NGP 102VA Vinyl Door Sweep with Anodized Aluminum Housing

NGP 102VA Vinyl Door Sweep with Anodized Aluminum Housing

(No reviews yet) Write a Review

Model: 102VA-36

In Stock (leaves warehouse same day if ordered before 3pm ET)

$41.41
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

NGP 102VA Vinyl Door Sweep with Anodized Aluminum Housing

Professional Door Bottom Sealing Solution

The NGP 102VA Vinyl Door Sweep combines durable anodized aluminum construction with high-performance PVC vinyl sealing for effective door bottom weatherization. Featuring aluminum alloy 6063 T5 temper housing and thermoplastic polymer vinyl formulated with environmentally friendly bio-based plasticizer, this door sweep operates reliably in temperatures from 0 F to 140 F. The economical design includes slotted screw holes for precise adjustment and comes complete with #6 x 3/4" stainless steel screws for secure installation.

Professional Features & Benefits

  • Temperature Performance: Operates effectively in temperature range from 0 F to 140 F for year-round reliability in various climate conditions.
  • Durable Aluminum Construction: Aluminum alloy 6063 T5 temper housing with anodized finish provides exceptional corrosion resistance and long-term durability.
  • Environmentally Friendly Materials: Thermoplastic polymer vinyl formulated with bio-based plasticizer reduces environmental impact while maintaining performance.
  • Flame and Moisture Resistant: PVC vinyl construction offers flame resistance and moisture resistance for enhanced safety and weather protection.
  • Adjustable Installation: Slotted screw holes allow for precise positioning and adjustment during installation for optimal sealing performance.
  • Complete Hardware Package: Includes #6 x 3/4" stainless steel SMS screws for secure mounting and professional installation.
  • Professional Gray Finish: Gray vinyl provides a neutral appearance that complements various door finishes and architectural styles.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Product Category: Door Trim and Accessories
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Door Bottom Sweeps and Door Shoes
  • Product Type: Door Sweeps and Bottoms
  • Series: Vinyl Door Sweep Series
  • Subcategory: Gaskets & Weatherstripping

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose NGP Quality?

NGP door sweep products deliver professional-grade reliability with aluminum alloy 6063 T5 temper construction and environmentally friendly bio-based plasticizer formulation. The flame and moisture resistant design operates effectively from 0 F to 140 F for demanding commercial applications. Engineered for dependable weatherization performance where consistent door bottom sealing is essential.

Product Specs

Product Group:
Door Trim and Accessories
Series:
Vinyl Door Sweep Series
Product Subgroup:
Door Bottom Sweeps and Door Shoes
Product Type:
Door Sweeps and Bottoms
Subcategory:
Gaskets & Weatherstripping
Commercial/Residential:
Commercial
Product Category:
Door Trim and Accessories
Department:
Door Hardware

NGP 102VA-36 – Frequently Asked Questions

1) Does the NGP 102VA door sweep come with mounting screws?
Yes, #6 x 3/4 inch stainless steel sheet metal screws ship with the sweep. Nothing else is needed for a standard hollow metal or wood door, though the screws are self-drilling into a pilot hole rather than through-bolts, so on a hollow metal door you drill and pilot the face. The screw holes in the housing are slotted, so you can set the sweep, close the door, and slide it up or down to get an even seal on the threshold before final tightening.
2) Will the NGP 102VA vinyl sweep hold up outdoors in cold winters and hot summers?
The 102VA is rated from 0 F to 140 F. That covers most of the continental US, but in a climate that runs below zero regularly, the vinyl blade will stiffen outside its stated range and the seal gets less forgiving. The housing is anodized 6063 T5 aluminum, so corrosion resistance on the metal side is not the limiting factor, the vinyl temperature range is.
3) What is the closest equivalent to the NGP 102VA vinyl door sweep from another brand?
The nearest peer is the Cal-Royal BTN-112 door bottom sweep, which uses an extruded aluminum retainer with a neoprene insert. The NGP 102VA pairs an anodized aluminum alloy 6063 T5 housing with a PVC vinyl seal and slotted screw holes for height adjustment, and ships with #6 x 3/4 inch stainless steel screws. Both are surface-applied sweeps that fasten to the face of the door bottom; the difference is the sealing material, neoprene on the BTN-112 versus vinyl on the 102VA.
4) What should I use instead of a vinyl door sweep when the threshold gap is uneven or the floor is worn?
A brush sweep rides an irregular floor better than a solid vinyl blade. The Pemko 29326NB is a 36 inch brush door bottom sweep with clear anodized aluminum and a concealed fastener design. The NGP 102VA seals with a PVC vinyl blade in an anodized aluminum housing and uses slotted screw holes so the housing can be dropped or raised to suit the gap, but the sweep line stays straight across the opening.
5) For an exterior door taking driven rain, is a door sweep enough or do I need something else?
A sweep seals the gap between door bottom and threshold; it does not shed water running down the face of the door. For that, the Pemko 3452 is a surface plate rain drip door bottom, which combines the bottom seal with a drip that throws water clear of the sill. The NGP 102VA is a vinyl sweep in an anodized aluminum housing rated for 0 F to 140 F with a flame and moisture resistant PVC seal, and it is often applied on the interior face where a separate drip cap handles the runoff.
6) Is a vinyl door sweep or a brush sweep better for an exterior commercial door?
A vinyl blade like the 102VA gives you a continuous contact seal against the threshold, which is what you want for air and moisture at an exterior opening. A brush sweep, such as the Pemko 29326NB or the Cal-Royal BTN-112 with its neoprene insert, sweeps debris and tolerates an uneven or rough floor better, but bristles do not seal air as tightly as a solid vinyl blade. On a smooth threshold, go vinyl. On a rough concrete slab or where the door drags, go brush.
7) Is the NGP 102VA door sweep surface mounted on the face of the door?
Yes, it is a surface applied sweep. The aluminum housing screws to the face of the door near the bottom edge with the vinyl blade projecting down to the threshold, so it goes on without any door prep, machining, or removing the door from its hinges. That is the difference from a door shoe, which wraps the bottom edge, and from an automatic door bottom, which mortises into the door.
8) Can I use the NGP 102VA on a fire rated door?
The 102VA vinyl is flame resistant, which is a material property, not a door assembly rating. Use it for weather and air sealing. If the opening is a rated assembly and you need listed gasketing to satisfy the inspection, specify a product carrying the rating for that assembly rather than relying on the material description here.
9) I need a low VOC or green certified door sweep for a LEED project. Is the NGP 102VA it?
The 102VA uses a thermoplastic polymer vinyl made with a bio-based plasticizer, which reduces the petroleum content in the seal. If your spec calls for a certification on the document, the Pemko 345V carries a GREENGUARD Gold certified Eco-V insert and is the one to submit. The 345V is the safer choice when the submittal has to show a certification mark rather than a material claim.
10) Will a door sweep alone stop water from blowing under my exterior door?
A sweep like the 102VA seals the gap between the door bottom and the threshold, and the PVC vinyl is moisture resistant, but on a wind driven rain exposure the water usually runs down the door face and gets behind the sweep. For that condition add a rain drip above the opening or use a drip type bottom such as the Pemko 3452 surface plate rain drip door bottom, which sheds the water off the face before it reaches the sweep line.
11) Which door sweep should I specify on a project with a green building or indoor air quality requirement?
The Pemko 345V door bottom sweep carries a GREENGUARD Gold certified Eco-V insert, which is the value a submittal reviewer looks for on that line. The NGP 102VA uses a thermoplastic polymer vinyl formulated with a bio-based plasticizer in an anodized aluminum alloy 6063 T5 housing. Both are aluminum-housed surface sweeps; the 345V answers the certification question with a third-party listing, while the 102VA answers it at the material level.
12) I need to standardize 36 inch door sweeps across a building. What are my options besides the NGP 102VA?
The NGP 102VA comes in 36 inch and 48 inch lengths, so a 36 inch leaf takes it as-is and a wider opening is cut down from the 48. Peer sweeps at that same 36 inch length include the Pemko 56 Series with an Eco-V insert and the Pemko 29326NB brush sweep in clear anodized aluminum with concealed fasteners. Picking one seal type across the fleet keeps replacement stock to a single line item.
13) Is a rain drip door bottom a drop-in replacement for a vinyl sweep?
No. The Pemko 3452 is a surface plate rain drip door bottom, so it adds a projecting drip profile at the door bottom rather than just a seal blade. The NGP 102VA is a vinyl sweep whose anodized aluminum housing mounts flat to the door face with slotted screw holes and #6 x 3/4 inch stainless steel screws. If a 102VA is coming off the door, confirm the drip profile clears the threshold and any weatherstripping already at the sill before swapping in a drip-style bottom.
14) Is the NGP 102VA rated for commercial traffic or is it a residential weatherstrip?
It is a commercial product. The anodized aluminum extrusion and stainless steel fasteners are specified for office buildings, schools, healthcare, retail, warehouses, multi-tenant residential, and government facilities. For a property manager standardizing door bottoms across a portfolio, the 102VA is the economy vinyl option in NGP's sweep line rather than a heavy duty automatic bottom.
15) What color is the NGP 102VA sweep and will it match my existing aluminum doors?
Anodized aluminum housing with a gray vinyl blade. The anodized housing reads as a natural silver aluminum, so it blends with clear anodized storefront and aluminum entrances. The gray vinyl is neutral and does not shift toward brown or black against a painted hollow metal frame. Both lengths carry the same finish, so a mixed 36 and 48 inch order across a building still matches face to face.
