Coordinator until an acknowledgement is received. Designed for commercial applications, the S-TRX-V comes prewired and installed with a battery in a mounting box, sharing the same printed circuit board (PCB) as other ClearPath transmitters for seamless system integration.

Key Features

  • 2.4 GHz Operating Frequency: Operates at 2.4 GHz, producing a wavelength more than 5 times shorter than commonly-used frequencies for superior signal penetration through cracks and barriers.
  • Digital Two-Way Communication: Industry-first digital two-way communication provides greater security and ensures successful signal transmission between the transceiver and the S-COR Coordinator.
  • Persistent Signal Transmission: Transceivers continuously attempt to contact the Coordinator until an acknowledgement is received, eliminating missed activations in demanding environments.
  • LCD Screen Programming via S-COR: When paired with the S-COR Coordinator, the system's LCD screen enables quick and easy programming — an industry-first convenience feature.
  • Real-Time Device Diagnostics: Upon switch activation, the transceiver communicates device ID, signal strength, and battery monitoring data directly to the S-COR Coordinator's LCD screen.
  • Multi-Device Pairing: Supports pairing of multiple transceivers with Coordinators for scalable, flexible system configurations across large facilities.
  • Ready-to-Install Design: Comes prewired and installed with a battery in a mounting box, sharing the same PCB as other ClearPath transmitters for simplified deployment.

Certifications & Compliance

  • Commercial Grade — Designed for Commercial Applications
  • Part of the MS Sedco ClearPath' Spectrum Wireless System — Industry-First Digital Two-Way Communication Platform

Technical Specifications

  • System: ClearPath Spectrum wireless radio control transceiver
  • Mounting: Vestibule mounting box with 2 transceivers for independent door activation
  • Operating Frequency: 2.4 GHz
  • Communication: Digital two-way with S-COR coordinator
  • Battery Life: Approximately 3 years

Typical Applications

  • Commercial Office Building Automatic Door Systems
  • Healthcare Facility Hands-Free Door Activation
  • Educational Institution Accessible Entry Points
  • Retail Establishment Automatic Entrance Doors
  • Industrial and Warehouse Facility Access Control
  • Government and Municipal Building Automatic Doors
  • Multi-Tenant Residential and Mixed-Use Property Entries

Why MS Sedco S-TRX-V?

The MS Sedco S-TRX-V ClearPath Spectrum Transceiver delivers professional-grade wireless door activation reliability through industry-first digital two-way communication operating at 2.4 GHz — a frequency that provides superior barrier penetration compared to commonly-used alternatives. Its persistent acknowledgement-based signal protocol and real-time diagnostics including device ID, signal strength, and battery monitoring make it a dependable choice for demanding commercial automatic door applications.

Product Specs

Product Group:
Electronic Access Controls
Series:
Spectrum Radio Controls
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Type:
Radio Control
Subcategory:
Radio Control
Commercial/Residential:
Commercial
Electronic:
Yes
Product Model:
S-TRX-V
Product Category:
Electronic Access Controls
Department:
Door Hardware

MS Sedco S-TRX-V – Frequently Asked Questions

1) Does the MS Sedco S-TRX-V work on its own, or do I need the S-COR coordinator too?
The S-TRX-V is only half a system. It talks to the S-COR Coordinator using digital two-way communication, and it keeps retrying until the Coordinator acknowledges the signal. Programming is done on the S-COR's LCD screen, so plan on a Coordinator at the door operator plus one or more transceivers at the activation points.
2) Can one S-TRX-V run two separate automatic doors in a vestibule?
Yes. The S-TRX-V ships as a vestibule mounting box holding two transceivers, so each one can activate a door independently. That is the configuration for an airlock or double-entry vestibule where the inner and outer doors need separate activation.
3) How long does the battery last in the S-TRX-V and will I know when it is low?
Battery life runs about three years. You don't have to guess where it stands: every time a switch is activated the transceiver reports device ID, signal strength, and battery monitoring data to the S-COR Coordinator's LCD screen, so maintenance staff can read the state of each device without pulling covers.
4) Why does the S-TRX-V use 2.4 GHz instead of the usual door radio frequencies?
2.4 GHz produces a wavelength more than five times shorter than commonly used door radio frequencies, so the signal gets through cracks and around barriers more easily. In a vestibule or a building with metal frames and glass, that is what keeps the activation from dropping.
5) What comes in the box with the S-TRX-V, and how much wiring is involved?
It arrives prewired with the battery already installed in its mounting box, so there is no line voltage run to the activation point. It also uses the same printed circuit board as the other ClearPath transmitters, which keeps programming and spares consistent if you already run ClearPath elsewhere in the building.
6) Can I add more transceivers to one coordinator as I expand the building?
Yes. Multiple transceivers can be paired to a Coordinator, which is how larger facilities cover several activation points on one system. Pairing is done through the Coordinator's LCD screen.
7) What exactly is the MS Sedco S-TRX-V, a push plate or a receiver?
It is a wireless radio control transceiver in the ClearPath Spectrum series, model S-TRX-V. It takes the signal from an activation switch and sends it wirelessly to the S-COR Coordinator, which drives the door operator. The switch or push plate itself is a separate item.
8) Is the S-TRX-V rated for commercial buildings or is it a residential product?
Commercial. MS Sedco lists the S-TRX-V as commercial grade for applications like healthcare hands-free entries, schools, retail entrances, warehouses, government buildings, and multi-tenant residential lobbies.
