NGP 5V Vinyl Door Shoe with Mill Aluminum Construction and Black PVC Seal

NGP 5V Vinyl Door Shoe with Mill Aluminum Construction and Black PVC Seal

(No reviews yet) Write a Review

Model: 5V-36
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$54.99
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

NGP Vinyl Door Shoe with Mill Aluminum Construction and Black PVC Seal

Professional Door Bottom Sealing Solution

The NGP Vinyl Door Shoe combines durable mill aluminum construction with black PVC vinyl sealing for effective door bottom weatherization. Featuring aluminum alloy 6063 T5 temper construction and thermoplastic polymer PVC formulated with environmentally friendly bio-based plasticizer, this door shoe operates reliably in temperatures from 0 F to 140 F. The economical design includes slotted screw holes for easy adjustment and comes complete with #6 x 3/4" stainless steel sheet metal screws.

Professional Features & Benefits

  • Temperature Performance: Operates effectively from 0 F to 140 F for reliable sealing across seasonal temperature variations.
  • Durable Aluminum Construction: Aluminum alloy 6063 T5 temper provides exceptional strength and corrosion resistance for long-term commercial applications.
  • Environmentally Friendly Materials: PVC formulated with bio-based plasticizer reduces environmental impact while maintaining performance characteristics.
  • Flame and Moisture Resistant: Specialized vinyl formulation provides flame resistance and moisture protection for enhanced safety and durability.
  • Adjustable Installation: Slotted screw holes allow for precise positioning and alignment during installation for optimal sealing performance.
  • Complete Hardware Package: Includes #6 x 3/4" stainless steel sheet metal screws for secure mounting and corrosion resistance.
  • Professional Appearance: Mill aluminum finish with black vinyl seal provides clean, professional appearance suitable for commercial applications.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Product Category: Door Trim and Accessories
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Door Bottom Sweeps and Door Shoes
  • Product Type: Door Shoes
  • Series: Vinyl Door Shoe Series
  • Subcategory: Gaskets & Weatherstripping

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose NGP Quality?

NGP door shoes deliver professional-grade weatherization with aluminum alloy 6063 T5 temper construction and environmentally friendly PVC formulation. The temperature-tested performance from 0 F to 140 F ensures reliable sealing across demanding commercial applications. Engineered with flame and moisture resistant materials for dependable long-term performance where effective door bottom sealing is essential.

Product Specs

Product Group:
Door Trim and Accessories
Series:
Vinyl Door Shoe Series
Product Subgroup:
Door Bottom Sweeps and Door Shoes
Product Type:
Door Shoes
Subcategory:
Gaskets & Weatherstripping
Commercial/Residential:
Commercial
Product Category:
Door Trim and Accessories
Department:
Door Hardware

NGP 5V-36 – Frequently Asked Questions

1) Will the NGP 5V door shoe fit a 36 inch wide door, or do I need to cut it?
The 5V vinyl door shoe comes in 36 inch and 48 inch lengths. On a standard 36 inch leaf the 36 inch piece goes on as-is; for a 42 or 48 inch opening, order the 48 inch and trim the aluminum extrusion down to the leaf width. Cutting shortens it, so size up rather than down, and take the 48 inch for anything over 36.
2) Does the NGP 5V door shoe have a rain drip on it?
The 5V is the plain economy shoe: mill aluminum or dark bronze carrier with a black PVC insert, no drip cap. If the opening takes driving rain and you want water thrown clear of the sill, the Pemko 211V and the Pemko 215 are both door shoes with a rain drip built in. Use the 5V where the opening is under a canopy or interior-adjacent.
3) Can I put a vinyl door shoe on a fire rated door?
Don't specify the 5V for a labeled opening. It's a weatherization shoe, not a fire-rated assembly. When the door carries a label, use a shoe listed for it: the Pemko 210 is a fire-rated door bottom shoe, and the Pemko 215 is fire-rated and UL10C certified. Putting an unlisted shoe on a labeled door is the kind of thing an AHJ writes up on a walkthrough.
4) What is a direct equivalent to the NGP 5V vinyl door shoe from another manufacturer?
The Cal-Royal DS-403 is an aluminum door shoe with a vinyl insert, the same basic part: an extruded aluminum carrier fastened to the door bottom with a vinyl seal riding on the threshold. The Pemko 209 is the same type of part with an Eco-V vinyl insert on a 1/2 inch by 1-3/8 inch profile. The NGP 5V is a mill aluminum or dark bronze carrier with a black PVC seal in 36 inch and 48 inch lengths, so measure the door width and the amount of shoe that has to wrap the door bottom before picking between them.
5) What door shoe should be used on a fire-rated opening instead of the NGP 5V?
Go to a shoe the manufacturer publishes as fire-rated. The Pemko 210 is a fire-rated door bottom shoe with an Eco-V insert in 36 inch aluminum construction, and the Pemko 215 is a fire-rated door shoe carrying UL10C certification with a rain drip and Eco-V insert. The NGP 5V is a commercial weatherization shoe in aluminum alloy 6063 T5 with a flame and moisture resistant PVC seal rated 0 F to 140 F; for a labeled door assembly the specifier will want the rated part number on the submittal.
6) What door shoe handles driving rain on an exterior entrance better than a plain vinyl shoe?
Look for a shoe with an integral rain drip. The Pemko 211V is an L-shaped door shoe with a rain drip and a GREENGUARD Gold certified Eco-V insert, and the Pemko 215 also carries a rain drip. The drip leg throws water clear of the door bottom and the threshold joint. The NGP 5V is a mill aluminum or dark bronze carrier with a black PVC seal and no drip leg, which suits interior and sheltered exterior openings where the seal is doing weatherization rather than shedding runoff.
7) What finishes does the NGP 5V door shoe come in, and can I get the 48 inch in dark bronze?
Two finishes on the 5V: mill aluminum and dark bronze. Both are made in 36 inch and 48 inch, so a 48 inch dark bronze is an orderable combination. Mill aluminum is the plain unfinished extrusion that disappears against aluminum storefront; dark bronze matches bronze anodized frames and dark painted hollow metal.
8) Do I need to buy screws separately for an NGP 5V door shoe?
No extra hardware needed. Each 5V door shoe ships with #6 x 3/4 inch stainless steel sheet metal screws, and the mounting holes are slotted so you can shift the shoe up or down to set the seal against the threshold before you tighten. Stainless fasteners matter on an exterior opening where a plated screw would rust and streak the door face.
9) Will a vinyl door shoe seal an exterior door in a cold climate?
The 5V is rated 0 F to 140 F, which covers most of the continental US swing but not a sustained deep-freeze opening. Below zero the PVC stiffens and the seal gets less forgiving of a door that has settled. On a walk-in cooler door or a far-northern exterior entrance, look at a silicone-insert shoe instead. For a typical commercial entry, office, school, or warehouse man-door, the 0 to 140 F range is the working band.
10) Is a door shoe the right thing, or should I use a door sweep?
A shoe like the 5V wraps the bottom edge of the door, so the aluminum carrier caps the door bottom and the PVC insert rides on the threshold or sill. A sweep only screws to the face of the door and hangs a seal below it. Pick the shoe when you also want to protect a wood door bottom from water and when you have threshold clearance to work with; pick a face-mounted sweep when the door is already close to the floor or you cannot get at the bottom edge without pulling the door.
11) I have Pemko door shoes on the rest of the building. Can I put an NGP 5V on one door?
Functionally it will seal the same way, but it won't look identical. The 5V uses a black PVC insert in a mill aluminum or dark bronze carrier; the Pemko 209, 211V and 215 all run Eco-V vinyl inserts and the 211V is an L-shaped profile rather than a straight one. If you are standardizing a facility and the doors sit side by side, stay with the family you already have. For a single back-of-house door out of sight of the matched openings, the NGP is a straight substitution.
12) Is the Pemko 210 a drop-in replacement for an NGP 5V door shoe?
Treat it as a different part, not a swap. The Pemko 210 is a fire-rated door bottom shoe supplied in 36 inch aluminum construction, so it matches the 36 inch NGP 5V on length but is a rated assembly with its own insert. Carriers from different manufacturers differ in leg height and the amount they lap up the face of the door, so a shoe pulled off one door will not necessarily cover the fastener holes left by another. Mark and drill fresh; the NGP 5V uses slotted screw holes and ships with #6 x 3/4 inch stainless steel sheet metal screws.
13) Which door shoe suits a facility standardizing on low-emission materials?
The Pemko 211V carries a GREENGUARD Gold certified Eco-V insert, which is the certification an institutional spec usually names. The NGP 5V uses a thermoplastic polymer PVC formulated with a bio-based plasticizer and is a commercial-grade part used in healthcare, educational and government buildings. Both are aluminum carriers with a vinyl seal, so the decision comes down to which certification language the facility standard requires on the submittal.
14) What is the difference between the L-shaped Pemko 211V and a standard door shoe like the NGP 5V?
The 211V is an L-shaped shoe with a rain drip, so its profile wraps the door bottom and carries a projecting drip leg on the exterior face. A standard shoe such as the NGP 5V or the Pemko 209, which runs a 1/2 inch by 1-3/8 inch profile, is a simpler carrier holding the vinyl seal with no drip leg. The L-shape needs clearance in front of the door face and changes how the shoe meets the threshold, so confirm the door bottom clearance and the threshold profile before substituting one shape for the other.
15) For a 48 inch wide door, which aluminum vinyl door shoes are worth looking at?
The NGP 5V comes in a 48 inch length in mill aluminum and dark bronze, so it covers a wide leaf without splicing. Among the alternatives, the Pemko 210 is supplied in 36 inch aluminum construction, which means a wide opening needs a longer stock length from that family rather than the 36 inch part. Door shoes are routinely cut down to width, so on a 48 inch leaf start from a 48 inch piece and trim, never butt two short pieces at the middle of the door bottom where the seal has to stay continuous.
16) What is the NGP 5V door shoe actually made of, and will it hold up outdoors?
Carrier is aluminum alloy 6063 T5 temper, the standard architectural extrusion alloy, so it won't rust on an exterior opening. The seal is a thermoplastic PVC formulated with a bio-based plasticizer, flame and moisture resistant. Combined with the stainless mounting screws, there is no ferrous metal in the assembly to bleed rust onto the door.
17) Is the NGP 5V door shoe rated for commercial use or is it a residential part?
Commercial. NGP builds the 5V for office buildings, schools, healthcare, retail, warehouse, multi-tenant residential and municipal work, and the 6063 T5 aluminum carrier is the same extrusion grade used in storefront. It's the economy tier of the commercial line rather than a homeowner part, which is why it's a common spec for a property manager doing a full building's worth of man-doors.
18) Can I adjust a door shoe after it's installed if the seal doesn't touch the threshold?
Yes, and that's the reason to use the 5V on a door that's out of square. The mounting holes are slotted, so you loosen the screws and slide the carrier up or down to bring the PVC insert into contact with the threshold, then retighten. On a door that has dropped on its hinges, this saves you from shimming or re-hanging just to close a light gap.
